Accessory Installation Guide
2024MY Crosstrek Rear Bumper Cover | E771SFN000 |
INSTALLATION INSTRUCTIONS
PART NUMBER: E771SFN000
DESCRIPTION: REAR BUMPER COVER
NOTE:
- Do not wash the vehicle for 24 hours following installation of bumper cover.
- If bumper cover requires cleaning after installation, wipe with a soft cloth or sponge and mild soap and wipe thoroughly with a dry cloth. Do not use gasoline, thinner, acid, alkali or other solvent based products.
- The recommended adhesive surface temperature range is: 60°-110°F (15°- 43°C).
- If the surface temperature is below 60°F (15°C), heat the double sided tape and bumper surface to a temperature of 80°F (27°C).
- A one-hour cure time is recommended before exposing the vehicle to extreme temperatures (hot or cold).
- If templates are damaged or lost print template page as replacements.
REMARQUE:
- Ne pas laver le véhicule pendant 24 heures suivant I’installation du couvre pare-chocs.
- Si Ie couvre pare-chocs doit être nettoyé après l’installation, l’essuyer à l’aide d’une éponge ou d’un linge imbibé d’une solution de savon doux puis frotter avec un chiffon sec. Ne pas utilizer d’essence, de diluant, d’acide ou d’alcali ou d’autres prodults à base de solvant.
- La plage de température recommandée pour Ia surface adhésive est de 15 à 43°C (60 à 110°F).
- Si la température de Ia surface est sous 15°C (60°F), chauffer Ie ruban à double face et la surface du pare-chocs à une température de 27°C (80°F).
- Un temps de durcissement d’une heure est recommandé avant d’exposer le véhicule à des températures extrêmes (chaudes ou froid es).
- Si les modèles sont endommagés ou perdus, imprimez la page du modèle en remplacement.
PREPARATION: Park vehicle in well lit area. Open rear gate. Unpack parts. Read the entire installation instruction prior to beginning.
STEP 1: Clean any dirt, oil or wax from attaching area of bumper with a clean cloth and rubbing alcohol. Then prepare the surface with the supplied alcohol pads.
STEP 2: Note: If the temperature is below 60°F (15°C), heat the double sided tape and bumper surface to a temperature of 80°F (27°C).
STEP 3: DO NOT REMOVE ANY TAPE AT THIS TIME. Place part on rear bumper and roughly align the rear gate’s latch striker with the center triangle on the part. Then look under the hatch’s weather stripping for molded-in triangles in the rear bumper and align with the outboard triangles on the part. See detailed illustration below.
Inspect the gaps on all 4-sides and become familiar with the “home” position of this part.
STEP 4: While part is in the home position locate supplied left and right corner alignment templates. Using the part as a guide position the right then the left templates. Ensure templates are against back vertical wall and aligned with part profile, then tape down outside edges of templates.
STEP 5: Flip part over. Fold and crease the tape liners as shown in the illustration below. You may tape each liner to the top surface of the part (optional).
STEP 6: Reposition part onto rear bumper. Align again following STEP 3 and 4. Ensure each tape liner is positioned properly from STEP 5. Find the “home” position and inspect both sides of the part to ensure proper positioning then firmly hold in place.
STEP 7: While firmly holding the part with your left hand, use your right hand to gently pull the liner shown below by approximately 3″ (76mm) BUT DO NOT PRESS DOWN.
STEP 8: Press down on the part by a finger’s width only at the location shown below. Do not press down anywhere else but now lightly hold the part in place.
STEP 9: Gently pull the liner shown below by approximately 3″ (76mm) BUT DO NOT PRESS DOWN.
STEP 10: Carefully inspect and align (if necessary) the side of the part to the bumper and then press down on the part by a finger’s width only at the location shown below. Do not press down anywhere else.
STEP 11: Carefully and gently remove the entire tape liner section shown below. Pulling with too much force or too quickly can tear the tape liner. TIP: If liner tears, pull the other liner that is intact.
STEP 12: Use a towel and apply firm pressure (approximately 15lb. of force) to the area highlighted in yellow.
STEP 13: Gently pull the liner shown below by approximately 3″ (76mm) BUT DO NOT PRESS DOWN.
STEP 14: Press down on the part by a finger’s width only at the location shown below. Do not press down anywhere else.
STEP 15: Gently pull the liner shown below by approximately 3″ (76mm). BUT DO NOT PRESS DOWN.
STEP 16: Carefully inspect and align (if necessary) the side of the part to the bumper and then press down on the part by a finger’s width only at the location shown below. Do not press down anywhere else.
STEP 17: Carefully and gently remove the entire tape liner section shown below. Pulling with too much force or too quickly can tear the tape liner. TIP: If liner tears, pull the other liner that is intact.
STEP 18: Use a towel an apply firm pressure (approximately 15lbs. of force).
STEP 19: Carefully and gently remove the entire tape liner section shown below. Pulling with too much force or too quickly can tear the tape liner. TIP: If liner tears, pull the other liner that is intact.
STEP 20: Use a towel an apply firm pressure (approximately 15lbs. of force).
STEP 21: Carefully and gently remove the two tape liner sections shown below. Pulling with too much force or too quickly can tear the tape liner. TIP: If the liner tears, pull the same liner from the opposite direction. Then remove corner alignment templates.
STEP 22: Use a towel and apply firm pressure (approximately 15lbs of force) to the areas highlighted in yellow.
STEP 23: Inspect part for any areas not adhering to the bumper. Firmly pressed down as needed. Done.
