NHTSA ID Number: 10161814
Manufacturer Communication Number: 07-153-19
Summary
This service bulletin announces availability of the cap portion (a.k.a. spark plug boot) as a service part separate from the complete ignition coil assembly. If the cap portion as shown in the illustrations below is damaged during removal or replacement, it is no longer necessary to replace the complete ignition coil assembly.
10 Affected Products
Vehicles
INTRODUCTION:
This service bulletin announces availability of the cap portion (a.k.a. spark plug boot) as a service part separate from the complete ignition coil assembly. If the cap portion as shown in the illustrations below is damaged during removal or replacement, it is no longer necessary to replace the complete ignition coil assembly.
PART INFORMATION:
The part number for the new CAP- IGNITION COIL is 22489AA040.
SERVICE PROCEDURE / INFORMATION:
- Removal of CAP-IGNITION COIL:
- Installation of CAP-IGNITION COIL:
IMPORTANT NOTE: NEVER use any lubricant or grease on either part when re-assembling.
SEOCONTENT-START
Bulletin Number: 07-153-19; Date: 05/07/19 Page 1 of 2
Continued…
NUMBER: 07-153-19
DATE: 05/07/19
APPLICABILITY: 2015-19 Legacy and Outback 2.5L
SUBJECT: Ignition Coil Cap Now Available as Service Part
CAUTION: VEHICLE SERVICING PERFORMED BY UNTRAINED PERSONS COULD
RESULT IN SERIOUS INJURY TO THOSE PERSONS OR TO OTHERS.
Subaru
Service Bulletins are intended for use by professional technicians ONLY. They
are written to inform those technicians of conditions that may occur in some vehicles,
or to provide information that could assist in the proper servicing of the vehicle. Properly
trained technicians have the equipment, tools, safety instructions, and know-how to
do the job correctly and safely. If a condition is described, DO NOT assume that this
Service Bulletin applies to your vehicle, or that your vehicle will have that condition.
Subaru of America, Inc. is
ISO 14001 Compliant
ISO 14001 is the international standard for
excellence in Environmental Management
Systems. Please recycle or dispose of
automotive products in a manner that is friendly
to our environment and in accordance with all
local, state and federal laws and regulations.
INTRODUCTION:
This service bulletin announces availability of the cap portion (a.k.a. spark plug boot) as a service
part separate from the complete ignition coil assembly. If the cap portion as shown in the illustrations
below is damaged during removal or replacement, it is no longer necessary to replace the complete
ignition coil assembly.
PART INFORMATION:
The part number for the new CAP- IGNITION COIL is 22489AA040.
SERVICE PROCEDURE / INFORMATION:
1) Removal of CAP-IGNITION COIL:
SERVICE BULLETIN
ATTENTION:
GENERAL MANAGER q
PARTS MANAGER q
CLAIMS PERSONNEL q
SERVICE MANAGER q
IMPORTANT – All
Service Personnel
Should Read and
Initial in the boxes
provided, right.
©2019 Subaru of America, Inc. All rights reserved.
Bulletin Number: 07-153-19; Date: 05/07/19 Page 2 of 2
2) Installation of CAP-IGNITION COIL:
New Part: CAPIGNITION
COIL
IMPORTANT NOTE: NEVER use any lubricant or grease on either part when re-assembling.
WARRANTY / CLAIM INFORMATION:
For vehicles within the Basic New Car Limited Warranty period or covered by an active Subaru
Added Security Gold plan, this repair may be submitted using the following claim information:
Labor Description Labor Operation # Labor Time Fail Code
REPLACE ONE IGNITION COIL CAP B813-163 0.5
GAM-02
REPLACE EACH ADDITIONAL IGNITION COIL CAP B813-165 0.2
IMPORTANT REMINDERS:
• SOA strongly discourages the printing and/or local storage of service information as
previously released information and electronic publications may be updated at any time.
• Always check for any open recalls or campaigns anytime a vehicle is in for servicing.
• Always refer to STIS for the latest service information before performing any repairs.
NUMBER: 07-153-19
DATE: 05/07/19
