Accessory Installation Guide
| Subaru Battery Tie Down
2020 WRX/WRX STI (all models) | SOA3881270 |
SEOCONTENT-START
A
BATTERY TIE DOWN X 1
B
TOOLS REQUIRED
INSTRUCTIONS LABELS X1
10mm DEEP SOCKET
MEANING OF CHARACTERS
INSTALLATION INSTRUCTIONS
PART NUMBER SOA3881270
ISSUE 01
DATE 02/08/19
PAGE 1/2
PART NUMBER: SOA3881270
DESCRIPTION: SUBARU BATTERY TIE DOWN
SUBARU OF AMERICA
RE-USE 10mm RE-USE
10mm RE-USE RE-USE
SUBARU OF AMERICA
2: REMOVE NUTS
PAGE
2/2
PART NUMBER
SOA3881270
ISSUE
01
DATE
02/08/19
ALL MODELS
4: INSTALL SUBARU BATTERY TIE
DOWN
ALL MODELS
ALL MODELS
3: REMOVE BATTERY TIE DOWN
6: REINSTALL CABLE TIE CLIP
REMOVED IN 1
5: REINSTALL NUTS REMOVED IN 2.
TIGHTENING TORQUE: 3.5 NM
(0.4 KGF-M, 2.6 FT-LB)
ALL MODELS
1: REMOVE CABLE TIE CLIP
INSTALLATION INSTRUCTIONS
ALL MODELS ALL MODELS
A
ATTACHE DE BATTERIE X 1
B
OUTILS REQUIS
ÉTIQUETTES D’INSTRUCTIONS X1
DOUILLE LONGUE DE 10 MM
NUMÉRO DE PIÈCE : SOA3881270
INSTRUCTIONS D’INSTALLATION
DESCRIPTION : ATTACHE DE BATTERIE SUBARU
SIGNIFICATION DES SYMBOLES
NUMÉRO DE PIÈCE SOA3881270
VERSION 01
DATE : 8 février 2019
SUBARU OF AMERICA
PAGE 1 de 2
Retirer
Retirer
Installer
Installer
Déconnecter
Déconnecter
Connecter
Connecter
Emplacement de l’attache
Emplacement de l’attache ou de la visou de la vis
Couple de
Couple de serrageserrage
Desserrer
Desserrer
Jeter
Jeter
Réutiliser
Réutiliser
RÉUTILISER 10 mm RÉUTILISER
10 mm RÉUTILISER RÉUTILISER
INSTRUCTIONS D’INSTALLATION
TOUS LES
MODÈLES
TOUS LES
MODÈLES
1. RETIRER L’ATTACHE-CÂBLE 2. RETIRER LES ÉCROUS
6. REMETTRE EN PLACE L’ATTACHECÂBLE
RETIRÉ À L’ÉTAPE 1
TOUS LES
MODÈLES
TOUS LES
MODÈLES
3. RETIRER L’ATTACHE DE
BATTERIE
4. INSTALLER L’ATTACHE DE
BATTERIE SUBARU
NUMÉRO DE PIÈCE
SOA3881270
VERSION
01
DATE :
8 février 2019 SUBARU OF AMERICA PAGE
2 de 2
TOUS LES
MODÈLES
TOUS LES
MODÈLES
5. REMETTRE EN PLACE LES ÉCROUS
RETIRÉS À L’ÉTAPE 2. COUPLE DE
SERRAGE : 3,5 N.M (0,4 KGF-M, 2,6 LB-PI)
