Accessory Installation Guide
| 2020 Impreza LED Fog Lamp Upgrade | H451SFL300 |
Installation Instructions French
SEOCONTENT-START
Installation Instructions
Part Number: H451SFL300
Description: LED Fog Lamp Upgrade, Impreza
Kit Contents
Fog Lights, Driver: 1
Passenger: 1
Tools Required
10mm Socket and
Ratchet
Torque Wrench
Philips and flat head
screw drivers
Trim Tool
Icon Legends / Cautions
Description Issue Date Page 2020 Impreza LED Fog Lamp Upgrade 1 11/4/2019 Subaru
of America 1 / 3
: Remove/Disconnect : Install : Location of Clip or Screw
1) Read all instructions before proceeding with installation. If uncomfortable performing any procedures,
have installation performed by a Subaru dealer technician.
2) Take care not to damage vehicle components during removal and installation.
3) Route wiring so that it does not rub against any sharp edges.
Fog Light Cover, Driver: 1
Passenger: 1
Fastener Remover
Installation Instructions
Part Number: H451SAN100
Description: Fog Light Kit, Outback
Installation
Disconnect Negative (-) battery cable from the battery
sensor terminal. Hold the battery sensor carefully when
removing the 10mm nut.
1-1
Remove four (4) clips and retain for reinstallation
1-2
Pull down belly pan to reveal remaining bolt holding
fender liner in place.
Remove bolt and pull down the fender liner. Retain bolt
for reinstallation.
1-3 1-4
From inside, locate and remove philips head screw
securing fog light cover. Retain screw for reinstallation
Remove fog light cover.
Remove Halogen Fog Lamp. Retain Clip, Bolt and J Nut
Description Issue Date Page 2020 Impreza LED Fog Lamp Upgrade 1 11/4/2019 Subaru of America 2 / 3
Installation Instructions
Part Number: H451SFL200
Description: Fog Light Kit, Impreza
Installation
Description Issue Date Page 2020 Impreza LED Fog Lamp Upgrade 1 11/4/2019 Subaru of America 3 / 3
1-5
Install Fog Lamp Cover. Reinstall fog light cover screw,
fender liner cover bolt and four (4) clips.
Repeat install for remaining side of vehicle.
1-6
1-7
Install LED Fog lamp using J Nut, Bolt and Clip.
Plug in lamp connector, ensure the tab locks into place
Clip
J Nut
and
Bolt
Connect Negative (-) battery cable to the battery sensor
terminal.
Torque to 7.5Nm (5.5 ft lbs)
Instructions d’installation
Numéro de pièce: H451SFL300
Description: Mise à niveau des feux de brouillard à LED, Impreza
Contenu de la trousse
Phare antibrouillard, côté
conducteur : 1
côté passager : 1
Outils requis
10mm Socket and
Ratchet
Clé dynamométrique Outil à garniture en nylon
Légende des icônes et mises en garde
Description Issue Date Page 2020 Impreza Fog Lamp Kit 1 11/4/2019 Subaru of America 1 / 3
: Remove/Disconnect : Install : Location of Clip or Screw
1) Lisez toutes les instructions avant de débuter la pose. Si vous ne vous sentez pas à l’aise
2) Prenez soin de ne pas endommager les composants du véhicule durant la pose et la dépose.
3) Acheminez le câblage de façon à vous assurer qu’il ne frotte pas contre des rebords coupants.
Garniture,
côté conducteur : 1
côté passager : 1
Outil de dépose d’attache
Instructions d’installation
Débranchez la borne négative de la batterie à l’aide d’une
clé à douille de 10 mm.
1-1
Retirez quatre (4) clips et conservez-les pour
réinstallation.
1-2
Tirez sur le plat ventre pour révéler le boulon restant qui
maintient la doublure d’aile en place.
Retirez le boulon et abaissez la doublure de l’aile.
Conservez le boulon pour la réinstallation.
1-3 1-4
De l’intérieur, localisez et retirez la vis à tête cruciforme
fixant le cache des feux de brouillard. Conserver la vis
pour la réinstallation
Enlevez le cache de l’antibrouillard.
Retirer la lampe de brouillard halogène. Conserver le clip,
le boulon et l’écrou en J
Description Issue Date Page 2020 Impreza Fog Lamp Kit 1 11/4/2019 Subaru of America 2 / 3
Numéro de pièce: H451SFL300
Description: Mise à niveau des feux de brouillard à LED, Impreza
Instructions d’installation
Description Issue Date Page 2020 Impreza Fog Lamp Kit 1 11/4/2019 Subaru of America 3 / 3
1-5
Installez le cache de lampe de brouillard. Installez la vis
de cache de phare antibrouillard, le boulon de cache de
doublure d’aile et quatre (4) clips.
Répétez l’installation pour le côté restant du véhicule.
1-6
1-7
Installez le feu de brouillard à DEL à l’aide de l’écrou, du
boulon et du clip J
Branchez le connecteur de la lampe, assurez-vous que la
languette se verrouille en place
Attache
Écrou
en J et
Boulon
Numéro de pièce: H451SFL200
Description: Trousse de phares antibrouillard, Impreza
Connectez le câble négatif (-) de la batterie à la borne du
capteur de batterie.
Couple à 7,5 Nm (5,5 pi lb)
