Δ0 １ STI FRONT UNDER SPOILER INSTALLATION MANUAL Genuine part number: E2410CC000 Applicable model: BRZ (ZD), Type A and later models Sold by: SUBARU CORPORATION Precautions 1. Be sure to observe the content in CAUTION for installation described in the main text during the work. Neglecting it may cause dropping of or peeling-off on the part, and also may prevent the vehicle from functioning. 2. Before the installation, turn the ignition switch to OFF, and apply the parking brake without fail. 3. Do not use thinner or the like, otherwise the surface of the STI front under spoiler may be corroded. Also, keep the spoiler away from fire, otherwise it may be deformed. 4. When the ambient temperature is 15°C or lower, warm up all strips of the double-sided tape and around the installation portion of the STI front under spoiler to approximately 25 to 40°C using a dryer or infrared lamp. Local warming may deform the part. Do not use an industrial dryer. 5. Firmly press the double-sided tape to adhere well. If it is reattached, the adhesive performance will extremely decrease. To avoid redoing, position the tape correctly before attachment. 6. The adhesive strength of the double-sided tape increases gradually after the attachment. Do not wash the vehicle within 24 hours after attaching the part. When washing the vehicle or applying wax to the vehicle is required on the day when the part is attached, leave the vehicle for at least 1 hour, and seal the double-sided tape attached portions with tape or the like to prevent water intrusion. In addition, be careful not to apply an excessive force to the front under spoiler. (Do not perform a high-pressure or automatic car wash on the day when the part is installed.) 7. When performing an air blow after the installation of the part, keep the nozzle 300 mm or more away from the part. If it is too close, the surface of the part may be peeled off. 8. Perform degreasing so as not to allow any solvent to accumulate in a gap of a component. A liquid pool may adversely affect the coated surfaces, rubber materials, and the like. Use a soft cloth to absorb the solvent and wipe the necessary portion. Then, wipe off completely with a dry cloth. Tools to be used Clip remover, Drill bits (3 mm, 6 mm, 9.5 mm, 10 mm), Hole saw (18 mm), Torque wrench, Phillips screwdriver, Flathead screwdriver, Ratchet wrench (8 mm), Awl, Gloves, Waste cloth Degreaser (Recommended: Nonane), Masking tape, Sandpaper, Safety goggles, Fabric adhesive tape This manual describes how to install and handle the STI front under spoiler. Before installing the part, please be sure to read this manual for proper installation. ○○○○○ Small bag Template No. 10 10 Components Part name Qty. Front under spoiler Hexagon-head bolt Well nut Clip A (ø10) Clip B (ø8) Cushion Template (LH and RH as a set) Instruction Manual ３ ⑦ Completion image *NOTICE – Before the work, clean the lower and side surfaces of the front bumper. – Perform the work in a room at a temperature of or higher. (When the temperature is lower than , the double-sided tape will not adhere sufficiently.) Fig. 2 Mating positions Template LH Front bumper Align to the centers of the crossed scribe lines on the bumper. Installation procedure 1. Preparation for installation (3) Align the template ⑦ to the centers of the crossed scribe lines on the front bumper as shown in the figure on the left. (Fig. 2) (1 location on each side, 2 locations in total) ① Front under spoiler Masking tape ① Front under spoiler Fig. 1 15°C 15°C (1) To prevent scratches during installation, apply pieces of masking tape to the rear end of the front under spoiler. (1 location on each side, 2 locations in total) (2) Referring to the service manual, remove the front bumper from the vehicle. To prevent scratches, cover each side of the bumper. ４ 3mm→6mm ａ ａ ａ ａ 3mm→6mm Fig. 4 Front bumper Front bumper Front bumper Front bumper Drill Drill Drill *For portion “a”, make a hole that goes through the bumper guard and front bumper at the same time Bumper guard Bumper guard *Remove it. *Remove it from the vehicle. Hole saw 18 mm Hole saw 18 mm Fig. 5 (6) Apply a drill to each center of the positions marked in the figure on the left to make holes in the order of 3 mm and 6 mm. (Fig. 4) (3 mm and 6 mm: 6 locations each on RH and LH, 12 locations in total) (18 mm: 4 locations each on RH and LH, 8 locations in total) CAUTION CAUTION CAUTION Use the drill bits with the correct diameter when making holes. Before the work, make a stopper with fabric adhesive tape to a position approximately 5 mm away from the tip of the drill bit to prevent interference caused by the drill bit. Drill bit Fabric adhesive tape ａ ａ ａ ａ Fig. 3 Scribe line on bumper (Size: 5 mm) Marking position Front bumper Awl (5) Remove the template ⑦. (4) Mark crossed scribe lines with an awl at the marking positions on the template ⑦ and at the positions on the front bumper shown in the figure. (Fig. 3) (6 location on each side, 12 locations in total) * These scribe lines will not be used. When making holes, wear safety goggles. (7) Referring to the service manual, remove the lower energy absorber, front intake cover, and front bumper guard from the front bumper, and apply a hole saw (18 mm) to each center of the positions marked in the Fig. 3 to make holes. (Fig. 5) (8) Remove burrs completely using sandpaper or the like. After that, reinstall the front bumper guard, front intake cover, and lower energy absorber to the front bumper. ③ ５ Front bumper Front bumper Front bumper Front bumper CAUTION CAUTION Fig. 7 Vehicle clip (not reuse) Vehicle clip (reuse) Back side view of wheel house Fig. 8 Well nuts Fig. 9 Degreaser (Recommended: Waste cloth Nonane) Surface to be degreased and cleaned (12) As shown in the figure on the left, remove the vehicle clips on the front bumper lower surface and front bumper wheel house flange. (Fig. 7) (2 locations each on RH and LH, 4 locations in total) (13) Insert well nuts③to the holes (9.5 mm holes) made in Fig. 5. (Fig. 8) (5 locations each on RH and LH, 10 locations in total) 2. Spoiler installation work (1) Degrease the double-sided tape attached portion on the front under spoiler ① of the front bumper with a waste cloth soaked in a degreaser (recommended: Nonane) as shown in the figure. (Fig. 9) (1 location each on RH and LH, 2 locations in total) Do not use the vehicle clips removed from the lower surface. The vehicle clips removed from the wheel house flange will be reused. Surface to be degreased and cleaned 9.5mm 9.5mm 10mm Front bumper Drill Drill Drill Drill Fig. 6 (9) Apply a drill to each center of the positions marked in the figure to make holes in the order of 9.5 mm and 10 mm. (Fig. 6) (9.5 mm: 5 locations each on RH and LH, 10 locations in total) (10 mm: 1 location each on RH and LH, 2 locations in total) CAUTION CAUTION Use the drill bits with the correct diameter when making holes. Before the work, make a stopper with fabric adhesive tape to a position approximately 5 mm away from the tip of the drill bit to prevent interference caused by the drill bit. Fabric adhesive tape (10) Remove burrs around the holes completely using sandpaper or the like. (11) Referring to the service manual, reinstall the front bumper to the vehicle. ６ ① ② ① ⑤ ② ④ ① Front bumper Front bumper Front bumper Front bumper Front bumper Fig. 11 Fig. 13 Clip A Front under spoiler Bolts Clip B Front under spoiler Front under spoiler *Check that no gap is made in this area. Peeling direction of backing paper Front under spoiler Front under spoiler Portions marked with ▼: Be careful not to catch the molding. Sectional view Sectional view Accepted Not caught Not accepted Caught Opening (3) Fix the front under spoiler ① to the front bumper lower surface with the clip A ④ and clip B ⑤ first and then temporarily fix with bolts ②. (Fig. 11) (Bolt ②: 5 locations each on RH and LH, 10 locations in total) (Clip A ④: 1 location each on RH and LH, 2 locations in total) (Clip B ⑤: 1 location each on RH and LH, 2 locations in total) (5) Fix the front under spoiler ① to the front bumper wheel house flange with the vehicle clip removed in Fig. 7. (Fig. 12) Put your hand to the back side of the front bumper and firmly press the tape positions from both the front and back sides. *Put your hand into the duct and firmly press on the back side of the bumper. Firmly press Firmly press Front bumper ① Front under spoiler Vehicle clip Fig. 12 ① ① *NOTICE – Be sure to degrease and clean the attachment surface. – Perform the work in a room at an ambient temperature of 15°C or higher. – When the temperature is lower than 15°C, warm up the attachment surface and double-sided tape with a heating device or the like. (25 to 5℃ as a guide) – If air enters between the tape and the attachment surface, the adhesive strength will become weak. Be sure to firmly press with a force of 49 N or more. Fig. 10 Masking tape Masking tape Backing paper Front under spoiler Backing paper (2) Peel off some portions of the backing paper from the double-sided tape attached on the front under spoiler ① by approximately 20 mm each as shown in the masking tape to each of them. (Fig. 10) (2 locations each on RH and LH, 4 locations in total) Double-sided tape attachment standard Masking tape Backing paper Front under spoiler Fold the backing paper back to the design surface of the part, and apply a piece of masking tape to it. (4) Peel off the masking tape applied to the rear end of the front under spoiler ①. Pay sufficient attention not to make scratches. (1 location each on RH and LH, 2 locations in total) (6) While paying attention not to allow the molding of the front under spoiler ① to be caught in the bumper, peel off the backing paper of the double-sided tape inward from the vehicle outer side (in the order of ① → ② in the figure on the left). Then, firmly press the entire tape area with a force of 49 N or more. (Fig. 13) figure on the left, fold them back, and apply a piece of Fr UP Front bumper Front bumper Front bumper Fig. 15 Fig. 16 Front under spoiler Front under spoiler Front under spoiler Degreaser Surface to be degreased and cleaned (Recommended: Nonane) Cushion attachment portion Surface to be degreased and cleaned Attachment direction Aligning edge of Reference for contact with BRKT of Cushion Cushion (8) Degrease the cushion ⑥ attached portion of the front bumper lower surface with a waste cloth soaked in a degreaser (recommended: Nonane) as shown in the figure on the left. (Fig. 15) (1 location each for RH and LH, 2 locations in total) (9) Attach the cushion ⑥ to the front bumper along the edge of the front under spoiler [1] as shown in the figure on the left. (Fig. 16) Sectional view of cushion attached portion Attach the cushion along the edge of ① Front bumper Fig. 14 Front under spoiler Final tightening (7) Finally tighten the bolts ② temporarily fixed in step (3). (Fig. 14) Tightening torque for reference: 1.0 N·m (0.1 kgf·m) (5 locations each for RH and LH, 10 locations in total) ① Front under spoiler Front bumper *How to correct when the molding is caught Sectional view Use a finger to catch the caught molding to correct it. – When the molding is caught, correct the position while paying attention not to scratch the bumper or peel off the double-sided tape. – The molding can be returned to the correct position by catching the caught molding with finger. Revision history Content Date Newly created April 14, 2021 Fig. 17 ① Front under spoiler Front bumper The installation work has been completed. ８ * Check for any light leaking out in this area. (10) Finally check for lifting or tilting of the installation portion, missing of any clip and bolt, and the like. If any, correct it as necessary. Also, check the operation of the side turn signal lamps of the vehicle. (11) Check that no light is leaking out from the contact surface between the front under spoiler ① and bumper. (12) Check that there is no scratch or dirt on the bumper and the surrounding area of the spoiler.

**************************************************************************************************************
