Accessory Installation Guide
2025MY Forester – FRONT BUMPER TRIM | E5510SL000 |
Installation manual
FRONT BUMPER TRIM
Genuine SUBARU part numbers:
E5510SL000 (Turquoise blue)
E5510SL020 (Silver)
Vehicle model: FORESTER 2025MY~
To installation worker
This manual describes how to install and handle FRONT BUMPER TRIM.
1.Before installation, be sure to read thismanual for proper work.
2.The caution mark ⚠in this manualindicates important instructions. Strictly follow them.
3.SUBARUmay not be held responsible for problems that occur due to your failure to follow thisinstallation manual.
⚠Important instructions
1.Before starting installation work, move the vehicle to a safe location.
2.To work safely, make sure that the vehicle does not move. (Make sure to apply parking brake.)
3.After turning the ignition off, disconnect the battery ground terminal.
4.Handlethis product with care not to damage it or the vehicle.
Work outline
Replacementof Front Bumper Molding
①Unpack the box and check that theproduct has no defect.
②Remove the front bumper.And then remove the bumper guard.
③Replace the molding of the bumper guard with this product.
④Install thebumper guard to the front bumper. And then install it to the vehicle.
⑤After completing theabove, check the appearance to ensure there is no scratch and such.
Work procedures
1.Remove the front bumper.
(1)To replace the molding with this product, remove the front bumper from the vehicle.
・Read the service manual todo this work.
・Theremovedparts are reused.
Be careful not to lose or damagethem during work.
・Be careful of harness connectors including sensors.
Ifexcessive load is applied to them, wire breakage or connector failure could occur.
2.Remove the bumper guard.
(1)To replace the molding with this product, remove the bumper guard from the bumper.
①.Removethe clips (one side: 3 places) that fasten the bumper guard side LH
(RH).
②.Loosen theclaws (one side: 3 places) and remove the bumper guard side LH (RH).
③.Remove the clips (one side: 2 places) that fasten the bumper guard.
④.Loosenthe claws (18 places) and remove the bumper guard.
⚠Importantinstructions
Withoutremoving the bumper, you cannot access some screws that fasten the molding.
3.Replace the molding with this product.
(1)Remove the screw (1 place) that fastens the molding to the bumper guard.
(2)While widening the claw fitting portion (on bumper guard), remove the claws (8 places) on the molding from the vehicle inside.
(A plastic remover helps remove claws easily.)
(3)After removing all the claws, install this product to the bumper guard. Make sure that all the fitting portions are inserted.
(4)After the replacement, fasten this product with the removed screws. (Tightening torque: 0.8 N・m)
⚠Importantinstructions
・Theremoved screws are used again. Be careful not to lose them.
・Be care notto damage the vehicle, this product, or surrounding parts.
4.Install the bumper again.
(1)Install the front bumper guard to the bumper.
(2)Install the front bumper to the vehicle.
*Installthem in the reverse order to removal.
*Be care not to damage thevehicle, this product, or surrounding parts.
5.Check after replacement completion
(1) Make sure that there is no scratch on thisproduct or surrounding areas, and that this product is surely installed.
(2)Return the removed parts to the customer.
Thisis the completion of molding replacement.
E5510SL000
https://techinfo.subaru.com/stis/doc/accInstallGuide/ixi%20E5510SL000,020_00.pdf
- Fit For 2015 - 2021 Subaru WRX STI Sedan Only
- High-Quality Light Weight Durable ABS Material
- Flat Black Finished; Ready To Be Paint To Match Your Vehicle
- Upgrade Your Vehicle with Sporty Appearance with Protection to The Original Lip
- The Installation Manual or Tool is NOT Included. Professional Installation is Highly Recommend
- 30-PCS Front Bumper, Engine Cover, Fender Splash Shield, Quarter Trim Panel, Cowl Trim Panel, Cowl Grille Clip, Headlamp Assembly Retainer, Protector Retainer For Subaru BRZ Tribeca Legacy Outback. OEM Number: for Subaru 90914-0051
- 30-PCS Engine Cover, Phillips Drive Fender Liner Clip, Under Cover Clip, Handle, Inside Clip, Floor Pan Splash Shield Clip For Subaru Crosstrek Forester Legacy Outback XV Crosstrek B9 Tribeca. OEM Number: for Subaru 90913-0067
- 40-PCS Bumper Engine Cover Fender, Grille Clip, Side Cover Clip, Reflector Clip, Reinforced Beam Clip, Splash Pan Clip, Deflector Retainer For Subaru Crosstrek Forester Impreza Ascent BRZ WRX STI. OEM Number: for Subaru 90914-0007
- High Quality - Our clips are made of premium black nylon material, ensuring excellent durability and resistance to breakage. They feature a push-in design for fast and secure fastening. Completely meet your daily use needs. Each size is packed in a separate pouch.
- Practical Function - The push-type fastener clips play an important role in replacing and securing car accessories like engine covers, bumper, fender, cowl trim panel, and wheel well, The fastener can effectively enhance your work efficiency and provide better safety for vehicles.
- Easy to Install: The installation of this front bumper side spoiler is simple and does not require complicated operations, save time and effort.
- Applicable Model: This front bumper side trim is an ideal replacement for Subaru Forester 2014‑2017, please confirm the model to ensure precise fit.
- Premium Materials: This front bumper side spoiler is made of lightweight ABS material, which has better wear resistance, aging resistance and durability.
- Damage : Professional manufactured, exquisite workmanship, this front bumper side spoiler won't scratch the paint on your car or damage the original equipment of the vehicle.
- Stylish Exterior Decoration: With its sleek, clean lines, this front bumper side spoiler perfectly embellishes and highlights your car and shows off your charisma.
- 40pcs 90914-0007 Bumper, Engine Cover, Fender & Grille Push-Type Retainer for Subaru Baja, Forester, Impreza, Legacy, Outback & Tribeca 2011 - 2000
- 30pcs 90913-0067 Engine Cover and Fender Liner for Subaru B9, Forester, Legacy, Outback & Tribeca 2005 -
- 30pcs 90914-0051 Front Bumper & Quarter Panel Push-Type Retainer for Subaru Impreza, Legacy, Outback & Tribeca 2011 - 2005
- FITS VARIOUS SUBARU MODELS - The clips fit selected Subaru as well some other car brands.
- Premium OEM Upgraded Quality and Durable —Made of Premium Auto Grade Nylon:PA66(Not Ordinary Cheap Nylon),solid like metal.
Replacement for Subaru Clips OEM NO.: 909140007 (90914-0007)—Fender Liner / Engine Cover / Wheel well Clips
—23/64"(10mm)Hole, Head Dia:13/16"(21mm);Stem Lgt:9/16"(15mm)--20PCSReplacement for Subaru Fasteners OEM NO.:909130067 (90913-0067)—Bumper / Fender Liner / Mud flap / Engine cover / Grill Clips
—5/16"(8mm) Hole, Head Dia:11/16"(18mm);Stem Lgt:3/8"(10mm)--15PCSReplacement for Subaru Rivets OEM NO.: 909140051(90914-0051)—Front Bumper / Quarter Trim Panel / Cowl Trim Panel / Splash Shield / Headlamp Assy Clips
—1/4"Hole(7mm),Head Dia:13/16"(20mm);Stem Lgt:3/8"(9mm)--15PCS- Replacement for Subaru Clips OEM NO.: 91486KJ010 (91486-KJ010)—Cowl Panel Vent Cap Clips —0.17"(4.4mm)Hole, Head Dia:0.72"(18.2mm);Stem Length:0.54"(13.7mm)--15PCS. Replacement for Subaru Clips OEM NO.: 909140063 (90914-0063)—Cowl Vent Air Inlet Duct Push-Type Retainer Clips —0.27"(6.8mm)Hole, Head Dia:0.78"(19.9mm);Stem Length:0.52"(13.2mm)--15PCS
- Premium OEM Upgraded Quality and Stable Subaru Clips Set —Made of Premium Auto Grade Nylon:PA66(Not Ordinary Cheap Nylon),solid like metal. Stable Fasteners & Fastener Remover with Conveniently Organized Box —15*4.4mm hole clips+15*6.8mm hole clips+15*8mm hole clips+20*10mm hole clips+15*7mm hole clips+1*Fastener Remover
- Garage-Pro Aftermarket Replacement Compatible with 2017-2018 Subaru Forester
- Garage-Pro JCWRS01610002GP Features: Textured
- Location: Front, Driver Side
- Interchange Part Numbers: 57708SG030, SU1046100
- A high quality, Direct Fit OE Replacement Bumper Trim with FREE 1-year UNLIMITED mileage warranty coverage on Garage-Pro items.
- Aftermarket Replacement Bumper Trim Compatible with 2017-2018 Subaru Forester
- Interchange Part Numbers: 57708SG020, SU1047100
- Front, Passenger Side Bumper Trim Finish Textured
- Direct Fit Aftermarket Replacement
- A high quality, Direct Fit OE Replacement Bumper Trim, with FREE 1-year UNLIMITED mileage warranty coverage on Garage-Pro items.
- Other Names:Under Cover Clip, Grille Clip, Fender Liner Clip, Splash Shield Clip, Fender Liner Retainer Clip, Lower Cover Clip, Sight Shield Clip, Cover Clip, Reinforced Beam Clip, Side Cover Clip, Bumper Cover Retainer Clip, Lower Bracket Retainer Clip, Fender Liner Retainer, Suspension Cross-Member Clip, Wheelhouse Liner Retainer, Grille Assembly Clip, Plate Clip, Pad Clip, Bumper Cover Fastener, Reinforcement Fastener, Guide Clip, Side Retainer Rivet, Upper Quarter Trim Fastener.
- Upper Seal Clip, Corner Support Clip, Protector Clip, Under Cover Retainer Clip, Upper Bracket Clip, Grille Bracket Clip, Lower Bracket Clip, Retainer Plate Clip, Upper Plate Clip, Bracket Clip, Fog Lamp Assembly Clip, Side Bracket Retainer Clip, Upper Cover Retainer Clip, Cover Plate Clip, Hole Cover Clip, Pillar Trim Clip, Closure Panel Clip, Spoiler Clip, Protect Shield Clip, Backup Lamp Clip, Duct Clip, Outer Cover Clip, Bumper Cover Retainer, Bumper Cover Side Bracket
- Replaces Subaru: 90914-0007 Fits: Subaru: Ascent, B9 Tribeca, Baja, BRZ, Crosstrek, Forester, Impreza, Legacy, Outback, Tribeca, WRX, WRX STI, XV Crosstrek
- Head Diameter: 21mm Stem Length: 15mm Fits Into 10mm Hole
- Meet or Exceed OEM Specification. This is the most common Clip for Subaru cars. Commonly Used in Front Bumper, Front Grille, Front Suspension, Fuel Tank, Mudguard,Under Cover & Exhaust Cover, Inner Trim..etc
- Clips Type: Bumper, Engine Cover, Fender & Grille Push-Type Retainer
- Dimensions: Head Diameter: 21mm, Stem Length: 15mm (Excluding the Pin), Fits into 10mm Hole
- Material: Durable black nylon, easy to install and remove.
- Car Fitment for: 2019 Subaru Ascent, 2003-2006 Subaru Baja, 2013-2019 Subaru BRZ, 2016-2019 Subaru Crosstrek, 2003-2019 Subaru Forester, 2002-2019 Subaru Impreza, 2004-2014 Subaru Impreza STI, 2002-2014 Subaru Impreza WRX, 2000-2019 Subaru Legacy, 2000-2019 Subaru Outback, 2006-2014 Subaru Tribeca, 2015-2019 Subaru WRX, 2015-2019 Subaru WRX STI, 2013-2015 Subaru XV Crosstrek
- Package Includes: 20pcs Push Pins
Last update on 2024-04-29 / Affiliate links / Images from Amazon Product Advertising API
This product presentation was made with AAWP plugin.
SEOCONTENT-START
1
Δ00
Rev. No.
Revision content
Date
00
New establishment
2023/8/9
FRONT BUMPER TRIM
Installation manualGenuine SUBARU part numbers: E5510SL000 (Turquoise blue) E5510SL020 (Silver)Vehicle model: FORESTER 2025MY~
This manual describes how to install and handle FRONT BUMPER TRIM.
1.Before installation, be sure to read thismanual for proper work.
2.The caution mark ⚠in this manualindicates important instructions.
Strictly follow them.
3.SUBARUmay not be held responsible for problems that occur due to
your failure to follow thisinstallation manual.
To installationworker
⚠Important instructions
1.Before starting installation work, move the vehicle to a safe location.
2.To work safely, make sure that the vehicle does not move.
(Make sure to apply parking brake.)
3.After turning the ignition off, disconnect the battery ground terminal.
4.Handlethis product with care not to damage it or the vehicle.
Distributor: SUBARU Co., Ltd.
2
Completed installation sketch
Componentparts
Tools required for work
Workoutline
Replacementof Front Bumper Molding
①Unpack the box and check that theproduct has no defect.
②Remove the front bumper.And then remove the bumper guard.
③Replace the molding of the bumper guard with this product.
④Install thebumper guard to the front bumper. And then install it to the vehicle.
⑤After completing theabove, check the appearance to ensure there is no scratch
and such.
①
②
Gloves
Phillips head screwdriver
Cleaner
(Nonaneis recommended.)
Plastic remover
Front Bumper Trim
Protective tape■E5510SL000 (turquoise blue) / E5510SL020 (silver)No.Item nameQty①Front Bumper Trim RH1②Front Bumper Trim LH1
3
2.Remove the bumper guard.
(1)To replace the molding with this product,
remove the bumper guard from the bumper.
①.Removethe clips (one side: 3 places) that fasten the bumper guard side LH
(RH).
②.Loosen theclaws (one side: 3 places) and remove the bumper guard side LH
(RH).
③.Remove the clips (one side: 2 places) that fasten the bumper guard.
④.Loosenthe claws (18 places) and remove the bumper guard.
Work procedures
⚠Importantinstructions
Withoutremoving the bumper, you cannot access some screws that fasten the molding.
Bumper guard side LH (RH)
Bumperguard
④Whilewidening, remove the claw.
①Removethe clips.
③Removethe clips.
Vehiclecenter
Fig. 2 Front bumper LH when seen from the back side
Removingdirection
Removingdirection
Removingdirection
②Whilewidening, remove the claw.
1.Remove the front bumper.
(1)To replace the molding with this product,
remove the front bumper from the vehicle.
・Read the service manual todo this work.
・Theremovedparts are reused.
Be careful not to lose or damagethem during work.
・Be careful of harness connectors including sensors.
Ifexcessive load is applied to them, wire breakage or connector failure could
occur.
4
3.Replace the molding with this product.
(1)Remove the screw (1 place) that fastens the molding
to the bumper guard.
(2)While widening the claw fitting portion (on bumper guard),
remove the claws (8 places) on the molding from the vehicle inside.
(A plastic remover helps remove claws easily.)
(3)After removing all the claws, install this product to the bumper guard.
Make sure that all the fitting portions are inserted.
(4)After the replacement, fasten this product with the removed screws.
(Tightening torque: 0.8 N・m)
4.Install the bumper again.
(1)Install the front bumper guard to the bumper.
(2)Install the front bumper to the vehicle.
*Installthem in the reverse order to removal.
*Be care not to damage thevehicle, this product, or surrounding parts.
⚠Importantinstructions
・Theremoved screws are used again. Be careful not to lose them.
・Be care notto damage the vehicle, this product, or surrounding parts.
Bumper guard
Molding
(2)Whilewidening, remove the claws.
(1) Removethe screw.
Fig. 3 Frontbumper molding LHwhen seen from the back side
5.Check after replacement completion
(1) Make sure that there is no scratch on thisproduct or surrounding areas, and
that this product is surely installed.
(2)Return the removed parts to the customer.
Thisis the completion of molding replacement.
**************************************************************************************************************
**************************************************************************************************************
