Accessory Installation Guide
2022MY BRZ Rear Bumper Appliqué | E771SCC000 |
PART NUMBER: E771SCC000
INSTALLATION INSTRUCTIONS
DESCRIPTION:
BRZ Rear Bumper Appliqué
PREPARATION – BEFORE INSTALLATION:
1. APPLICATION SOLUTION: Fill 32oz. trigger type spray bottle
with 20% Alcohol 80% Water add 2ml of Baby Shampoo. Note: Solution depends on temperature of part, temperature of vehicle surface and other factors. Note: more soap makes it easier for the squeegee to slide bubbles out from under the part when installing.
2. This product should be installed with proper installation tools.
3. Install this product while observing all warnings and precautions stated in this instruction booklet.
4. VERY IMPORTANT: Thoroughly wash vehicle with Soap and Water.
5. Parts storage should be flat at room temperature and in a clean dry place. Care should be taken to avoid a dusty environment.
Notes to the Installer
1. Read the entire installation instructions prior to beginning the installation of the accessory.
2. Ensure that the vehicle is properly protected in the area that the accessory is to be installed.
3. To prevent vehicle damage, never place tools on top of painted surfaces, seats, dash pad, console or floor carpet / mat.
4. Always wear appropriate safety gear to include gloves and eye protection when required.
1
Clean
Thoroughly wash vehicle Surface with a soft lint-free cloth. Allow the area to dry completely.
2
Dry Fit
Before removing liner, locate the center notch in the appliqué directly under the center of the bumper as shown above. Align the top of Handling Tabs to vertical surface. Then align the bottom to the end of the tangent near the curved edge and lay into position.
3
Separate Liner
Remove liner from Bumper Appliqué. After removal of part liner, to prevent contamination, limit touching adhesive side of Appliqué by handling on the Handling Tabs. Spray Alcohol, Soap and Water Application Solution on Adhesive Side of the Appliqué.
4
Spray Bumper Surface
Spray bumper surface where applique will be installed with Application Solution.
5
Appliqué Alignment
Aligning Bumper Appliqué to the center of the Bumper as shown. Align the top of Handling Tabs to vertical surface. Then align the bottom to the end of the tangent near the curved edge and lay into position NOTE: If incorrectly located, lift straight up and reposition. Additional Alcohol soap and water spray might be needed.
6
Adhere top Surface
** Begin squeegee stroke lightly touching premask surface. As you drag squeegee, apply firm pressure. This will aid in not leaving impressions in part. ** Do not wrap the edge at this time.
Spray top surface of premask with an even mist of Application Solution. Firmly squeegee the appliqué down ONLY adhering on the horizontal surface of the bumper.
7
Adhere The Radius
** Important! Inspect for bubbles.
Then, firmly squeegee the radius of the bumper with three or four back and forth strokes in the direction shown.
8
Adhere Lower Edge/Surface
** Important! Inspect for bubbles.
Firmly squeegee the lower edge/surface of the bumper with three or four back and forth strokes in the direction shown.
9
Removal of Premask
** Important! Inspect for bubbles.
Remove top protective covering CAREFULLY 180° against itself. Re-spray appliqué surface with application solution. Re-squeegee any areas or edges that may have lifted during premask removal.
Care and Cleaning
Wash rear bumper area with warm soapy water as needed, (do not use other chemical based cleaners).
Visual Check
Make sure all edges are firmly adhered.
E771SCC000
https://static.oemdtc.com/AccessoryInstallationGuide/E771SCC000.pdf
