NHTSA ID Number: 10235899
Manufacturer Communication Number: 078714
Summary
This bulletin provides information regarding design changes to the rear combination lamp assembly to prevent fogging and accumulation of condensation.
NUMBER: 07-87-14
DATE: 10/15/14
| APPLICABILITY: | 2014MY XV Crosstrek Hybrid (HEV) |
|---|---|
| SUBJECT: | Design Change of Rear Combination Lamps to Prevent Fogging and Condensation |
INTRODUCTION
This bulletin provides information regarding design changes to the rear combination lamp assembly to prevent fogging and accumulation of condensation. These changes involve:
- An Anti-Fog coating is now applied during production to the inner surface of the outer lens.
- Additional ventilation added to the bottom portion of the housing.
- Revised shape and locations for the 4 existing ventilation holes.
COUNTERMEASURE IN PRODUCTION
The revised rear combination lamps were incorporated into production during July, 2014 starting with VIN E*330494.
PART INFORMATION
| PART NUMBER | DESCRIPTION |
|---|---|
| 84912FJ320 | LENS & BODY COMPL |
| 84912FJ330 |
SERVICE PROCEDURE / INFORMATION
When replacing the combination lamp assembly, follow the procedure outlined in the applicable Service Manual. Only the affected side combination lamp should be replaced unless the condition has been confirmed on both.
1 Affected Product
Vehicle
| MAKE | MODEL | YEAR |
| SUBARU | XV CROSSTREK | 2014 |
1 Associated Document
Manufacturer Communications
NUMBER: 07-87-14
DATE: 10/15/14
https://www.nhtsa.gov/recalls?nhtsaId=10235899
MC-10235899-9999.pdf 422.295KB
Loading...
Reload document
Open in new tab
NHTSA ID Number: 10068635
Manufacturer Communication Number: 07-87-14
Summary
SUMMARY TO BE PROVIDED ON A FUTURE DATE.
1 Associated Document
Service Bulletin Document
NUMBER: 07-87-14
DATE: 10/15/14
https://www.nhtsa.gov/recalls?nhtsaId=10068635
SB-10068635-0699.pdf 422.295KB
