Accessory Installation Guide
2022MY WRX Sport Grille | J1010VC120 |
Installation Manual
Genuine Part Number: J1010VC120(WRX)
Applicable Model: WRX 2022MY～
Installation Precautions
For your safety, important instructions that should be observed are shown with the following symbols in this Installation Manual.
Tools Required
Combination Wrench (10 mm), Phillips-head Screwdriver, Flathead Screwdriver, Torque Screwdriver, Clip Remover,
Protective Tape, and Blanket or Protective Sheet
2022MY WRX Sport Grille
J1010VC120
