NHTSA ID Number: 10201049
Manufacturer Communication Number: 12-322-21
Summary
This bulletin announces a design change made to the cross bar integrated roof rails. The new roof rails have added reinforcement ribs on the bottom of the rail cover section.
NUMBER: 12-322-21
DATE: 08/25/21
INTRODUCTION
This bulletin announces a design change made to the cross bar integrated roof rails. The new roof rails have added reinforcement ribs on the bottom of the rail cover section. The ribs enhance the roof rail rigidity and prevent any “warped” or “wavy” appearance of the rail cover. This condition can be caused by high ambient temperatures and / or extreme sunlight exposure.
EXAMPLE:
PRODUCTION CHANGE INFORMATION:
The production change information for the Outback is currently TBD.
PART INFORMATION:
REMINDER: Always order the most up-to-date replacement parts based on the specific VIN being repaired.
| Part Description | Color | Part Number |
| ROOF RAIL ASSEMBLY-RIGHT | Black | 91151AN00B |
| Silver | 91151AN02B | |
| ROOF RAIL ASSEMBLY-LEFT | Black | 91151AN01B |
| Silver | 91151AN03B |
SERVICE PROCEDURE / INFORMATION:
REMINDER: Customer satisfaction and retention starts with performing quality repairs.
The service procedures for the roof rails remain unchanged. ALWAYS refer to STIS and review the full requirements of the repair being performed: Body & Electrical/WIRING SYSTEMS > EXTERIOR/INTERIOR TRIM > Roof Rail.
2 Affected Products
Vehicle
| MAKE | MODEL | YEAR |
| SUBARU | OUTBACK | 2020-2021 |
1 Associated Document
Manufacturer Communications
NUMBER: 12-322-21
DATE: 08/25/21
https://www.nhtsa.gov/recalls?nhtsaId=10201049
MC-10201049-0001.pdf 1267.22KB
