Accessory Installation Guide
| 2019-22MY Ascent – Cargo Area Lighting Harness – Service and Installation Kit | H461SXC211 |
INSTALLATION INSTRUCTIONS
PART NUMBER: H461SXC211
DESCRIPTION: Cargo Area Lighting Harness – Service and Installation Kit
*Requires Cargo Area Lighting Kit P/N: H461SXC200 to complete installation
