① STI Side Under Spoiler (LH) Spoiler assy-side – Install the STI Side Under Spoiler by reading the Installation Manual carefully. – Handle the STI Side Under Spoiler with care and do not let it fall. – Do not install or use this product in any way other than described in this manual. – We do not assume any responsibility for any trouble arising from failure to comply with the instructions in this manual. – Double-sided tape is used to attach the STI Side Under Spoiler. Attach it with care as once it is attached, it is extremely difficult to remove. -1- Genuine part number : E2610FN000/010 Applicable model : ＩＭＰＲＥＺＡ（ＧＵ）,ＴＹＰＥ Ａ～ STI Side Under Spoiler Installation Manual – This manual describes how to install and handle the STI Side Under Spoiler. – Read this manual carefully before work and make sure to install it correctly. ！ △ Precautions Installation Completion Illustration Δ00 ① ② ③ ④ ⑥ ⑤ ！ 注意 ・プリントした場合、縮尺が１／１でない可能性があります。 ・縮尺が１／１になるようにコピーしてからご使用ください 型紙 型紙はライン外側で切り取ってください。 SIDE UNDER SPOILER φ6.0 ＬＨ SPOILER R END ＲＨ SPOILER R END SIDE UNDER SPOILER φ6.0 ● Masking tape ● Drill 3mm 5mm 7mm 9.5mm ● Needle ● Clean cloth ● Dryer ● Degreasing agent (recommended nonane) ● Sandpaper ● Phillips screwdriver ● Socket 8mm ● Needle nose pliers ● Gloves ● Protective eyewear ● Torque wrench ● cloth adhesive tape Components Tools -2- Before Work ① ② RH:1 /LH:1 No. Part Name Qty STI Side Under Spoiler 18 – Make sure to check the components below before installation. – When installing this product, park the car on a level ground and apply the parking brake. – When installing this product, be sure not to damage the car body. – Before installing this product, wipe off any dirt or oil film from the Side Spoiler attachment surface with a soft waste cloth dampened in a neutral detergent.Then, let it dry completely before work. – The adhesive strength is weakened significantly when the temperature is low. In this case, use a dryer to warm up the double-sided tape before attachment. (Do not warm excessively as doing so may result in deformation.) – Be extremely careful not to let this product get wet by washing, etc. for 24 hours after attaching it. Dosing so may cause the product to come off. – To protect yourself from burns, make sure to stop the engine and let it cool completely before work. – When jacking up the vehicle, be sure to keep the ground level and a hard place where the jack does not bite, and be sure to support it with a rigid rack before carrying out the work. ③ ④ ⑤ Pattern paper LH/RH (P8) 18 Clip (Large) 2 1 Wellnut Bolt – E2610FN112/122 : STI Side Under Spoiler RH ①RH×1 E2610FN113/123 : STI Side Under Spoiler LH ①LH×1 E2610FN111 : Parts set ②×18 ③×18 ④×2 ⑤×2 ⑥ Clip (Small) 2 Caution Advice When jacking up the vehicle, be sure to place it on a hard surface where the ground is horizontal and the jack does not bite into it, and be sure to support it with a rigid rack before performing the work. To prevent the STI Side Under Spoiler from being deformed or damaged, please observe the following when using a two-pillar lift. ！ ！ -3- ① Set the car slope on the vehicle and secure the ground clearance. ② Adjust the screw height of the dish parts and set it so that the lift arm does not interfere with the STI Side Under Spoiler. ③ Set so that the lift arm does not overlap with the drilling position. Lift arm STI Side Under Spoiler Spoiler assy-side Interference Caution Sectional view Side panel Adjust screw height Make it 10 mm Dish parts or more -4- a LH 3mm → 7mm Ft Up RH Ft Up 1. Removal of Spoiler assy-side ( The RH also performs the same work. ) 1 LH Spoiler assy-side (1) Refer to the service manual and remove the Spoiler assy-side from the vehicle. 2. Drill holes in the Spoiler assy-side 2 Spoiler assy-side LH Bottom view ！ Advice Drill cloth adhesive tape 5mm ！ Advice After drilling, remove the burrs around the hole. (2) Cover the 7mm hole with masking tape so that it is not mistaken for the 9.5mm hole Masking tape 7mm hole Installation procedure (1) As shown in Fig. 2, mark the center of the lower surface locator a on the rear end of the Spoiler assy-side with a marking needle or the like. After that, drill a 3mm pilot hole, then a 7mm hole. ＜ Detail view a ＞ Locator center (1 places each for LH and RH, 2 places in total) To prevent the drill from interfering with other parts when drilling, make a stopper with cloth adhesive tape, etc., at a point about 5 mm from the tip of the drill before working. a -5- LH Ft Up 3mm → 7mm→ 9.5mm LH Ft Up LH Ft Up 3mm → 5mm RH Ft Up ///////////////// ////////// ////////// //////////// //////////// //////////// /////// 3 4 5 6 Locator center Masking tape (3) As shown in Fig. 3, mark the center of the Spoiler assy-side lower surface locator with a marking needle or the like.After that, drill pilot holes in order of 3mm, 7mm, and finally drill a hole of 9.5mm. ！ Advice After drilling, remove the burrs around the hole. Masking tape ② Wellnut (4) Insert the ② Wellnut into the 9.5 mm hole. (5) Remove the masking tape. ！ Advice After drilling, remove the burrs around the hole. LH Spoiler assy-side Bottom view Clean with a waste cloth, etc. Clean with a waste cloth, etc. 3. Cleaninng/Degreasing Align with outer circumference R end Match the shape of the bumper If rainwater is attached, wipe it dry with a dry cloth. Insufficient wiping and drying can cause the product to come off. ！ Advice (1) Clean, degreas, and dry the shaded area of the Spoiler assy-side with a degreasing agent. (6) As shown in Fig. 5,Determine the position of the ⑥ pattern paper on the rear end of the Spoiler assy-side, fix it with masking tape, etc., and mark the center of the hole with a marking needle. After that, remove the template and make a 3mm pilot hole, then a 5mm hole. ＜ Detail view a ＞ ！ Advice If it is difficult to insert the wellnut, do not twist it too much and insert it carefully. b Marking position ＜ Detail view a ＞ Pattern paper LH (1 places each for LH and RH, 2 places in total) (9 places each for LH and RH, 18 places in total) (9 places each for LH and RH, 18 places in total) SIDE UNDER SPOILER φ5.0 ＬＨ SPOILER R END -6- LH Ft Up （1） （4） （3） （2） （5） （6） （7） （8） 4. Installation of STI Side Under Spoiler ！ Advice Do not remove the release paper more than necessary. The double-sided tape clings to the peripheral parts, which makes it difficult to position them. Peel from back to front. Masking tape Back side view 7 8 9 10 ！ Advice If it is difficult to remove the release paper, slowly pull it out with needle-nose pliers. Make sure that the molding does not turn over when pulling out the release paper. ③ Bolt ① STI Side Under Spoiler Spoiler assy-side Phillips screwdriver ③ Bolt Phillips screwdriver ① STI Side Under Spoiler Spoiler assy-side thin plate Push ※ How to fix when the mall is overturned. If you press the turned-up part with a thin board, it will return to its original state. (5) The double-sided tape adhesive part is crimped with enough force to bend the lower surface of the Spoiler assy-side. (49N or more) (1) Peel off the double sided tape release paper of the ① STI Side Under Spoiler by about 30 mm and fix it on the front side with masking tape. (2) As shown in Fig. 8,Apply the ① STI Side Under Spoiler to the spoiler assy-side, fix it with ④ Clip (large) and ⑤ Clip (small), and finally tighten the front end side with a Phillips screwdriver and ③ Bolt temporarily. (3) As shown in Fig. 9, use a Phillips screwdriver to temporarily tighten ③ Bolt in the remaining fastening holes of ① STI Side Under Spoiler. (4) As shown in Fig. 10, press the double-sided tape while slowly pulling out the release paper from (1) to (8) in the direction of the arrow so that it does not break in the middle. (8 places each for LH and RH, 16 places in total) LH Ft Up ④ Clip (Large) ⑤ Clip (Small) -7- 11 5. Restore the Spoiler assy-side (1) Refer to the service manual and restore the Spoiler assy-side to the vehicle. This is the end of the work. △ Newly created document Revised contents Details of the work Date 00 ・By installing this product, it is up to 18mm lower than the Spoiler assy-side. ・Because it is easy to come into contact with curbs, ring clasps, steps, etc. Be careful not to touch it while driving or parking. If it comes in contact with it, it may be scratched, deformed, damaged or dropped, and the spoiler may be damaged accordingly. ・In the case of slight contact, you may not notice the contact, so be sure to perform a pre-operation inspection and check the area around the mounting part in particular. ・Also, running in snow or ruts may damage the spoiler, deform it, drop it off, or damage the vehicle. Damage caused by these or equivalent external forces is not covered by the warranty. ・By installing this product, it is easier to get on and off than the standard Spoiler assy-side. If you get your feet caught, you may get injured. Also, it is scratched, deformed, damaged, dropped or dropped. Please be careful when getting on and off as it may cause damage to the vehicle. Explanation to customers ・We do not accept warranty repairs such as scratches, discoloration of paint, and peeling that occur during use. 12 Spoiler assy-side Reference tightening torque 1.0N・m ( 0.1kgf・m ) (6) Fully tighten ③ Bolt on the bottom surface of ① STI Side Under Spoiler with a torque wrench. ！ Advice normal state over torque ！ Advice (9 places each for LH and RH, 18 places in total) (7) Finally, check the float of the mounting part, make sure that there are no missing Clips or Bolts, or forget to tighten them, and visually check the condition of ② Wellnut from the back side. 6 / Dec / 2022 -8- Cut on the outside of the line. ⑥ Pattern paper ！ Advice ・If you print, there is a possibility of scale is not a 1/1. ・Use after copying so that the scale is 1/1. ＲＨ SPOILER SIDE UNDER SPOILER φ5.0 SIDE UNDER SPOILER φ5.0 ＬＨ SPOILER R END R END
