NHTSA ID Number: 10150946
Manufacturer Communication Number: 03-79-18R
Summary
This bulletin announces a change to the clutch system components optimizing their durability and resistance to certain severe driving conditions including high-temperature operation.
4 Affected Products
Vehicle
MAKE | MODEL | YEAR |
SUBARU | WRX | 2015-2018 |
INTRODUCTION:
This bulletin announces a change to the clutch system components optimizing their durability and resistance to certain severe driving conditions including high-temperature operation.
PRODUCTION CHANGE INFORMATION:
The new clutch components were incorporated into production during mid-2018MY production starting with VIN J*806877.
PART INFORMATION:
The new clutch system components consist of the following:
Part Number / Description | Details / Notes |
12342AA170 FLYWHEEL AY-FLEX ASSEMBLY |
|
30210AA800 COVER COMPLETE-CLUTCH |
SERVICE PROCEDURE / INFORMATION:
Whenever clutch system repairs are necessary, follow the procedures in the applicable Service Manual. There are no changes to the existing Service Manual procedures when installing these new components.
IMPORTANT NOTES:
- For multiple occurrences or low mileage clutch disc / cover / flywheel replacements due to excessive wear or failure, always confirm the customer’s driving habits or usage conditions before proceeding with any clutch system repairs.
- Using the new-style replacement parts listed above WILL NOT protect the clutch system from severe abuse.
- Should the customer’s driving habits cause excessive and / or premature wear of “old-style” components, replacing all 5 of the parts listed above as a set will improve durability of the clutch system.
- If the new-style pedal assembly has already been installed, just the flywheel, cover and disc can be replaced as a set.
- REMINDER: NEVER attempt to resurface the flywheel assembly.
- Always advise the customer to operate their clutch system as outlined in the Owner’s Manual “Starting and Operating / Manual Transmission” section.
- Always use the proper grease (Nichimoly N-130, Conoco-Philips Multiplex Red #2 or Subaru p.n. 000041000) when lubricating the contact points of the release bearing and related components as specified in the Service Manual. (See TSB 03-78-17 for more related information.)
SEOCONTENT-START
APPLICABILITY: 2015-18MY WRX
SUBJECT: Clutch System Part Changes
WARRANTY / CLAIM INFORMATION:
Always refer to the Labor Time Guide for specific component coverage.
Labor Description | Labor Operation # | Labor Time | Fail Code |
WRX Clutch Replacement per TSB 03-79-18 | B215-211 | 4.3 | KDF-48 |
WRX Clutch /Pedal Bracket Repl. per TSB 03-79-18 | C316-611 | 1.0 |
IMPORTANT REMINDERS:
- SOA strongly discourages the printing and/or local storage of service information as previously released information and electronic publications may be updated at any time.
- Always check for any open recalls or campaigns anytime a vehicle is in for servicing.
- Always refer to STIS for the latest service information before performing any repairs.
SEOCONTENT-END
NUMBER: 03-79-18R
DATE: 04/18/18
REVISED: 10/22/18
https://www.nhtsa.gov/recalls?nhtsaId=10150946
https://static.nhtsa.gov/odi/tsbs/2018/MC-10150946-9999.pdf
NUMBER: 03-79-18R
DATE: 04/18/18
REVISED: 10/22/18
https://www.nhtsa.gov/recalls?nhtsaId=10150921
https://static.nhtsa.gov/odi/tsbs/2018/MC-10150921-9999.pdf
