Accessory Installation Guide
| 2019-24MY Ascent -Illuminated Cargo Sill | H61SXC300 |
INSTALLATION INSTRUCTIONS
PART NUMBER: H461SXC300
DESCRIPTION: Ascent Illuminated Cargo Sill
STEP 1: Prepare for the Installation.
(a) Inspect all kit components and check for damage or missing parts.
(b) Remove the negative battery terminal.
CAUTION: Do not touch the positive terminal with any part of the tool when removing the cable.
STEP 2: Disassemble the Vehicle.
(a). Remove cargo floor panel from vehicle, as well as any contents in cargo area or other accessories that may be present (tonneau cover).
Step 3: Remove driver side courtesy lamp from cavity in LH side cargo panel. Remove connector from courtesy lamp.
Step 4: Using trim tool detach clips and remove OE cargo sill.
Step 5: Uncover and remove fastener located in D‐ring cavity in LH side cargo panel.
Step 6: Remove fastener located above the courtesy lamp on LH side cargo panel. Remove cover with trim tool to access the screw.
Step 7: Using the trim tool, disengage the clips securing the LH cargo panel to reveal courtesy lamp power connector.
Step 8: Lay illuminated Cargo Sill on cargo floor. Attach the female harness connector to vehicle power that was originally connected to the lamp.
Step 9: Wrap connector with foam tape.
Step 10: Reinsert the courtesy lamp into lamp cavity and attach the male connector.
Step 11: Secure the harness to the back side of the LH cargo panel using foam tape.
Step 12: Reattach LH cargo panel with (x2) attachment clips seated properly. Reinsert upper and lower fasteners (x2).
Step 13: Route harness as shown to avoid pinch by cargo panel.
Step 14: Attach Illuminated Cargo Sill to vehicle with (x4) mating clips by applying even pressure.
Step 15: Seal any pinched weather strip with trim tool or by hand.
Step 16: Reconnect vehicle battery. Replace all other cargo contents or accessories and reassemble the vehicle.
H61SXC300
Loading...
Reload document
Open in new tab
H61SXC300 (French)
Loading...
- 【High-Quality Materials】: Our car rear bumper protection strip is made of high quality PVC material, which is resistant to high temperature, friction and corrosion, and has good hardness and toughness. It can protect your car door panel from wear and tear, will not scratch the original car paint, even if it is frequently scraped, it will not be easily damaged.
- 【Anti-scratch/Waterpoor】: This product can effectively protect the car trunk door sill, it can prevent nasty scratches, wear and tear, and provide protection during the process of items, luggage up and down and in and out to keep the vehicle surface paint perfect. It is also waterproof, so you don't have to be afraid of getting wet when it rains, just wipe it off.
- 【Easy Installation】: Before installation, wipe the trunk door sill clean and make sure the surface is clean and dry. Tear off the adhesive backing film, grasp the location where it needs to be pasted, stick the protection strip flat on its surface and press it evenly for a few seconds to make sure it is tight. The installation process does not require much effort and can be easily completed in a few minutes.
- 【Widely Application】: This product is cut for the original version and is universally suitable for most cars, trucks, pickups or SUVs. After many tests and uses on real cars, our protection strips will never fail to fit in any way. We have 2 sizes for you to choose from, we suggest you measure the size of the installation location before you buy.
- 【Decorative】: This car door sill sticker is not only protective, but also decorative. It has two colors for you to choose, please choose the color that suits your car to make it more personalized and sporty fashion.
- The Guardian of Your Car's Rear Bumper: as a car rear bumper protector guard, this quality product is large and provides reliable protection for your vehicle; Measuring approximately 36 x 25 inches/ 92 x 64 cm, it offers comprehensive coverage for your trunk, protecting cargo from scratches and damages
- A Shield Built to Last: crafted from quality oxford cloth, this rear bumper protector is designed for endurance; It resists wear and tear, promising a long lasting service, offering impressive longevity and keeping your car in showroom condition for longer
- Universal Design for Ideal Convenience: the car bumper protector is not just about protection, but also versatility; It fits a wide range of vehicles, prevent the rear bumper from scratch and damage when transporting or placing heavy objects and boxes in the trunk, keeping your trunk clean and organized
- Enhanced Protection Effect: this bumper protector doesn't only cover, it ensures enhanced protection effect; Designed to shield your vehicle's surface from dirt, scratches, and other potential damages; The large size means larger area can disperse and absorb more impacts, thus better protecting your trunk from being bumped or scratched in daily use
- Effortless Installation and Storage: installing this car bumper protector guard is a breeze with 2 added straps and buckles can be easily fixed in car trunk; There is nylon fastener tape on the head, which makes it easy to fold the guard for storage, and you can pull it off when needed and fold it up when not in use for convenient storage
- 【Great Material】: These trunk door sills are made of high-quality environmentally friendly carbon fiber grain material, beautiful and generous, wear-resistant and anti-scratch, can effectively reduce the external impact, anti-scratch and anti-scratch, resilient, anti-aging, anti-UV, carbon fiber grain protection sticker can enhance the class of your favorite car.
- 【Adequate Protection】: These carbon fiber pattern protection stickers can provide you with maximum effective protection, and protect your car from scratches, reduce the trunk guard is scraped and scratched because of heavy lifting and other activities, no longer have to worry about unintentionally causing harm to your favorite car repeatedly.
- 【Multi-Function】: These trunk door sill guards are multi-functional, they are decorative, scratch and impact resistant. Carbon fiber car door sill stickers provide protection from severe scratches while also helping you cover existing scratches, prevent car wear and tear, paint scratches, paint damage and other conditions.
- 【Easy to Install & Remove】: These carbon fiber grain car door sill protection strips are very easy to install and remove, easy to install, the protection strips are tough and can be freely deformed and cut freely, you can cut and splice them according to your needs, then just stick them on where you want to install them, they don't hurt the car paint.
- 【Wide Compatible】: These universal carbon fiber grain trunk door sill protectors come in two sizes, the short one measures 35.4 x 2.95 inches and the long one measures 40.9 x 3.35 inches, they are universally applicable to most trucks, pickups or SUVs, you just need to find the corresponding size to buy according to your needs.
- Perfect Fitment: Based on the original car design, 1:1 ratio of production. Rear trunk mat compatible with 2019 2020 2021 2022 2023 2024 Subaru Forester. Please check your car model before purchasing.
- Premium Materials: Made of high quality TPE material. TPE cargo mats without any bad smell, can be bent and folded, with strong elasticity and flexibility.
- Abundant functionality: Cargo liner enhance appearance, protect your trunk 24/7. Keep your car clean, protect your trunk away from scratches and stain.
- Easy Installation: Very easy to install and remove. Install the trunk liner directly in the trunk without any other tools or cutting. When you want to clean, take it out and rinse it with water or towel.
- Warranty: If you have any questions with the rear trunk mat replacement for your Subaru Forester 2019 2020 2021 2022 2023 2024, please contact us immediately and we will provide a satisfactory after-sales service.
- 【Designed for Subaru Forester】This cargo mat is only suitable for Subaru Forester 2019 2020 2021 2022 2023 2024, designed according to the original car trunk size,100% fits your car and does not need to trim. (Not fit with subwoofer on trunk side wall)
- 【Eco-Friendly and Non-Toxic】This trunk liner is made of high-quality TPO material, non-toxic and odorless. Let you and your family stay healthy inside the car.
- 【Scratch Resistance】Strong flexibility of the trunk floor mat, folding is not easy to break, waterproof and resistant to dirt. The raised sides provide extra protection, features grid pattern for a non-slip surface surrounded by a high ridge & edges. with the protection of the trunk cushion,you do not have to worry about about the luggage scratching the car trunk.
- 【Easy to Clean Up】There is water retaining design at the edge of the cargo carpet, which effectively prevents sewage from flowing into the car.No worrying about muddy shoes or food making your car dirty! Waterproof mats can be rinsed with water directly, which is easier to take care of.
- 【Easy Installation】Take the cargo floor mat out of the package and dropped it into the back of your car- Done. It was literally that simple.
- Optimal Solution: Our small 3 Pockets Envelope Style cargo net is a must-have accessory for your car! Easy to install and practical, this accessory is key to preventing any load from moving in the trunk for a safer and more comfortable drive.
- Easy to Install: The car storage rear trunk organizer is designed for individual car models. The net is very easy and quick to install, as well as secure and durable. Because it is designed for individual car models, no additional devices or new holes are needed for installation.
- Made to Last: The mesh net is made entirely out of nylon, a heavy-duty material that is sturdy, resilient, and very long-lasting. The trunk net is lightweight and easy to put away when not used.
- Compatibility: This trunk net organizer for SUBARU OUTBACK 2000-2023 is designed specifically for each car model.
- Keeping Your Car Organized: The car cargo organizer comes with 3 locks for fixing the mesh on top so that objects from the mesh cannot fall out. It stops your groceries, sports equipment, or other accessories from moving in the trunk.
- This Dog Trunk Cover for SUV Helps Prevent Dogs from Slipping While Entering or Exiting Vehicle.
- Trunk Matt Protects Vehicle from Dirt and Scratches.
- Cargo Mat for back of SUV with clips can securely attaches to Cargo Area Tie Down Hooks.
- Foldable Tailgate Pad Can Easily Deployed & Stored While Secured in Place.
- Lightweight and wearable, Easily to use and folding.Unfold size: 30*24.5" PLEASE CHECK SIZE WHEN ORDER
- Custom Fit: Compatible for 2019-2024 Subaru Forester. Does not fit vehicles with vinyl flooring. Made by unique precision digital laser scanning to protect the Rear of your vehicle's. Completely and accurately lines the interior carpet.
- All Weather Guard: The TPE tri-extruded composition ensures 100% safe, 100% odorless and environmentally friendly in all weather (rain, fog, snow, etc.). OEDRO floor liners are compatible with the 2019-2024 Subaru Forester. [Remember to double check the correct car models] They provide an excellent rugged and durable grip. Absolutely no slipping.
- Tough & Durable: 300% better temperature resistance than PVC. The mats are non-toxic, odorless, contain no latex, cadmium, lead or any harmful PVC’s. The high tensity TPE material not only feels nice and is extremely wear-resistant, but also remains flexible in extreme cold weather.
- Easy To Clean: Wipes down easily. OEDRO floor liners are compatible with the 2019-2024 Subaru Forester. They are easy to clean, won't shed, and won't accumulate stains or build up. Quick and easy to get your car's carpets looking nice and new again! High-density core materials trap liquid, milk, snow, dirt, sand etc. and keep your car and shoes clean.
- Package Contents: Available in a set with 1 cargo liner.
- [High quality material]: This rear bumper protector is made of high-quality rubber, with strong scratch resistance, wear resistance, aging resistance, waterproof and other characteristics, and long service life.
- [Multi function]: The rear bumper protection device can not only be used to prevent scratches when loading and unloading luggage, toolboxes, and groceries, but also can be used to cover existing scratches, paint damage, etc. to keep the appearance of your car clean.
- [Wide compatibility]: This rear bumper protector (35*2.76 inch) is suitable for 98% of cars. Please measure the size of the installation position before buying to ensure that this protector is suitable for your car.
- [Anti slip design]: The bumper guard Anti slip design, groove design and anti slip function of this bumper prevent objects from falling when placing.
- [Easy to install]: The scratch resistant rubber bumper is very durable and flexible,and the package includes a strip of adhesive tape, without drilling or welding, First, clean the surface to ensure that there is no oil, water or dirt. Remove tape from the back, stick and press the rear bumper protector.
Last update on 2024-06-04 / Affiliate links / Images from Amazon Product Advertising API
This product presentation was made with AAWP plugin.
SEOCONTENT-START
KIT CONTENTS:
PART NUMBER: H461SXC300
TOOLS REQUIRED:
INSTALLATION INSTRUCTIONS DESCRIPTION: Ascent Illuminated Cargo Sill
PART NUMBER:
H461SXC300
ISSUE
00 9/5/2023 SUBARU OF AMERICA PAGE 1 / 5
Drive Ratchet
Pry Tool Trim Panel Removal Tool
10mm Socket
Screwdriver
Cargo Sill
Wire Harness
Foam Tape
1
PART NUMBER: H461SXC300
STEP 1: Prepare for the Installation.
(a) Inspect all kit components and check for
damage or missing parts.
(b) Remove the negative battery terminal.
CAUTION: Do not touch the positive terminal with any
part of the tool when removing the cable.
STEP 2: Disassemble the Vehicle.
(a). Remove cargo floor panel from vehicle, as well as any
contents in cargo area or other accessories that may be
present (tonneau cover).
Step 3: Remove driver side courtesy lamp from cavity in LH
side cargo panel. Remove connector from courtesy lamp.
Step 4: Using trim tool detach clips and remove OE cargo sill.
PART NUMBER:
H461SXC300
ISSUE
00 9/5/2023 SUBARU OF AMERICA PAGE 2 /5
2
PART NUMBER: H461SXC300
Step 5: Uncover and remove fastener located in D‐ring
cavity in LH side cargo panel.
Step 6: Remove fastener located above the courtesy lamp on LH
side cargo panel. Remove cover with trim tool to access the screw.
Step 7: Using the trim tool, disengage the clips securing the
LH cargo panel to reveal courtesy lamp power connector.
Step 8: Lay illuminated Cargo Sill on cargo floor. Attach the female
harness connector to vehicle power that was originally connected
to the lamp.
PART NUMBER:
H461SXC300
ISSUE
00 9/5/2023 SUBARU OF AMERICA PAGE 3 / 5
3
PART NUMBER: H461SXC300
PART NUMBER:
H461SXC300
ISSUE
00 9/5/2023 SUBARU OF AMERICA PAGE 4 / 5
Step 9: Wrap connector with foam tape. Step 10: Reinsert the courtesy lamp into lamp cavity and attach the
male connector.
Step 11: Secure the harness to the back side of the LH cargo
panel using foam tape.
Step 12: Reattach LH cargo panel with (x2) attachment clips seated
properly. Reinsert upper and lower fasteners (x2).
4
PAGE 5/5
PART NUMBER: H461SXC300
PART NUMBER:
H461SXC300
ISSUE
00 9/5/2023 SUBARU OF AMERICA
Step 13: Route harness as shown to avoid pinch by cargo
panel.
Step 14: Attach Illuminated Cargo Sill to vehicle with (x4) mating
clips by applying even pressure.
Step 15: Seal any pinched weather strip with trim tool or by
hand.
Step 16: Reconnect vehicle battery. Replace all other cargo contents
or accessories and reassemble the vehicle.
5
**************************************************************************************************************
NUMÉRO DE PIÈCE :
H461SXC300
VERSION
00 8/10/2023 SUBARU OF AMERICA PAGE 1 de 5
CONTENU DE LA TROUSSE :
NUMÉRO DE PIÈCE : H461SXC300
OUTILS REQUIS :
INSTRUCTIONS D’INSTALLATION DESCRIPTION : Seuil illuminé de l’espace utilitaire
Clé à cliquet
Outil de levier Outil pour garniture
Douille de 10 mm
Tournevis
Seuil de l’espace de
chargement
Faisceau de câblage
Ruban mousse
1
Étape 3 : Retirez la lampe d’accueil située dans la cavité du
panneau du côté gauche de l’espace utilitaire. Retirez le
connecteur de la lampe d’accueil.
Étape 4 : À l’aide de l’outil pour garniture, détachez les attaches et
retirez le seuil d’espace utilitaire d’origine.
NUMÉRO DE PIÈCE :
H461SXC300
VERSION
00 8/10/2023 SUBARU OF AMERICA PAGE 2 de 5
NUMÉRO DE PIÈCE : H461SXC300
ÉTAPE 1 : Préparez‐vous à l’installation.
(a) Inspectez tous les composants de la trousse et vérifiez
si
des pièces sont endommagées ou manquantes.
(b) Débranchez la borne négative de la batterie.
MISE EN GARDE : Ne touchez pas la borne
positive avec une partie quelconque de l’outil lors
du retrait du câble.
ÉTAPE 2 : Démontez le véhicule.
(a). Retirez le panneau de plancher de l’espace de chargement du
véhicule, ainsi que tout autre
contenu dans l’espace utilitaire ou tout autre accessoire qui
pourrait
s’y trouver (couvre‐caisse).
2
Étape 7 : À l’aide de l’outil de garniture, dégagez les
attaches fixant le panneau du côté gauche de l’espace
utilitaire pour révéler le connecteur d’alimentation de la
lampe d’accueil.
Étape 8 : Posez le seuil illuminé de l’espace utilitaire sur le plancher
de l’espace utilitaire. Branchez le connecteur femelle du faisceau à
l’alimentation du véhicule qui était initialement connectée à la
lampe.
NUMÉRO DE PIÈCE :
H461SXC300
VERSION
00 8/10/2023 SUBARU OF AMERICA PAGE 3 de 5
NUMÉRO DE PIÈCE : H461SXC300
Étape 5 : Découvrez et retirez la fixation située dans la
cavité de l’anneau en D du panneau du côté gauche de
l’espace utilitaire.
Étape 6 : Retirez la fixation située au‐dessus de la lampe d’accueil
du panneau du côté gauche de l’espace utilitaire. À l’aide de l’outil
pour garniture, retirez le couvercle pour accéder à la vis.
3
NUMÉRO DE PIÈCE : H461SXC300
NUMÉRO DE PIÈCE :
H461SXC300
VERSION
00 8/10/2023 SUBARU OF AMERICA PAGE 4 de 5
Étape 9 : Enroulez le connecteur avec du ruban mousse. Étape 10 : Réinsérez la lampe d’accueil dans sa cavité et branchez
le connecteur mâle.
Étape 11 : Fixez le faisceau à l’arrière du panneau du côté gauche
de l’espace utilitaire à l’aide de ruban mousse.
Étape 12 : Rattachez le panneau du côté gauche de l’espace
utilitaire à l’aide des (x2) attaches de fixation. Réinsérez les
fixations du haut et du bas (x2).
4
PAGE 5 de 5
NUMÉRO DE PIÈCE : H461SXC300
NUMÉRO DE PIÈCE :
H461SXC300
VERSION
00 8/10/2023 SUBARU OF AMERICA
Étape 13 : Acheminez le faisceau comme illustré pour éviter
le pincement par le panneau de l’espace utilitaire.
Étape 14 : Fixez le seuil illuminé de l’espace utilitaire au véhicule à
l’aide des attaches (x4) en appliquant une pression uniforme.
Étape 15 : Scellez tout bourrelet d’étanchéité pincé à l’aide
de l’outil pour garniture ou à la main.
Étape 16 : Rebranchez la batterie du véhicule. Replacez tout autre
contenu ou accessoire de l’espace utilitaire et remontez le véhicule.
**************************************************************************************************************
