April 15, 2021 NHTSA CAMPAIGN NUMBER: 21V264000

ECM Software May Cause Stall

A short circuit in the ignition coils may cause a stall, increasing the risk of a crash.



NHTSA Campaign Number: 21V264

Manufacturer Subaru of America, Inc.

Components ENGINE AND ENGINE COOLING, ELECTRICAL SYSTEM

Potential Number of Units Affected 466,205



Summary

Subaru of America, Inc. (Subaru) is recalling certain 2017-2019 Subaru Impreza and 2018-2019 Crosstrek vehicles. The Engine Control Module (ECM) may continue to power the ignition coil after the engine is shut off, causing a short circuit.



Remedy

Subaru will notify owners, and dealers will update the ECM software, replace the ignition coils and, if necessary, the front exhaust pipe, free of charge. Owner notification letters were mailed beginning June 1, 2021. Owners can contact Subaru customer service at 1-844-373-6614. Subaru’s number for this recall is WRE-21. Note: This recall includes all vehicles previously repaired under Recall 19V743.



Notes

Owners may also contact the National Highway Traffic Safety Administration Vehicle Safety Hotline at 1-888-327-4236 (TTY 1-800-424-9153), or go to www.safercar.gov.



Check if your Subaru has a Recall




NUMBER: WRE-21R
DATE: 04/23/21
NHTSA ID: 21V-264
REVISED: 08/23/22

APPLICABILITY: 2017-2019 MY Impreza
2018-2019 MY Crosstrek
SUBJECT: Ignition Coil Replacement



INTRODUCTION: Subaru of America, Inc. (Subaru) is recalling certain 2017-2019 model year Impreza and 2018-2019 model year Crosstrek vehicles to check and, if necessary, update the ECM programming, and to replace all four ignition coils in each vehicle.

This recall supersedes Subaru’s previous WUQ-02 ignition coil reprogramming recall issued in October 2019. Effective April 23, 2021, any open WUQ-02 recall coverage has been expired, and WUQ-02 recall repairs should no longer be performed after that date.

All vehicles previously affected by the WUQ-02 recall are now affected by this new recall and must return to complete the WRE-21 recall repair.



DESCRIPTION OF THE DEFECT AND SAFETY RISK:

Subaru has determined that the ECM reprogramming was effective for vehicles that were repaired under previous recall WUQ-02.  However, as a result of further analysis, Subaru has determined that all four ignition coils should be replaced to prevent the condition described below.

Under certain circumstances, the ignition coil may be energized longer than designed after the engine is OFF.  If the ignition coil remains energized for too long, the internal temperature of ignition coil may increase which could cause a short circuit and a blown fuse.  If a short circuit occurs while the vehicle is in motion, the vehicle may experience a loss of motive power while driving without the ability to immediately restart the engine.

If a short circuit in the ignition coil occurs while the vehicle is in motion, the vehicle may experience a loss of motive power while driving without the ability to immediately restart the engine, increasing the risk of a crash.



AFFECTED VEHICLES:

The number of U.S. vehicles affected by this recall is 466,205.

  Model Year Carline Production Date Range
2017-2019 Impreza 4D 7/1/2016 – 6/17/2019
2017-2019 Impreza 5D 7/1/2016 – 6/17/2019
2018-2019 Crosstrek 5/09/17 – 5/08/2019



Not all vehicles in the production date ranges listed above are affected by this recall.  Coverage must be confirmed by using the Vehicle Coverage Inquiry function on subarunet.com prior to repair.  This recall coverage information is now available.

Over the next several weeks, prior to owner notification, Subaru will be receiving air shipments of the parts needed to support the launch of this recall.  Therefore, the status of the WRE-21 recall will display as “Open – Limited Parts Available” until the owner notification letters are released in June.

This status is for informational purposes and will not prevent the ability for retailers to perform and claim reimbursement for this repair prior to owner notification.  Once the owner notification letters are released, the status will be updated to “Open.”



DESCRIPTION OF THE REMEDY:

For all vehicles included in this recall, Subaru retailers will check and, if necessary, update the ECM programming, and replace all four ignition coils at no cost to the customer.  If a certain DTC is found to be stored, Subaru will replace the front exhaust pipe at no cost as well.



RETAILER RESPONSIBILITY:

Any vehicles listed in any recall/campaign that are in retailer stock must be:

  • Immediately identified
  • Tagged or otherwise marked to prevent their delivery or use prior to repair
  • Repaired in accordance with the repair procedures outlined in the Product Campaign Bulletin

Retailers are to promptly perform the applicable service procedures to correct all affected vehicles in their inventory (used, demo & SSLP).  Additionally, whenever a vehicle subject to this recall is taken into retailer inventory necessary steps should be taken to ensure the recall correction has been made before selling or releasing the vehicle.

Please be sure to download a copy of your complete inventory report from the Vehicle Inventory Dashboard available on subarunet.com to identify any vehicles with open recalls that may be in your retail, CPO, and SSLP inventory.  Affected vehicles will show an Open Recall column indicator (Y).



OWNER NOTIFICATION:

Subaru will notify affected vehicle owners by first class mail in June.  Retailers will be advised when the notification is scheduled.



PART INFORMATION:

IMPORTANT NOTES:

  • A quantity of FOUR (4) ignition coils must be ordered to repair ONE (1) vehicle.
  • All orders for these ignition coils must be placed through PRIME only.
Description Part Number Qty. Required
COIL ASSEMBLY- IGNITION 22433AA7419S 4 Per Vehicle



SERVICE PROCEDURE / INFORMATION:

REMINDER:  Customer satisfaction and retention starts with performing quality repairs.

The following Flow Chart is provided as an overview of the procedures required to perform this Recall.  A detailed Service Procedure is also supplied below.

Refer to PDF Below for chart.



STEP 1)  Does the engine start normally?

No The engine does NOT start normally: Proceed to STEP 2 (inspection of fuses in M/B).

Yes The engine starts normally: Proceed to STEP 3.



STEP 2)  Inspect the M/B fuse #21 (15A) for IMPREZA and CROSSTREK.  Is the fuse blown?

No The fuse is NOT blown: Diagnose the hard starting condition per the applicable Service Manual then proceed to STEP 3.

Yes The fuse IS blown: Proceed to STEP 3. After checking DTCs, replace the fuse.



STEP 3)  Using the SSM scan for DTCs.  Are any of the following DTCs current or stored in the ECM memory?

[P0301: CYLINDER 1 MISFIRE]

[P0302: CYLINDER 2 MISFIRE]

[P0303: CYLINDER 3 MISFIRE]

[P0304: CYLINDER 4 MISFIRE]

[P0420: CATALYST SYSTEM EFFICIENCY BELOW THRESHOLD BANK 1]

No NONE of the DTCs are current or stored: Replace all four (4) ignition coils following the procedure in the applicable Service Manual.

Yes ANY of DTCs are current or stored: Replace all four (4) of the ignition coils AND the Exhaust Pipe Front assembly following the procedure in the applicable Service Manual to perform the work



TIP:  When disconnecting the harness connectors from the ignition coils, squeeze the wire retaining clip (a) and push the connector off using a trim clip tool as shown in the illustration below.  DO NOT remove the wire retaining clip from the harness connector.



IMPORTANT NOTE:

It is CRITICAL to confirm a secure connection of terminal (C) to the main fuse box. The terminal MUST be torqued to 7.5N·m (0.8kgf-m, 5.5ft-lb).



STEP 4)  Using the SSM, check the CID to determine if the ECM requires reprogramming.  Compare the current CID to the “GOOD” CID numbers supplied in the table below.

CRITICAL STEP: Is the current CID listed as “GOOD” on the table below?

No Current CID IS NOT listed as “GOOD” on the table below.  REPROGRAM THE ECM to the latest available version using the normal FlashWrite procedure.

Yes Current CID IS listed as “GOOD” on the table below.  DO NOT REPROGRAM THE ECM.  The procedure is complete.  Proceed to CLAIM REIMBURSEMENT AND ENTRY PROCEDURES section.



Model MY Transmission Type Active Grille Shutter Y/N GOOD” CID Numbers
Impreza 2017 CVT Y XH3J2B0D

XH3J2E0D

XH3J2C0D

XH3J2G0D

2017-18 5MT Y XH3J2B0C

XH3J2C1C

XH3J2C0C

XH3J2G0C

5MT N XH3J2B0A

XH3J2C1A

XH3J2C0A

XH3J2G0A

CVT N XH3J2B0B

XH3J2C0B

XH3J2E0B

XH3J2G0B

2018 CVT Y XH3J900D

XH3JA00D

XH3JB00D

XH3J2C0B

2019 5MT Y XH3N500C

XH3N600C

XH3NA00C

CVT Y XH3N500D

XH3N600D

XH3N800D

XH3NA00D

5MT N XH3N500A

XH3N600A

XH3NA00A

CVT N XH3N500B

XH3N600B

XH3N800B

XH3NA00B

Crosstrek 2018 6MT N XH3J2B0E

XH3J2C0E

XH3J2G0E

CVT N XH3J2B0F

XH3J2C0F

XH3J2E0F

XH3J2G0F

2019 6MT Y XH3N500E

XH3N600E

XH3NA00E

CVT N XH3N500F

XH3N600F

XH3N800F

XH3NA00F

REMINDER:  If the current CID is listed in this table as “GOOD”, DO NOT reprogram the ECM.



PACK FILE APPLICABILITY:

Model Year, IMPREZA PAK File Name New ECM Part Number Old ECM Part Numbers Decryption Keyword New ECM CID Number
2017MY, CAL, MT W/ AGS 22765AU28A.pak 22765AU28A 22765AJ59A,

22765AJ59B,

22765AJ59C,

22765AJ59D,

22765AJ59E,

22765AJ59F,

22765AJ59G,

22765AJ59H &

22765AJ59J

BD9CAD75 XH3J2G0C
2017MY, CAL, CVT W/ AGS 22765AU29A.pak 22765AU29A 22765AJ60A,

22765AJ60B,

22765AJ60C,

22765AJ60D,

22765AJ60E,

22765AJ60F,

22765AJ60G,

22765AJ60H &

22765AJ60J

FE01CFEB XH3J2G0D
2017MY, CAL, MT WO/ AGS 22765AU30A.pak 22765AU30A 22765AK61A,

22765AK61B,

22765AK61C,

22765AK61D,

22765AK61E,

22765AK61F,

22765AK61G,

22765AK61H &

22765AK61J

C3C6AC44 XH3J2G0A
2017MY, CAL, CVT WO/ AGS 22765AU31A.pak 22765AU31A 22765AL71A,

22765AL71B,

22765AL71C,

22765AL71D,

22765AL71E,

22765AL71F,

22765AL71G,

22765AL71H &

22765AL71J

182F9B0B XH3J2G0B
2018MY, CAL, CVT WO/ AGS 22765AL71A.pak 22765AL71A 22765AM28A,

22765AM28B,

22765AM28C,

22765AM28D,

22765AM28E,

22765AM28F &

22765AM28G

250AEE3A XH3J2C0B
2019MY, CAL, MT W/ AGS 22765AM64G.pak 22765AM64G 22765AM64A,

22765AM64B,

22765AM64D &

22765AM64E

6E8A55B5 XH3NA00C
2019MY, CAL, MT WO/ AGS 22765AM65G.pak 22765AM65G 22765AM65A,

22765AM65B,

22765AM65D &

22765AM65E

FAA8D023 XH3NA00A
2019MY, CAL, CVT W/ AGS 22765AM66G.pak 22765AM66G 22765AM66A,

22765AM66B,

22765AM66D &

22765AM66E

FC067661 XH3NA00D
2019MY, CAL, CVT WO/ AGS 22765AM67G.pak 22765AM67G 22765AM67A,

22765AM67B,

22765AM67C,

22765AM67D &

22765AM67E

5CC20BED XH3NA00B



Model Year,            CROSSTREK PAK File Name New ECM Part Number Old ECM Part Numbers Decryption Keyword New ECM CID Number
2018MY, CAL,

6MT

22765AJ618.pak 22765AJ618 22765AJ610,

22765AJ611,

22765AJ612,

22765AJ613,

22765AJ614,

22765AJ615,

22765AJ616

F9F53E35 XH3J2G0E
2018MY, CAL, CVT 22765AJ628.pak 22765AJ628 22765AJ620,

22765AJ621,

22765AJ622,

22765AJ623,

22765AJ624,

22765AJ625 &

22765AJ626

B9308D26 XH3J2G0F
2019MY, CAL, 6MT WO/ AGS 22765AM816.pak 22765AM816 22765AM810,

22765AM811,

22765AM812,

22765AM813 &

22765AM814

D2566269 XH3NA00E
2019MY, CAL, CVT WO/ AGS 22765AM826.pak 22765AM826 22765AM820,

22765AM821,

22765AM822,

22765AM823 &

22765AM824

150AAA5D XH3NA00F



CALIFORNIA “VEHICLE EMISSION RECALL – PROOF OF CORRECTION” CERTIFICATE

The California Air Resources Board and the Department of Motor Vehicles Registration/Recall Program requires that all emission related Recall/Campaign or Service Program repairs be completed before a vehicle registration is renewed. Please provide owners of vehicles registered in the state of California a completed “Vehicle Emission Recall – Proof of Correction” certificate. Vehicle owners should be advised to retain this certificate because the California Department of Motor Vehicles may require they provide proof this service program repair has been completed.




URGENT

IMPORTANT SAFETY RECALL

This notice applies to the VIN identified in the address section printed below



Subaru Safety Recall WRE-21

NHTSA ID 21V-264

June 2021



Dear Subaru Owner:

This notice is sent to you in accordance with the National Traffic and Motor Vehicle Safety Act.

SUBARU OF AMERICA, INC. has decided that a defect, which relates to motor vehicle safety, exists in certain 2017-2019 Impreza vehicles and 2018-2019 model year Crosstrek vehicles.

You received this notice because our records indicate that you currently own one of these vehicles.

This recall replaces Subaru’s previous WUQ-02 ignition coil reprogramming recall issued in October 2019.  All vehicles affected by the previous recall must return to complete the WRE-21 recall repair, even if the previous recall repair was completed.



REASON FOR THIS SAFETY RECALL

Subaru has determined that the ECM reprogramming was effective for vehicles that were repaired under previous recall WUQ-02.  However, as a result of further analysis, Subaru has determined that all ignition coils should be replaced to prevent the condition described below.

Under certain circumstances, the ignition coil may remain energized longer than designed after the engine is OFF.  If the ignition coil remains energized for too long, the internal temperature of the ignition coil may increase which could cause a short circuit and a blown fuse.



SAFETY RISK

If a short circuit in the ignition coil occurs while the vehicle is in motion, the vehicle may experience a sudden loss of power while driving without the ability to immediately restart the engine, increasing the risk of a crash.



WHAT SUBARU WILL DO

Subaru will check and, if necessary, update the electronic control module (ECM) programming, and replace all four ignition coils in your vehicle at no cost to you.  Additionally, in the unlikely event that a certain diagnostic trouble code (DTC) is found, Subaru will replace the front exhaust pipe including the catalytic converter at no cost to you.



WHAT YOU SHOULD DO

As mentioned above, all vehicles affected by the previous recall must return to complete the WRE-21 recall repair, even if the previous recall repair was completed.

Please contact your Subaru retailer (dealer) immediately for an appointment to have this repair performed, at no cost to you.



HOW LONG WILL THE REPAIR TAKE?

The time required for the ECM program check, DTC check, and ignition coil replacement is approximately one hour and ten minutes. However, if it is determined that the ECM needs to be reprogrammed, that reprogramming will require an additional twenty minutes.

In the unlikely event that a certain DTC is found, the front exhaust pipe including the catalytic converter will need to be replaced. That replacement, if necessary, will require an additional fifty minutes.

Your retailer can provide you with a better estimate of the overall time for this service visit, as it may be necessary to leave your vehicle for a longer period of time on the day of your scheduled appointment to allow your Subaru retailer flexibility in scheduling.

For your convenience, your retailer may provide you with a loaner or rental vehicle, at no cost to you, until the repair is complete.



OWNER INFORMATION

Government regulations require that recall notifications be sent to the last known owner of record. That information is based primarily on state registration and title data. If you are a lessor of this vehicle, federal regulations require you to forward this notice to your lessee within ten days.

If you have moved or sold your vehicle, please update this information online at www.subaru.com, select ‘Customer Support,’ then select ‘Address Update’ or ‘Ownership Update’ from the “Quick Links” menu.



CALIFORNIA REGISTERED OWNERS

The California Air Resources Board requires that emission related campaigns be completed prior to California’s vehicle registration renewal process; without this repair, you will not be able to register your vehicle during your next annual registration. Upon completion of this campaign, your California dealer will complete and provide you a “Proof of Correction Certificate.” If required, present the certificate to the California Department of Motor Vehicles (the “DMV”) when renewing your California registration as proof of campaign completion. If the DMV does not request the certificate, we recommend that you keep it for your records.

In addition, the State of California requires that every vehicle must pass an emission test (SMOG Check) every two years and before it is sold. Without the repair we are providing at no charge, your vehicle may not pass this test.



IF YOU HAVE PREVIOUSLY PAID FOR A REPAIR

If you have already paid for repairs associated with this coverage, you may be eligible for reimbursement. Reimbursement consideration will be based on the amount an authorized Subaru retailer in your area would charge for the same repair.

Please send the original service repair order, which has the name of the repair facility, date of repair, mileage at the time of repair, complete 17-digit vehicle identification number (VIN), and your name, with correct mailing address and telephone number to the address listed below.

Subaru of America, Inc.

Customer Advocacy Department, Attention: WRE-21 Recall

P.O. Box 9103, Camden, NJ 08101-9877



Please send original receipts only and retain a photocopy for your records.  Please be assured that we will attempt to process your reimbursement request as quickly as possible, but it may take up to 60 days for this process to be completed.



IF YOU NEED FURTHER ASSISTANCE:

To locate the nearest Subaru retailer, you can access our website at www.subaru.com and select ‘Find a Retailer.’

For additional information, please go to: http://www.wre21.service-campaign.com.

If you need additional assistance, please contact us directly:

  • By e-mail: Go to www.subaru.com and select “Contact Us”
  • By telephone: 1-844-373-6614

Monday through Friday between 8:00 a.m. and 7:00 p.m. ET

  • By U.S. Postal mail: Write us at Subaru of America, Inc.

Attn: Customer Advocacy Department

P.O. Box 9103, Camden, NJ 08101-9877

To subscribe to the NHTSA Recall Notification email System, please go to: https://www-odi.nhtsa. dot.gov/nhtsa/subscriptions.

Please contact us immediately if the Subaru retailer fails or is unable to make the necessary repairs free of charge.

You may also contact the Administrator, National Highway Traffic Safety Administration (NHTSA), 1200 New Jersey Ave., SE, Washington, DC 20590 or call the toll-free Vehicle Safety Hotline at 1-888-327-4236 (TTY: 1-800-424-9153) or go to http://www.NHTSA.gov if you believe the Subaru retailer has failed or is unable to remedy your vehicle without charge within a reasonable amount of time.

Your continued satisfaction with your Subaru is important to us.  Please understand that we have taken this action in the interest of your safety and your vehicle’s proper operation.  We sincerely apologize for any inconvenience this matter may cause and urge you to schedule an appointment as soon as possible.

Sincerely,

Subaru of America, Inc.

A subsidiary of SUBARU CORPORATION




Chronology of Defect / Noncompliance Determination Provide the chronology of events leading up to the defect decision or test data for the noncompliance:



October 17, 2019Subaru submitted voluntary safety recall 19V743.



November 18, 2019Subaru received the first technical report from a foreign market alleging a misfire occurring shortly after completion of the recall remedy.  Subaru collected the part for further evaluation.



November 2019 – March 2021Subaru conducted an investigation in cooperation with a third-party company.  In March 2020, it was confirmed that the ignition coil mold resin condition was a contributing factor.  In July 2020, as a result of analyzing the residual strain characteristics in the mold resin, Subaru confirmed that residual strain is generated by repeated heat cycling of the mold resin, and that the resin residual strain does not increase if the temperature remains low enough.  In December 2020, as a result of investigating the correlation between semiconductor strain and heat generation, Subaru confirmed that if the semiconductor is strained, the current and temperature increases.  In March 2021, simulation showed that residual strain in the mold resin and semiconductor created prior to ECM reprogramming could continue to accumulate, even under normal-duration ignition coil energization timing.  The results also showed that mass-produced ignition coils that were never exposed to energization for longer than expected durations would not accumulate strain.



April 8, 2021 – In certain foreign markets, the subject vehicle population is equipped with an automatic start/stop feature.  Field data in these markets serves as an early warning indicator for markets that do not offer an automatic start/stop feature, such as the U.S. market.  There have been no additional VOQs and 18 additional non-dealer field reports in the U.S. market.  Based on the results of the investigation and out of an abundance of caution, Subaru decided to conduct a voluntary safety recall to equip potentially affected vehicles with new ignition coils after the updated ECM programming has been applied.



Subaru is not aware of any reported accidents or injuries related to this condition.




SUBARU ANNOUNCES TWO NEW RECALLS

  • Recalls will be free of charge to customers
  • No accidents or injuries have been reported related to the recalls



Subaru of America, Inc. announced that it will voluntarily conduct two separate recalls. Subaru is announcing these recalls to encourage each owner of an affected vehicle to contact an authorized Subaru retailer as soon as they receive notification of this recall from Subaru of America.

The recalls involve the following vehicles:

  1. 2017-2019 Impreza and 2018-2019 Crosstrek models
  2. 2019 Subaru Forester and 2019 Subaru Crosstrek models

The first recall is to check and/or update the engine control module (ECM) programming and to replace all ignition coils which could, over time, degrade and cause starting or stalling issues. Incident rates are extremely low, but Subaru is conducting the recall out of an abundance of caution. This recall covers 466,205 vehicles comprising 2017-2019 Impreza and 2018-2019 Crosstrek models. No accidents or injuries have been reported due to this issue.

The second recall is for 2019 Subaru Forester and 2019 Subaru Crosstrek models to examine and re-torque bolts on the rear stabilizer bracket which could, over time, come loose. The loose bracket could then interact with other components causing damage. This recall involves 405,000 vehicles comprising 2019 Forester and Crosstrek models. Incident rates are very low and there have been no accidents or injuries reported due to this issue.

Mailed notification to owners will occur within 60 days.




5 Affected Products

Vehicles

MAKE MODEL YEAR
SUBARU CROSSTREK 2018-2019
SUBARU IMPREZA 2017-2019




16 Associated Documents

Remedy Instructions and TSB

RCRIT-21V264-6153.pdf 1318KB

Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

Download [1.26 MB]




Manufacturer Notices(to Dealers,etc) – Date: April 23, 2021 UPDATE Safety Recall: WRE-21 Impreza/Crosstrek Ignition Coil Replacement

RCMN-21V264-6285.pdf 182.706KB

Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

Download [178.42 KB]




Recall Quarterly Report #1, 2021-2

RCLQRT-21V264-3428.PDF 211.143KB

Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

Download [206.19 KB]




Manufacturer Notices(to Dealers,etc) – Date: May 13, 2021 UPDATE Safety Recall: WRE-21 Impreza/Crosstrek Ignition Coil Replacement

RCMN-21V264-7538.pdf 181.364KB

Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

Download [177.11 KB]




Remedy Instructions and TSB

RCRIT-21V264-6381.pdf 1318.449KB

Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

Download [1.26 MB]




Remedy Instructions and TSB

RCRIT-21V264-8334.pdf 1267.132KB

Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

Download [1.21 MB]




ISSUED Owner Notification Letter(Part 577)

RCONL-21V264-7230.pdf 229.411KB

Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

Download [224.03 KB]




Media Information

RMISC-21V264-4070.pdf 18.759KB

Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

Download [18.32 KB]




Manufacturer Notices(to Dealers,etc) – Date: April 15, 2021 Subarunet Announcement New Safety Recall: WRE-21 Impreza/Crosstrek Ignition Coil Replacement

RCMN-21V264-5429.pdf 175.542KB

Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

Download [171.43 KB]




Defect Notice 573 Report

RCLRPT-21V264-9268.PDF 215.681KB

Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

Download [210.63 KB]




Recall Acknowledgement

RCAK-21V264-8895.pdf 645.115KB

Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

Download [630.00 KB]




Chronology

RMISC-21V264-3597.pdf 101.889KB

Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

Download [99.50 KB]




Recall Quarterly Report #2, 2021-3

RCLQRT-21V264-9830.PDF 211.25KB

Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

Download [206.30 KB]




Remedy Instructions and TSB

RCRIT-21V264-9443.pdf 1450.76KB

Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

Download [1.38 MB]




Recall Quarterly Report #3, 2021-4

RCLQRT-21V264-5058.PDF 211.336KB

Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

Download [206.38 KB]




Remedy Instructions and TSB

RCRIT-21V264-1360.pdf 1581.184KB

Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

Download [1.51 MB]




Latest Recalls Documents

https://www-odi.nhtsa.dot.gov/acms/cs/documentList.xhtml?docId=21V264&docType=RCL




NHTSA ID Number: 10219493

Manufacturer Communication Number: WRE-21R

Summary

Subaru of America, Inc. (Subaru) is recalling certain 2017-2019 model year Impreza and 2018-2019 model year Crosstrek vehicles to check and, if necessary, update the ECM programming, and to replace all four ignition coils in each vehicle.



1 Associated Document

Manufacturer Communications

NUMBER: WRE-21R
DATE: 04/23/21
NHTSA ID: 21V-264
REVISED: 08/23/22

https://www.nhtsa.gov/recalls?nhtsaId=10219493

MC-10219493-0001.pdf 2087.383KB

Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

Download [1.99 MB]




NHTSA ID Number: 10208660

Manufacturer Communication Number: WRE-21R

Summary

Subaru of America, Inc. (Subaru) is recalling certain 2017-2019 model year Impreza and 2018-2019 model year Crosstrek vehicles to check and, if necessary, update the ECM programming, and to replace all four ignition coils in each vehicle.



1 Associated Document

Manufacturer Communications

NUMBER: WRE-21R
DATE: 04/23/21
NHTSA ID: 21V-264
REVISED: 02/21/22

https://www.nhtsa.gov/recalls?nhtsaId=10208660

MC-10208660-0001.pdf 1581.184KB

Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

Download [1.51 MB]




NHTSA ID Number: 10201023

Manufacturer Communication Number: WRE-21R

Summary

Subaru of America, Inc. (Subaru) is recalling certain 2017-2019 model year Impreza and 2018-2019 model year Crosstrek vehicles to check and, if necessary, update the ECM programming, and to replace all four ignition coils in each vehicle.



1 Associated Document

Manufacturer Communications

NUMBER: WRE-21R
DATE: 04/23/21
NHTSA ID: 21V-264
REVISED: 08/31/21

https://www.nhtsa.gov/recalls?nhtsaId=10201023

MC-10201023-0001.pdf 1450.76KB

Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

Download [1.38 MB]




NHTSA ID Number: 10194852

Manufacturer Communication Number: WRE-21R

Summary

Subaru of America, Inc. (Subaru) is recalling certain 2017-2019 model year Impreza and 2018-2019 model year Crosstrek vehicles to check and, if necessary, update the ECM programming, and to replace all four ignition coils in each vehicle.



1 Associated Document

Manufacturer Communications

NUMBER: WRE-21R
DATE: 04/23/21
NHTSA ID: 21V-264
REVISED: 05/19/21

https://www.nhtsa.gov/recalls?nhtsaId=10194852

MC-10194852-0001.pdf 1322.102KB

Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

Download [1.26 MB]




NHTSA ID Number: 10191661

Manufacturer Communication Number: WRE-21R

Summary

Subaru of America, Inc. (Subaru) is recalling certain 2017-2019 model year Impreza and 2018-2019 model year Crosstrek vehicles to check and, if necessary, update the ECM programming, and to replace all four ignition coils in each vehicle.



1 Associated Document

Manufacturer Communications

NUMBER: WRE-21R
DATE: 04/23/21
NHTSA ID: 21V-264
REVISED: 04/30/21

https://www.nhtsa.gov/recalls?nhtsaId=10191661

MC-10191661-0001.pdf 1302.482KB

Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

Download [1.24 MB]




NHTSA ID Number: 10194835

Manufacturer Communication Number: Subarunet Announ

Summary

Subaru of America, Inc. (Subaru) is recalling certain 2017-2019 model year Impreza and 2018-2019 model year Crosstrek vehicles to check and/or update the ECM programming, and to replace all four ignition coils in each vehicle.



1 Associated Document

Subarunet Announcement
To: All Subaru Retailers
From: Subaru of America, Inc.
Date: May 13, 2021
UPDATE Safety Recall: WRE-21 Impreza/Crosstrek Ignition Coil Replacement

https://www.nhtsa.gov/recalls?nhtsaId=10194835

MC-10194835-0001.pdf 181.364KB

Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

Download [177.11 KB]




NHTSA ID Number: 10191594

Manufacturer Communication Number: Subarunet Announ

Summary

Subaru of America, Inc. (Subaru) is recalling certain 2017-2019 model year Impreza and 2018-2019 model year Crosstrek vehicles to check and/or update the ECM programming, and to replace all four ignition coils in each vehicle.



1 Associated Document

Manufacturer Communications

Subarunet Announcement
To: All Subaru Retailers
From: Subaru of America, Inc.
Date: April 23, 2021
UPDATE Safety Recall: WRE-21 Impreza/Crosstrek Ignition Coil Replacement

https://www.nhtsa.gov/recalls?nhtsaId=10191594

MC-10191594-0001.pdf 186.725KB

Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

Download [182.35 KB]




NHTSA ID Number: 10191564

Manufacturer Communication Number: Subarunet Announ

Summary

Subaru of America, Inc. (Subaru) is recalling certain 2017-2019 model year Impreza and 2018-2019 model year Crosstrek vehicles to check and/or update the ECM programming, and to replace all four ignition coils in each vehicle.



1 Associated Document

Manufacturer Communications

Subarunet Announcement
To: All Subaru Retailers
From: Subaru of America, Inc.
Date: April 15, 2021
New Safety Recall: WRE-21 Impreza/Crosstrek Ignition Coil Replacement

https://www.nhtsa.gov/recalls?nhtsaId=10191564

MC-10191564-0001.pdf 179.561KB

Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

Download [175.35 KB]






“This site contains affiliate links for which OEMDTC may be compensated”
Bestseller No. 1
A-Premium Ignition Coil Pack Compatible with Subaru Forester 2009-2010 Impreza 2011 H4 2.5L Naturally Aspirated
  • [Vehicle Fitment]: Compatible with Subaru Forester H4 2.5L 2009-2010 (Naturally Aspirated) // Impreza H4 2.5L 2011 (Naturally Aspirated)
  • [Reference Number]: 22433AA590, 32011356, UF-625, UF625, GN10613, C854, 5C1765, 1788499, 48981
  • [Specifications]: ①Terminal Type: Blade; ②Terminal Quantity: 4; ③Mount Type: Bolt On; ④Mounting Location: Valve Cover; ⑤Voltage: 12V
  • [Perfect Fit]: Quick and easy installation; Perfect match for the original vehicles.
  • [Buy with Confidence]: A-Premium offers a one-year unlimited-mileage guarantee on our meticulously crafted ignition coil. We offer a wide variety of automotive accessory categories, ensuring that you can hit the road with peace of mind.
Bestseller No. 2
ENA Set of 4 Ignition Coil Pack Compatible with Subaru Baja Impreza Legacy Outback Replacement for C1479 UF508 UF567
  • Engineered for original equipment and replacement applications
  • Designed and manufactured to operate reliably under all conditions
  • Easy and quick installation
  • Please use the Amazon Confirmed Fit function and enter your vehicle information for a correct compatibility
  • 1 Year Limited Warranty
Bestseller No. 3
TRQ Ignition Coils Wires & Spark Plugs Compatible with Baja Forester Impreza Legacy Outback
  • Direct Fit, OE Replacement Ignition Kit
  • Kit Includes: (4) Spark Plugs; (1) Spark Plug Wire Set; (1) Ignition Coil
  • Vehicle Specific: Check fitment information in the listing for compatibility
  • OE Reference Number(s): 101905611,101905640D,12290RB0J01,12290RB0J11,12290RTW004,1771012930,1822A002,1822A021,1822A030,1822A069,1822A078,1822A079,1881411062,1883911051,22401AA310,22401AA730,22401AA731,22433AA410,22433AA41A,22433AA41B,22433AA570,22451AA720,22451AA730,22451AA800,22451AA810,272207,274103C000,31216297,31216525,3S4G12405AB,8692070,8692071,8694749,9008091180,9091901184,9091901210,9091901211,9091901237,90919C1002,90919T1007,96130723,980795515V,99917022790,AGSF22YPC,L34118110,L3Y418110
  • Aftermarket Reference Number(s): 0241235774,05159713AB,05269897,09479,0948200549,0948200550,101905611,101905640D,12290RB0J01,12290RB0J11,12290RTW004,1313,1756119,1765299,1771012930,1788402,1822A002,1822A021,1822A030,1822A069,1822A078,1822A079,1881411062,1883911051,2240120J05,2240120J06,2240120J07,22401AA310,22401AA730,22401AA731,22433AA410,22433AA41A,22433AA41B,22433AA570,22451AA720,22451AA730,22451AA800,22451AA810,241235774,272207,274103C000,27577,30520467,31216297,31216525,32000118,32000330
Bestseller No. 4
DrCax OEM Ignition Coil UF480 C1401 EJ205 Compatible with Subaru 2002 2003 2004 2005 Impreza WRX, WRX Wagon Replaces 22433AA561 22433AA560 - H4 2.0L Engines - 1 Pack
  • [PRECAUTIONS PURCHASE]: Please use Amazon's Your Garage function and verify the fitment of the autopart by the year/make/model of your vehicle and the OE number of the replaceable part.
  • [SOLUTION]: Fixes common ignition system failures such as backfiring, misfires, stalling, engine jerking, poor idling and restores power for peak engine performance, check engine lights for circuit malfunction and hard stalling.
  • [OE STANDARD]: All of the DrCax ignition coils are built to achieve or exceed OE specifications, subject to strict quality control testing. Every component either matches or improves on the OE design to ensure fast and easy installation with superior possible performance and dependability.
  • [REPLACEMENT PART NUMBER]: ?5C1398, E960, 52-1749, IC560, UF480, 22433-AA421, 22433-AA560, 22433-AA561
  • [BUY WITH CONFIDENCE]: DrCax ignition coil comes complete with a One year warranty.If the coil ever fails on your car,simply contact us for a replacement. Save time and money by taking advantage of this warranty.
Bestseller No. 5
YEAPHI Ignition Coil Armature Magneto Compatible with Subaru Robin Ex13 Ex17 Ex21 Ex 13 17 21 Engine Motor SP170 SP210 Sp 170 210 277-79431-01 277-79431-11 20A-79431-01 277 79431 01 11 20A Z101
  • Type:Ignition Coil Armature Magneto Compatible with Subaru Robin Ex13 Ex17 Ex21 Ex 13 17 21 Engine Motor SP170 SP210 Sp 170 210 277-79431-01 277-79431-11 20A-79431-01 277 79431 01 11 20A Z101
  • Fitment:Compatible with 277-79431-01 277-79431-11 20A-79431-01,SP170 SP210
  • Package includes: 1x Ignition Coil
  • You can find the right part you need including ignition coil, air filters, recoil starter, clutch kits and other engine repair parts
  • We have about 27 years of experience in spares parts for general gasoline engines, such as ignition coil, AVR, voltage regulator, flywheel, etc.
Bestseller No. 6
DRIVESTAR Ignition Coil Pack 2000-2005 for Subaru Outback Legacy 1999-2004 Impreza Forester 2004-2006 Baja 2.2L 2.5L Replacement with UF240,22433-AA410
  • 【Fitment】Coil fit 1999-2004 for Subaru Impreza Forester Baja Outback and so on.More Detial please check Part Finder
  • 【Direct Replacement】We only use the highest grade materials.This makes our product durable and reliable under extreme conditions while providing High Electrical Resistance,strong Spark from plugs,and being resistant to Corrosion and Abrasion
  • 【High Quality Material】all parts of the ignition coil are designed with proven materials,including wire and wire coating that have high tolerance to high temperature,which can resist the cracks,pin holes and imperfections that most often lead to failure issues
  • 【Note】To keep longer use time of the ignition coils,please pay attention to the condition of sparks.The ignition coils need to work more frequently when work together with the aged spark,that will get the ignition coils become easy to overload and aged
  • 【Compatible with OEM Numbers】22433-AA570,5C1276,UF-240,IC304,UF240,204587,52-1632,2505-92152,E765,UF-324,352Z,178-8402,E750,E524D,52-1632
Bestseller No. 7
DrCax OEM Ignition Coil UF724 22433AA651 Compatible with Scion FR-S Subaru BRZ Forester Impreza Legacy Outback Replaces 22433AA652 UF710 UF720 2.0L 2.5L H4-1 Pack
  • [PRECAUTIONS PURCHASE]: Please use Amazon's Your Garage function and verify the fitment of the autopart by the year/make/model of your vehicle and the OE number of the replaceable part.
  • [SOLUTION]: Fixes common ignition system failures such as backfiring, misfires, stalling, engine jerking, poor idling and restores power for peak engine performance, check engine lights for circuit malfunction and hard stalling.
  • [OE STANDARD]: All of the DrCax ignition coils are built to achieve or exceed OE specifications, subject to strict quality control testing. Every component either matches or improves on the OE design to ensure fast and easy installation with superior possible performance and dependability.
  • [REPLACEMENT PART NUMBER]: SU003-04670, SU003-04713, SU00304670, UF-724, UF724, C974, 5C1899, COP626, 49131, UF-720, UF-721, UF-722, UF-723, UF-737, UF710
  • [BUY WITH CONFIDENCE]: DrCax ignition coil comes complete with a One year warranty.If the coil ever fails on your car,simply contact us for a replacement. Save time and money by taking advantage of this warranty.
Bestseller No. 8
A-Premium Set of 4 Ignition Coil Pack and Iridium Spark Plugs Compatible with Subaru Outback 2013-2014, Forester 2014-2016, Impreza 2013-2015, XV Crosstrek 2013-2014, Legacy 2013-2014, 2.0L 2.5L
  • [Vehicle Fitment]: Compatible with Subaru Forester 2014-2015 H4 2.5L Naturally Aspirated, Forester 2016 H4 2.5L, Impreza 2013-2015 H4 2.0L, Legacy 2013-2014 H4 2.5L, Outback 2013-2014 H4 2.5L, XV Crosstrek 2013 H4 2.0L, XV Crosstrek 2014 H4 2.0L GAS
  • [Reference Number]: UF-724, UF724, UF721, SU003-00417, FA20, FK0438, NGK93501, 93501
  • [Specifications]: ①Coil Terminal Quantity: 3; ②Terminal Type: Blade; ③Mount Type: Bolt On; ④Mounting Location: Valve Cover; ⑤Voltage: 12V; ⑥Spark Plug Material: Iridium
  • [Iridium spark plug]: Iridium is a type of refined alloy which is highly suitable to be used as the materials of the central electrode in a spark plug. It extends the life of the spark plug nearly threefold, ensures a more stable idle speed of the engine, and delivers a super performance to the engine with improved fuel efficiency, reduced emissions and faster starting up.
  • [Buy with Confidence]: A-Premium offers a one-year unlimited-mileage guarantee on our meticulously crafted ignition coils and spark plugs kit. We offer a wide variety of automotive accessory categories, ensuring that you can hit the road with peace of mind.
Bestseller No. 9
ENA Set of 6 Ignition Coil Pack Compatible with Subaru 2001 2002 2003 2004 2005-2009 Outback, 2006 2007 B9 Tribeca, 2008 2009 Tribeca Legacy 3.0L 3.6L H6 Coils Replacement for C1326 UF287
  • Compatible with Subaru 2001 2002 2003 2004 2005 2006 2007 2008 2009 Outback H6 3.0L, Compatible with Subaru 2006 2007 B9 Tribeca H6 3.0L
  • Compatible with Subaru 2008 2009 Tribeca H6 3.6L, Compatible with Subaru 2008 2009 Legacy H6 3.0L
  • Replacement for UF287 5C1281 E884 52-1700 IC392 22433-AA441 22433-AA530 48674 C1326
  • Please use the Amazon Confirmed Fit function and enter your vehicle information for a correct compatibility
  • Package Includes and Warranty: Set of 6 Ignition Coil Pack, 1 Year Limited Warranty
Bestseller No. 10
TRQ Engine Spark Ignition Coil Direct Fit Set of 4 for Subaru Forester 2.5L
  • Direct Fit, OE Replacement Ignition Coil Set
  • Vehicle Specific: Check fitment information in the listing for compatibility
  • OE Reference Number(s): 22433AA652,22433AA690,22433AA691
  • Aftermarket Reference Number(s): 22433AA652,22433AA690,22433AA691,E1210,GN10685,UF710,UF737

Last update on 2024-05-07 / Affiliate links / Images from Amazon Product Advertising API

This product presentation was made with AAWP plugin.




Leave a Comment

Share to...
