1. Be sure to observe the content in CAUTION for installation described in the main text during the work.
Neglecting it may cause dropping of or peeling-off on the part, and also may prevent the vehicle from functioning.
2. Before the installation, turn the ignition switch to OFF, and apply the parking brake without fail.
3. Do not use thinner or the like, otherwise the surface of the STI ROOF SPOILER may be corroded. Also, keep the spoiler away from fire, otherwise it may be deformed.
4. When the ambient temperature is 15°C or lower, warm up all strips of the double-sided tape and around the installation portion of the STI ROOF SPOILER to approximately 25 to 40°C using a dryer or infrared lamp.
Local warming may deform the part. Do not use an industrial dryer.
5. Firmly press the double-sided tape to adhere well.
If it is reattached, the adhesive performance will extremely decrease. To avoid redoing, position the tape correctly before attachment.
6. The adhesive strength of the double-sided tape increases gradually after the attachment. Do not wash the vehicle within 24 hours after attaching the part.
When washing the vehicle or applying wax to the vehicle is required on the day when the part is attached, leave the vehicle for at least 1 hour, and seal the double-sided tape attached portions with tape or the like to prevent water intrusion.
In addition, be careful not to apply an excessive force to the STI ROOF SPOILER.
(Do not perform a high-pressure or automatic car wash on the day when the part is installed.)
7. When performing an air blow after the installation of the part, keep the nozzle 300 mm or more away from the part. If it is too close, the surface of the part may be peeled off.
8. Perform degreasing so as not to allow any solvent to accumulate in a gap of a component. A liquid pool may adversely affect the coated surfaces, rubber materials, and the like. Use a soft waste cloth to absorb the solvent and wipe the necessary portion. Then, wipe off completely with a dry waste cloth.
9. When a body coating treatment (glass coating, etc.) is applied, the original adhesive strength cannot be exerted. Check if the body coating treatment is applied. Also, remove any dirt or fat and oil without fail, and apply a firm pressure sufficiently.
<>
• Using compound with fine particles (in order not to impair painting), scrub off the coating film in the application area.
• After grinding, spray water using a spray or the like. If the area is no longer water-repellent, the coating film is removed.
Applicable model: FORESTER (SL) TYPE A～
1
This manual describes how to install and handle the STI ROOF SPOILER.
Before installing the part, please be sure to read this manual for proper installation. Precautions
Tools to be used
Sold by: SUBARU CORPORATION
STI ROOF SPOILER
Genuine part number: E7210SL310, STI ROOF S LER
△00
INSTALLATION MANUAL
Clip remover, Gloves, Drill bits (3 mm, 6 mm, 8.5 mm, 9 mm), Sockets (8 mm, 10 mm), Extension ing-off pin, Torque wrench, Phillips screwdriver, Degreaser (Recommended:
Needle-nose pliers Components
No. Part name Qty. ① Roof spoiler 1
② Bolt 1
③ Washer (metal surface) 1
④ Collar 1
⑤ Tapping screw 2
⑥ Washer (black) 2
⑦ J nut 2
⑧ Template set (A, BR/L) 1 Repair part No.:
Parts set (E7210SL301) ：②×1 /③×1 /④×1 /⑤×2 /⑥×2 /⑦×2 ① CAUTION Check the quantity of each component first. If any component is missing or damaged, please contact your dealer. Small bag ② ③ ④ ⑤ ⑥ ⑦ ⑧ 2 Completion image *NOTICE
– Before the work, clean the upper surface of the vehicle roof spoiler.
– Perform the work in a room at a temperature of 15°C or higher.
(When the temperature is lower than 15°C, the double-sided tape will not adhere sufficiently.)
Installation procedure
1. Preparation for installation Fig. 1 LH RH
Dw (1) Fully open the rear gate to make the center part inside the back door visible, and remove the ground terminal from the battery sensor. (Fig. 1)
• Note that the back door can no longer be opened if it is closed after the ground terminal Rear gate Center part CAUTION is removed.
• The removed vehicle parts will be reused. Be careful not to damage or lose them. (2) While paying attention to the tabs, remove the center part of the rear gate.
(Tab: 4 locations in total)
(Fig. 1) Tabs (4 locations) CAUTION Be careful not to damage any tab when removing the vehicle parts.
Mounting the vehicle parts will be prevented if any tab is broken. Fig. 2 Enlarged Connector on Connector on LH RH
Dw (3) Wrap masking tape around the tips of the needle-nose pliers, pinch the harness connector of the rear gate high mount stop lamp, and squeeze view vehicle body side high mount stop lamp side the locking tab to unlock.
Connector on vehicle body side Connector on high mount stop lamp side Masking tape Needle-nose pliers (4) When the locking tab is unlocked, disconnect the connector. Rear gate CAUTION (Fig. 2)
• Be careful not to pinch excessively with needle-nose pliers, since separating the connector will be difficult.
• Be careful not to damage your hand with the edge of the sheet metal. 3 Fig. 3 LH RH
(5) Carefully disengage both side covers by pulling them Rear gate Dw towards you. Do not fully remove, only remove enough to expose the bolt head shown in Fig.4.
(Fig. 3) Side cover CAUTION • The removed vehicle parts will be reused. Be careful not to damage or lose them. Fig. 4 Rear gate Up
LH RH (6) Remove the bolts of the vehicle roof spoiler from the vehicle interior side with the ratchet wrench and socket (10 mm). (Bolt: 6 locations in total)
(Fig. 4)
• Be sufficiently careful not to drop any bolt Bolts (6 locations) CAUTION inside the rear gate.
• The removed vehicle parts will be reused. Be careful not to damage or lose them.
• To remove the bolt, use the extension (100 mm). Fig. 5 Up
Ft RH
LH Clips (3 locations) Vehicle roof spoiler (7) Fully engage and reinstall side covers from step (5). Failure to do this may result in side covers damage.
(8) Lower the rear gate, pull the vehicle roof spoiler diagonally upward (45°), and remove it from the rear gate by lifting from underside.
Remove any clip remaining on the rear gate side and reattach it to the vehicle roof spoiler. Rear gate Vehicle roof spoiler Rear gate Apply a force upward from the bottom. 45° CAUTION (Fig. 5)
• When opening and closing the rear gate, be careful not to pinch fingers.
• When removing the vehicle roof spoiler, do not apply a force from the top. Up
Ft
Fig. 6 Up Remove it by lifting from underside. (9) Remove the grommet of the high mount stop lamp Ft RH
LH Vehicle roof spoiler (hereafter referred to as HMSL) harness from the rear gate.
(Fig. 6) Rear gate CAUTION When removing the grommet, be careful not to damage the vehicle body in contact with the vehicle roof spoiler. Grommet 4 Fig. 6 Nuts (2 locations) RH LH
Rr Vehicle roof (10) Disconnect wiring from the vehicle roof spoiler guide, remove the nut of the HMSL with the ratchet wrench and socket (8 mm), and remove the HMSL from the vehicle roof spoiler.
(Nut: 2 locations in total)
(Fig. 6)
The removed vehicle parts will be reused. Be HMSL spoiler CAUTION careful not to damage or lose them. Fig. 7 RH LH
Enlarged view of vehicle roof spoiler Rr
center lower portion (11) Attach the template A⑧ to the HMSL attachment portions on the vehicle roof spoiler at the position shown in the figure on the left, aligning the shape of the ribs around it.
(Fig. 7) Align to the rib shape. ⑧Template A Vehicle roof spoiler Fig. 8 Enlarged view of vehicle roof spoiler both edge
Vehicle roof spoiler Align to edge. RH LH
Rr (12) Attach the template BL ⑧ to the end on the vehicle roof spoiler at the position shown in the figure on the left, aligning the shape of the end.
(1 location each on RH and LH, 2 locations in total)
(Fig. 8) Fig. 9 ⑧
Template BL Vehicle roof spoiler Align to edge.
⑧Template BL
Sectional view of attachment area
RH LH (13) Make a mark with a marking-off pin at the center of Enlarged view of vehicle roof spoiler Rr
center lower portion the piercing position on the templates A and BL⑧. (1 location each on RH, LH and center, 3 locations in total) Marking-off pin Making position Marking-off pin Making position ⑧Template A Vehicle roof spoiler
⑧Template BL (14) Remove the templates A and BL ⑧. (Fig. 9) Enlarged view of vehicle roof spoiler both edge
5 Fig. 10
Enlarged view of vehicle roof spoiler center lower portion RH LH
Rr (15) Apply a drill to the center of the position marked in the step (11) to make a hole. After making a prepared hole with a 3 mm drill bit and then 6 mm drill bit, make a hole with an 8.5 mm drill bit.
(8.5 mm on center, 1 locations in total)
(Fig. 10)
Before the work, make a stopper with fabric adhesive tape to a position approximately 10 mm away from the tip of the drill bit to prevent Drill bit 3mm→6mm→8.5mm Vehicle roof spoiler interference caused by the drill bit.
10mm Drill bit CAUTION Sectional view of tightening portion Up Fabric adhesive tape Drill Ft Vehicle roof spoiler Passing through Fig. 11 Enlarged view of roof spoiler both ends
Vehicle roof (16) Apply a drill to the center of the position marked in the step (11) to make a hole. After making a prepared hole with a 3 mm drill bit and 6 mm drill bit, RH LH
Rr spoiler make a hole with a 9 mm drill bit.
(9.0 mm, 1 location each on RH and LH, 2 locations in total) (Fig. 11)
(17) After making the hole, remove burrs around the hole. Drill bit
3mm→6mm→9mm
Fig. 12
Vehicle roof spoiler (18) Degrease the entire vehicle roof spoiler with a waste cloth soaked in a degreaser (recommended: Nonane). (Fig. 12) Up
Ft RH
LH Waste cloth Degreaser (Recommended: Nonane)
Surface to be degreased and cleaned Fig. 13 Rr
LH RH (19) Paste it with aligning the edge of the masking tape to the center of the center rib of the HMSL mounting part. Vehicle roof spoiler Masking tape Align to rib center. (Fig. 13) Sectional view
Masking tape To radius end 6 Fig. 14
Backing paper ①Roof spoiler
Backing paper RH LH
Rr
(20) Peel off each of the backing paper of the
double-sided tape on the back side of the roof spoiler
① approximately 30 to 50 mm from the end, bend it Backing paper Inside of Backing paper Backing paper A Backing paper outward, and attach it to the front side with masking tape.
Peel off all the short backing paper shown on the left detailed view of portion A. (Fig. 14) ((6 locations each on RH, LH, 1 location on center, 13 plate Outside Backing paper Backing paper Peeled off completely locations in total)
Do not remove the templates excessively. Otherwise, the double-sided tape sticks to the of plate Masking tape Backing paper Detailed view of Portion A CAUTION vehicle roof spoiler, making it difficult to hold the roof spoiler ① up to the correct position. Fig. 15
①Roof spoiler (21) Install the J nut ⑦ to the installation hole on the both ends of the roof spoiler ①.
(1 location each on RH and LH, 2 locations in total) Insert from the square hole. ⑦J nut (Fig. 15) ⑦J nut ①Roof spoiler
Sectional view of tightening portion
Be careful of the direction in which the J nut⑦ CAUTION
*NOTICE is installed. – Be sure to degrease and clean the attachment surface.
– Perform the work in a room at an ambient temperature of 15°C or higher.
– When the temperature is lower than 15°C, warm up the attachment surface and double-sided tape with a heating device or the like.
(Guide: 25°C to 40°C)
– If air enters between the tape and the attachment surface, the adhesive strength will become weak. Be sure to firmly press it.
– After attaching the tape, avoid washing the vehicle for at least 24 hours. Fig. 16 ①Roof spoiler 2. Roof spoiler installation work
(1) Place the roof spoiler ① on the vehicle roof spoiler.
(Fig. 16)
When placing the roof spoiler①, be careful not to damage the vehicle roof spoiler and Vehicle roof spoiler ④Collar
③Washer (metal surface) CAUTION roof spoiler ①.
This work is recommended to be performed with 2 workers. Vehicle roof spoiler Up ②Bolt
①Roof spoiler ④Collar
③Washer (metal surface)
②Bolt (2) Into the hole drilled on the HMSL installation portion of the vehicle roof spoiler in 1.(14), insert the bolt② with the washer (metal surface) ③ and collar ④
pre-assembled in this order, and temporally fix it to the bracket of the roof spoiler①.
(Bolt: 1 location in total)
(Fig. 16) Ft Sectional view of tightening portion
7 Fig. 17 Vehicle roof spoiler ⑥Washer (black) (3) Into the holes drilled on both ends of the vehicle roof spoiler in 1.(15), insert the tapping screw ⑤ with the washer (black) ⑥, temporarily fix it to the J nut ⑦ portion installed to the roof spoiler ①.
(1 location each on RH and LH, 2 locations in total)
(Fig. 17) ⑤Tapping screw
Up
Ft ①Roof spoiler ⑦J nut Vehicle roof spoiler
⑥Washer (black) ⑤Tapping screw Fig. 18 Sectional view of tightening portion Up (4) For positioning of the roof spoiler ① and press-fit of Rear gate Clips (3 locations) LH RH double-sided tape, reinstall the vehicle roof spoiler to the vehicle once.
(Clip: 3 locations in total)
(Fig. 18) Fig. 19 Align the end of the masking tape to the Up
LH RH (5) Position the roof spoiler ① so that its HMSL periphery will be equally distant to the left and right from the masking tape applied to the center of the vehicle roof paint parting line of “T” of the STI emblem for positioning. spoiler as reference. (Fig. 19) ①Roof spoiler Vehicle roof spoiler Masking tape 8 Fig. 20
Ft Up
LH RH Vehicle roof spoiler (6) Slowly pull off the backing paper of the double-sided tape outward from the center in the order of “a→ b” so that it will not break at midpoint. Firmly press the double-sided tape area to the vehicle roof spoiler.
(Fig. 20) Fig. 21 b a b
①Roof spoiler (7) Slowly pull off the backing paper of the double-sided Ft Up
RH Vehicle roof tape outward from the center in the order of “c→ e” so that it will not break at midpoint. Firmly press the LH e d spoiler c c d e double-sided tape area to the extent that vehicle body shakes slightly. (Fig. 21) Fig. 22 Ft ①Roof spoiler Up Vehicle roof spoiler (8) Slowly pull off the backing paper f of the double-sided tape so that it will not break at midpoint. Firmly press the double-sided tape area to the extent that vehicle body shakes slightly. LH RH
f
①Roof spoiler (Fig. 22)
(9) Peel off the masking tape attached to the vehicle roof spoiler.
(10) Remove the vehicle roof spoiler once.
(Clip: 3 locations in total) When removing the vehicle roof spoiler, be careful not to hold the roof spoiler① by hands. CAUTION This work is recommended to be performed with 2 workers. Fig. 23 Ft RH LH ①Roof spoiler (11) Finally tighten the bolt② and tapping screw ⑤ temporarily fixed in 2.(2) and (3). (3 locations)
② Bolt tightening torque 2.0 N·m (0.2 kgf·m)
⑤ Tapping screw tightening torque
2.0 N·m (0.2 kgf·m)
(Fig. 23) ②Bolt final tightening ⑤Tapping screw final tightening 9 10
Clips (3 locations)
Fig. 24
Up
LH RH
Vehicle bolts (6 locations) final tightening 00 Newly created
Content Date
December 06, 2023
3. Check after installation work or inspection
Revision history
(1) Open and close the rear gate to check that the lity (malfunction, abnormal noise, contact) during the open/close operation.
(2) Check for any looseness, inclination, coming-off of bolts and nuts, and others in the installed area, and make corrections if necessary.
Finally, check that there is no scratch, dirt, or the like. The installation work has been completed.
Be careful not to catch the harness of each part when restoring vehicle parts.
Incomplete installation of the vehicle roof spoiler may cause leakage. Make sure that the bolts are fully tightened.
Make sure the HMSL harness grommet is installed. CAUTION
(12) Referring to 1.(8), reinstall the HMSL to the vehicle roof spoiler.
• Vehicle nuts (2 locations) Tightening torque 5.0 N·m (0.5 kgf·m)
(13) Perform 1.(1) to (7) in reverse order to reinstall the vehicle roof spoiler.
• Clips (3 locations)
• Vehicle bolts (6 locations) Tightening torque 8.0 N·m (0.8 kgf·m)
(Fig. 24)
(14) Check that the HMSL lights up.

**************************************************************************************************************

**************************************************************************************************************
