NHTSA ID Number: 10233445
Manufacturer Communication Number: 1213512R
Summary
If you have copies of 12-135-12R please discard and refer to 07-72-13 for the latest repair procedure.
NUMBER: 12-135-12R
DATE: 07/30/12
REVISED: 03/14/13
| APPLICABILITY: | 2011MY and Later Legacy and Outback |
| SUBJECT: | Sunroof Binding, Wedge Cap Adjustment Procedure Revisited |
NOTE: Service Bulletin 12-135-12R (Sunroof Binding, Wedge Cap Adjustment Procedure
Revisited) has been deleted from STIS and has been replaced with Service Bulletin 07-72-13 (Sunroof Does Not Open or Close Properly, Popping or Slamming Sound When Glass Lowers Prior To Opening).
If you have copies of 12-135-12R please discard and refer to 07-72-13 for the latest repair procedure.
26 Affected Products
Vehicles
1 Associated Document
Manufacturer Communications
NUMBER: 12-135-12R
DATE: 07/30/12
REVISED: 03/14/13
NHTSA ID Number: 10235831
Manufacturer Communication Number: 077213
Summary
Sunroof Does Not Open or Close Properly
1 Associated Document
Manufacturer Communications
NUMBER: 07-72-13
DATE: 01-29-13
MC-10235831-9999.pdf 790.452KB
