NHTSA ID Number: 10202811
Manufacturer Communication Number: 15-287-21
Summary
This bulletin announces the availability of diagnostic information regarding accessory remote engine start systems.
NUMBER: 15-287-21
DATE: 10/08/21
INTRODUCTION:
This Service Information Bulletin announces the availability of diagnostic information regarding accessory remote engine start systems. This information is to be used with the remote engine start troubleshooting guides posted on STIS. The chart of troubleshooting videos included in this bulletin contains a breakdown of RES operation characteristics along with links to associated demonstration videos.
SERVICE / INFORMATION:
Diagnostic information can be found in the following RES Troubleshooting Guide list on STIS.
NOTES:
1. Additional information for Outback & Legacy can be found in TSB 15-258-19R.
2. DTC #U0254 can be set when a STARLINK remote start is requested on vehicles equipped with an accessory remote start system.
RES Troubleshooting Guides | |||
Year | Model | Ignition Type | Document Code # |
17-22 | Impreza | Key Start | TSG 900MHz KS |
18-22 | Crosstrek | ||
19-22 | Ascent | ||
19-22 | Forester | ||
20-22 | Legacy/Outback | ||
19-22 | Impreza | Push Start | TSG 900MHz PS |
19-22 | Crosstrek | ||
19-20 | Ascent | ||
20-22 | Legacy/Outback | ||
17-18 | Impreza | Push Start | TSG SFL PS |
18 | Crosstrek |
Subaru Remote Engine Start Troubleshooting Videos | |||
Video # | Video Link | Vehicle Response (# of Horn Honks) | Description |
1 | Remote Engine Start Shutdown – Door Open | One (1) Horn Honk for RES Activation
NO Horn Honks for RES Shut Down |
Reasons for RES Shutdown – Any Door Open |
2 | Remote Engine Start Shutdown – Over-rev Protection | One (1) Horn Honk for RES Activation
NO Horn Honks for RES Shut Down |
Reasons for RES Shutdown – RPMs > ~3,500 |
Subaru Remote Engine Start Troubleshooting Videos | |||
Video # | Video Link | Vehicle Response (# of Horn Honks) | Description |
3 | Prevent Remote Engine Start – Brake Switch | Two (2) Horn Honks | Reasons to Prevent RES –
Brake Pedal Depressed / Switch Active |
4 | Prevent Remote Engine Start – Door Open | Six (6) Horn Honks | Reasons to Prevent RES – Any Door Open |
5 | Prevent Remote Engine Start – Hood Switch | Two (2) Horn Honks | Reasons to Prevent RES – Hood Open / Switch Active |
6 | Prevent Remote Engine Start – Key In Ignition | Ignition Turns “ON”
Two (2) Horn Honks |
Reasons to Prevent RES – Key in Ignition Switch |
Subaru Remote Engine Start Troubleshooting Videos | |||
Video # | Video Link | Vehicle Response (# of Horn Honks) | Description |
7 | Prevent Remote Engine Start – Shifter Out of Park | Ignition Turns “ON”
Two (2) Horn Honks |
Reasons to Prevent RES – Gear Selector / Shifter out of Park |
8 | Subaru RES Selectable Run Time Programming | Four (4) Horn Honks to access Selectable Run Time Programming | RES Programming –
Selectable Run Time – 3, 5, 10 or 15 (Default) Minutes |
9 | Subaru RES Transmitter Programming | Three (3) Horn Honks to access RES Transmitter Programming | RES Programming –
Transmitter Learn Mode (Stores up to 8 Fobs) |
23 Affected Products
Vehicles
MAKE | MODEL | YEAR |
SUBARU | ASCENT | 2019-2022 |
SUBARU | CROSSTREK | 2018-2021 |
SUBARU | FORESTER | 2019-2021 |
SUBARU | IMPREZA | 2017-2022 |
SUBARU | LEGACY | 2020-2022 |
SUBARU | OUTBACK | 2020-2022 |
1 Associated Document
Manufacturer Communications
NUMBER: 15-287-21
DATE: 10/08/21
