NHTSA ID Number: 10234277
Manufacturer Communication Number: 1519216
Summary
Loose / Gapping Accessory Front Wheel Arch Moldings
NUMBER: 15-192-16
DATE: 01/14/16
APPLICABILITY: | 2015-16MY Outback |
SUBJECT: | Loose / Gapping Accessory Front Wheel Arch |
INTRODUCTION:
This bulletin provides a service procedure to address customer concerns of loose or gapping accessory front wheel arch molding(s) (E201SAL000 Molding Kit). There are 2 retaining clips on each molding which have been improved to enhance retention of the molding to the fender lip thereby eliminating any gap between the molding and the body. This bulletin applies to the FRONT wheel arch moldings only.
PART INFORMATION:
Four new replacement clips come as a kit by ordering p. n. SOA930H100. The cross-section illustration below shows the retaining clip locations and how the clip attaches the inner lip portion of the molding to the fender’s inner lip.
The depth and angle of the lock “tang” portion (circled) of the clip have been changed to provide better retention. The photo shows a comparison between the old and new -style retaining clips.
SERVICE PROCEDURE / INFORMATION:
IMPORTANT: If either front wheel arch molding is loose or gapping or if any of the 4 retaining clips are found to be loose or missing, ALL 4 of the clips must be replaced. The original clips will be destroyed when removed therefore, never attempt to “adjust” them back into shape and reuse them.
- Using a sharpened plastic trim tool or a thin, flat-blade screw driver, CAREFULLY remove the old clip by disengaging the tang from the hole in the molding it clips into and prying inward. Use caution to prevent marring the textured finish of the molding with the tool. Push inward and upward at the same time ONLY AS MUCH AS IS NECESSARY to “unhook” the top portion of the clip from the inner lip of the fender.
- Once all of the old clips have been removed, always confirm the original protective tape is in place on the fender lip as shown below before installing any new clips.
- Pull outward slightly on the lip portion of the molding and start the clip onto the inside edge aligning the tang with the retaining hole.
- IMPORTANT: Make sure the top portion of the clip is “hooked” onto the inner lip of the fender at the same time.
- Once you are sure the clip is started onto both the inner lip of the fender and the inner edge of the molding, use your thumb and forefinger to CAREFULLY squeeze the clip into proper position as shown in the photos below.
2 Affected Products
Vehicle
MAKE | MODEL | YEAR |
SUBARU | OUTBACK | 2015-2016 |
1 Associated Document
Manufacturer Communications
NUMBER: 15-192-16
DATE: 01/14/16
https://www.nhtsa.gov/recalls?nhtsaId=10234277
MC-10234277-9999.pdf 691.583KB
NHTSA ID Number: 10075064
Manufacturer Communication Number: 15-192-16
Summary
SUMMARY TO BE PROVIDED ON A FUTURE DATE.
1 Associated Document
Service Bulletin Document
NUMBER: 15-192-16
DATE: 01/14/16
https://www.nhtsa.gov/recalls?nhtsaId=10075064
SB-10075064-5448.pdf 691.583KB
