Accessory Installation Guide
22MY BRZ Cargo Net | F551SCC000 |
Installation Instructions
INSTALLATION INSTRUCTIONS
PART NUMBER: F551SCC000
DESCRIPTION: BRZ
CARGO NET – SEDAN
1
Locate upper trim plug as indicated.
2
Remove upper trim plug from panel and discard.
3
Fit spacers, washers, and wellnut onto the T-Anchor in the upper mounting point as shown, and hand tighten until snug.
4a
Remove load floor and set on a clean, dry surface.
4b
Remove spare tire tray and set on a clean, dry surface.
5
Remove three lower trim plugs from the panel, retaining the center trim plug for reinstallation in step 9.
6
Remove trim by pulling upward, and set on a clean, dry surface.
6a
Locate and ensure all four white trim fasteners are intact after trim removal.
7
nstall item C, rubber wellnut into the lower trim.
8
Using the tools indicated, drill the two outer holes to a 1/2″. Reinstall trim panel, and reposition gasket along lower edge of trunk.
9
Reinstall spare tire tray and load floor removed in step 4a and 4b, and reinsert center trim plug retained in step 5.
10
Install T-anchor to the lower mounting point as shown in the photo. Tighten until snug, and orient in the vertical position as shown in step 11.
11
To complete final installation, place the lower bungee loops around the T-anchors as shown. Un-zip the pouch to release the cargo net, ensuring the pull tab is facing outward, and attach the upper bungee loops around the upper T-anchors.
ISSUE
1
DATE
10/27/2020
F551SCC000
https://static.oemdtc.com/AccessoryInstallationGuide/F551SCC000.pdf
