NHTSA ID Number: 10187307
Manufacturer Communication Number: 06-59-17R
Summary
This Service Information bulletin announces availability of a new front brake pad shim kit to specifically address customer concerns of a squeaking or squealing sound on the models listed above.
NUMBER: 06-59-17R
DATE: 07/12/17
REVISED: 05/31/18
APPLICABILITY: | 2013-2015MY Legacy and Outback 2012-2016MY Impreza 2013-2017MY Crosstrek 2013-2017MY Forester 2015-2017MY WRX |
SUBJECT: | Brake Squeak or Squeal Sound, Brake Pad Shim Design Change |
INTRODUCTION:
This Service Information bulletin announces availability of a new front brake pad shim kit to specifically address customer concerns of a squeaking or squealing sound on the models listed above. The new shims incorporate a new laminated design with increased damping characteristics to eliminate vibration identified as the root cause of the sound. The new kits include shims only (NO brake pads).
PART INFORMATION:
Description | Part Number | Applicability |
SHIM-DISK KIT | 26298FJ000 | 2013MY Legacy / Outback, Impreza / Crosstrek and Forester w/ 15” and 16” brake |
26298SG000 | 2010-2014MY Legacy / Outback, WRX and Forester w/ 17” brake | |
2015MY Legacy / Outback w/ 17” brake |
SERVICE PROCEDURE / INFORMATION:
These shim kits are to be used to address specific customer concerns of brake squeaking or squealing. The installation procedure is unchanged from the currently applicable Service Manual.
24 Affected Products
Vehicles
MAKE | MODEL | YEAR |
SUBARU | CROSSTREK | 2013-2017 |
SUBARU | FORESTER | 2013-2017 |
SUBARU | IMPREZA | 2012-2016 |
SUBARU | LEGACY | 2013-2015 |
SUBARU | OUTBACK | 2013-2015 |
SUBARU | WRX | 2015-2017 |
1 Associated Document
Manufacturer Communications
NUMBER: 06-59-17R
DATE: 07/12/17
REVISED: 05/31/18
https://www.nhtsa.gov/recalls?nhtsaId=10187307
MC-10187307-0001.pdf 231.701KB
