NHTSA ID Number: 10140502
Manufacturer Communication Number: 05-61-16
Summary
This bulletin announces a design change to the front strut mounts intended to address customer concerns of a popping-type sound which may be heard when making low speed turns.
NUMBER: 05-61-16
DATE: 04/12/16
APPLICABILITY: | 2012-2016MY Impreza 2.0L Models |
2013-2016MY XV Crosstrek | |
2015-2016MY WRX and WRX STI | |
2014-2016MY Forester | |
2013-2016MY BRZ | |
SUBJECT: | “Popping” Sound from Front Strut Mounts on Low Speed Turns |
INTRODUCTION:
This bulletin announces a design change to the front strut mounts intended to address customer concerns of a popping-type sound which may be heard when making low speed turns.
PRODUCTION CHANGE INFORMATION:
The new strut mounts were incorporated into production as per the table below:
Vehicle / Model | Starting VIN |
---|---|
WRX / WRX STI | G*828073 |
Forester | G*521576 |
Impreza 4-Door | G*010570 |
XV Crosstrek | G*250836 |
BRZ | G*602701 |
PART INFORMATION:
Description | Part Number |
Application |
---|---|---|
STRUT MOUNT- FRONT | 20320FG012 | WRX, WRX STI, Impreza, XV Crosstrek & Forester |
20320AA112 | BRZ |
SERVICE PROCEDURE / INFORMATION:
The new strut mounts are identified by a printed date code on the underside of the strut mount as shown in the photos and illustrations below. Strut mounts with a date code of 151225** (12/25/2015) and newer are the new type. (The 2-digit “Group” number (**) is insignificant for this bulletin.)
NOTE: The lot numbers are fairly small and may be difficult to see. The strut mount must be removed to see the number. |
- Road test the vehicle to confirm the customer concern.
- If the condition is confirmed and the sound determined to be coming from the strut mount(s), inspect the date code as outlined above.
- If the date code is determined to be before 12/25/2015, replace the affected strut mount(s) following the procedure in the applicable Service Manual.
- When complete, road test the vehicle again to confirm the repair.
20 Affected Products
Vehicles
MAKE | MODEL | YEAR |
SUBARU | BRZ | 2013-2016 |
SUBARU | CROSSTREK | 2015-2016 |
SUBARU | FORESTER | 2014-2016 |
SUBARU | IMPREZA | 2012-2016 |
SUBARU | WRX | 2015-2016 |
SUBARU | WRX STI | 2015-2016 |
SUBARU | XV CROSSTREK | 2013-2014 |
1 Associated Document
Manufacturer Communications
NUMBER: 05-61-16
DATE: 04/12/16
https://www.nhtsa.gov/recalls?nhtsaId=10140502
MC-10140502-9999.pdf 312.173KB
“This site contains affiliate links for which OEMDTC may be compensated” |
- Direct Fit, OE Replacement Suspension Kit
- Kit Includes: (2) Front Lower Control Arms with Ball Joints; (2) Front Sway Bar Links; (2) Front Outer Tie Rods
- Vehicle Specific: Check fitment information in the listing for compatibility
- OE Reference Number(s): 20202FJ040,20202FJ050,20420XA000,34141AC0109E,34161SA000
- Aftermarket Reference Number(s): 1015664,20202FJ040,20202FJ050,20420XA000,34141AC0109E,34161SA000,42799,45G20688,536036,5451688,CMS801225,CMS801226,ES3692,ES3712,K750084,MES3712,MS80814,MS80825,RK623560,RK623561,SUS07117,SUS07625,TC2917
- 【Suspension Kit Fitment】 2000 2001 2002 2003 2004 For Subaru Legacy;2000 2001 2002 003 2004 For Subaru Outback;
- 【Suspension Kit Include】(2) ES3712 Front Outer Tie Rod End; (2) EV473 Front Inner Tie Rod End; (2) K80426 Rear Sway Bar End Link; (2) K80693 Front Sway Bar End Link; (2) K9513 Front Lower Ball Joint;
- 【When To Replace Suspension Kit】 ①Steering Noise Sounds When Turning ②Feeling Every Bump ③Difficulty When Steering
- 【Suspension Kit Buyer's Guide】 A Complete Suspension Kit Typically Includes Control Arms, Idler Arm, Pitman Arm, Tie Rod Ends,Sway Bar Links And Ball Joints.All Of Our Suspension Parts Have Been Pregreased Before Delivery, Will Require No More Additional Work.
- 【Note】 Scitoo Auto Provide Suspension Kits For Most Cars,Suvs,Trucks And Trailers.⚠ Please Carefully Select Your Vehicle (Year/Make/Model/Trim )In The Top Left Corner Of The Page To Confirm Compatibility,Or Refer To The Vehicles Information In Description.
- Fits: Specific Models - Check Fitment Chart and Product Description for Accurate Information
- Kit Includes: 2x Front Lower Control Arms + 2x Front Lower Ball Joints + 2x Front Sway Bar End Links + 2x Rear Sway Bar End Links + 4x Front Inner Outer Tie Rod End Links + 2x Rack and Pinion Tie Rod Boots & Bellows
- Detroit Axle Suspension components are ready to meet the rigorous demands of today's foreign and domestic passenger cars, trucks, and SUVs
- Undergo impact, wear, and fatigue testing to help ensure quality and durability
- 10-Year Warranty
- Direct Fit, OE Replacement Suspension Kit
- Kit Includes: (2) Front Lower Control Arms with Ball Joints; (2) Front Sway Bar Links; (2) Front Outer Tie Rods
- Vehicle Specific: Check fitment information in the listing for compatibility
- OE Reference Number(s): 20202SC000,20202SC002,20202SC010,20202SC011,20202SC012,20202SC013,20470SA000,20470SA001,34141AC0109E,34161SA000
- Aftermarket Reference Number(s): 1015179,20202SC000,20202SC002,20202SC010,20202SC011,20202SC012,20202SC013,20470SA000,20470SA001,34141AC0109E,34161SA000,524783,524784,CMS801051,CMS801052,ES3692,ES3712,K750049,MES3712,MS80811,RK622787,RK622789,SUS04827,SUS06139,SUS06140,SUS06771,SUS07625
- Direct replacement - fits and performs like the original equipment bushing on specific vehicles
- Reliable fit - precision-engineered to match the design and dimensions of original components
- Durable construction - manufactured to strict standards using sturdy, safe materials
- Rigorously tested - thorough quality control measures ensure longevity
- Ensure fit - to make sure this part fits your exact vehicle, input your make, model and trim level into the garage tool
- [Vehicle Fitment]: Compatible with Subaru Impreza 2008 2009 2010 2011 2.5L
- [Reference Number]: Replacement for: 272696
- [Location]: Rear Left and Right, Driver and Passenger Side
- [Directly Fit]: This complete strut & coil spring assembly is made to the original equipment dimensions for dependable fit and performance
- [1-Year Quality Guarantee]: This brand new set of suspension shock strut assembly for car is the ideal choice for direct replacement. We extremely value your satisfaction and strive to provide you good shopping experience. Any further question, please feel free to contact us at any time.
- Premium Quality:Made following stringent OE specifications by an OE manufacturer.Each control arm undergo strict quality control not just before shipping but throughout the production process.During each step of production multiple quality control checks are performed to ensure a long,Trouble-free service life.
- Perfect Fit:Engineered and tested to match the fit,function and performance of the original control arm on specified vehicles.Easy to install by direct replacement.
- Upgraded Durability:At TUCAREST,We application engineer,design,manufacture and test all of our products to meet or exceed OEM equivalent parts in terms of aesthetics and performance.
- About Control Arm: Control arms allow wheels to move up and down while preventing forward and rearward movement. They are typically equipped with bushings on the frame side of the vehicle and a ball joint on the wheel side of the vehicle that allow flex and controlled movement according to road conditions and steering input from the driver.
- PLEASE NOTE: Before placing the order, please check your car model in the Amazon Fitment Filter System in the top left corner,Do not count on year make and model only,please view compatability tab including the notes,or send us a message to make sure it matches exactly.
- 【OE Quality】 - Manufactured in ISO9010 certified facility,Made with high strength steel tubing with solid plate mounting brackets for superior strength and durability.Each part is built to stringent OE specifications.Stable characteristics,High reliability.
- 【FEATURES】 - Each control arm assembly is designed for specific application,All parts are assembled in a fully automatic shop to hold the tightest engineering tolerance and to achieve the perfect OE fit.Rigorously tested for secure and sustained performance by team of skilled engineers.Including the application of specific heat treatment hardware.
- 【Precise fit】 - All parts are pre-assembled.It can be installed easily without using complicated tools.Tolerances to directly replace the original part on certain vehicle years,Makes and models.
- 【Cost-effective】- We are a factory direct sales.Customers can spend a small amount of money and get high quality Brand new Control arm.It not only makes your car safer on the road but also gives you a more pleasant and smoother driving experience.
- 【Please Note】 - Before placing the order,please check your car model in the Amazon Fitment Filter System in the top left corner,Do not count on year make and model only,view compatability tab including the notes.Any problem please free to contact us and you will get a satisfactory solution.
- Direct Fit, OE Replacement Suspension Kit
- Kit Includes: (2) Front Lower Control Arms with Ball Joints; (2) Front Sway Bar Links
- Vehicle Specific: Check fitment information in the listing for compatibility
- OE Reference Number(s): 20202FJ040,20202FJ050,20420XA000
- Aftermarket Reference Number(s): 1015664,20202FJ040,20202FJ050,20420XA000,42799,45G20688,536036,5451688,CMS801225,CMS801226,K750084,MS80814,MS80825,RK623560,RK623561,SUS07117,TC2917
Last update on 2024-04-11 / Affiliate links / Images from Amazon Product Advertising API
This product presentation was made with AAWP plugin.
SEOCONTENT-START
Bulletin Number: 05-61-16; Date: 04/12/16 Page 1
NUMBER: 05-61-16
DATE: 04/12/16
APPLICABILITY: 2012-2016MY Impreza 2.0L Models
2013-2016MY XV Crosstrek
2015-2016MY WRX and WRX STI
2014-2016MY Forester 2013-2016MY BRZ
SUBJECT: “Popping” Sound from Front Strut Mounts on Low Speed Turns
Continued…
SERVICE INFORMATION
ATTENTION:
GENERAL MANAGER 0
PARTS MANAGER 0
CLAIMS PERSONNEL 0
SERVICE MANAGER 0 IMPORTANT – All
Service Personnel Should Read and Initial in the boxes provided, right.
© 2016 Subaru of America, Inc. All rights reserved.
CAUTION: VEHICLE SERVICING PERFORMED BY UNTRAINED PERSONS COULD RESULT IN SERIOUS INJURY TO THOSE PERSONS OR TO OTHERS.
Subaru Service Bulletins are intended for use by professional technicians ONLY. They are written to inform those technicians of conditions that may occur in some vehicles, or to provide information that could assist in the proper servicing of the vehicle. Properly trained technicians have the equipment, tools, safety instructions, and know-how to do the job correctly and safely. If a condition is described, DO NOT assume that this Service Bulletin applies to your vehicle, or that your vehicle will have that condition.
SUBARU OF AMERICA, INC. IS ISO 14001 COMPLIANT
ISO 14001 is the international standard for excellence in Environmental Management Systems. Please recycle or dispose of automotiveproductsinamannerthatisfriendly to our environment and in accordance with all local, state and federal laws and regulations.
INTRODUCTION:
This bulletin announces a design change to the front strut mounts intended to address customer concerns of a popping-type sound which may be heard when making low speed turns. PRODUCTION CHANGE INFORMATION:
The new strut mounts were incorporated into production as per the table below:
Vehicle / Model
WRX / WRX STI
Forester Impreza 4-Door XV Crosstrek BRZ
Starting VIN G*828073 G*521576 G*010570 G*250836 G*602701 PART INFORMATION:
Description
Part Number
Application
STRUT MOUNT- FRONT 20320FG012
20320AA112
WRX, WRX STI, Impreza, XV
Crosstrek & Forester BRZ
SERVICE PROCEDURE / INFORMATION:
The new strut mounts are identified by a printed date code on the underside of the strut mount as
shown in the photos and illustrations below. Strut mounts with a date code of 151225** (12/25/2015)
and newer are the new type. (The 2-digit “Group” number (**) is insignificant for this bulletin.) Bulletin Number: 05-61-16; Date: 04/12/16 Page 2
• Road test the vehicle to confirm the customer concern.
• If the condition is confirmed and the sound determined to be coming from the strut mount(s),
inspect the date code as outlined above.
• If the date code is determined to be before 12/25/2015, replace the affected strut mount(s)
following the procedure in the applicable Service Manual.
• When complete, road test the vehicle again to confirm the repair. WARRANTY / CLAIM INFORMATION:
For vehicles within the Basic New Car Limited Warranty period or covered by a Subaru Added
Security Classic or Gold plan, this repair may be submitted using the following claim information: Labor Description
ONE STRUT MOUNT R&R*
BOTH STRUT MOUNTS R&R* Labor Operation # B611-201 B611-204 Applicability EXCEPT BRZ BRZ
EXCEPT BRZ BRZ Failure Code NAB-25 Labor Time
2.0
1.7
2.4
2.1 * INCLUDING wheel alignment IMPORTANT REMINDERS:
• SOA strongly discourages the printing and/or local storage of service information as previously released information and electronic publications may be updated at any time.
• Always check for any open recalls or campaigns anytime a vehicle is in for servicing.
• Always refer to STIS for the latest service information before performing any repairs.
NOTE: The lot numbers are fairly small and may be difficult to see. The strut mount must be removed
to see the number.
**************************************************************************************************************
**************************************************************************************************************
