Accessory Installation Guide
2024MY Impreza Rear Bumper Appliqué | E771SFN200 |
INSTALLATION INSTRUCTIONS
PART NUMBER: E771SFN200
DESCRIPTION: Rear Bumper Applique
PREPARATION – BEFORE INSTALLATION:
- This product should be installed with proper installation tools.
- Install this product while observing all warnings and precautions stated in this instruction booklet.
- VERY IMPORTANT: Thoroughly wash vehicle with Soap and
Parts storage should be flat at room temperature and in a clean dry place. Care should be taken to avoid a dusty environment.
Notes to the Installer
- Read the entire installation instructions prior to beginning the installation of the accessory.
- Ensure that the vehicle is properly protected in the area that the accessory is to be installed.
- To prevent vehicle damage, never place tools on top of painted surfaces, seats, dash pad, console or floor carpet / mat.
- Always wear appropriate safety gear to include gloves and eye protection when required.
Rear Bumper Applique
1
Alcohol
Thoroughly wash vehicle with a soft lint-free cloth. Wipe the panel where the Bumper Applique will be installed with alcohol wipes.
Allow the area to dry completely.
2
Dry Fit
**Confirm that the rear bumper appliqué does not obstruct any of the Reverse Automatic Braking sensors.
Align the Bumper Applique into position using the handling tabs, door notches and panel edges as references. Locate center notch in the applique directly under the notches in bumper and align as shown above.
3
Separate Liner
Remove liner from Bumper Applique as shown. To prevent contamination, limit touching adhesive side of the Bumper Applique by using handling tabs.
Spray alcohol, soap and water application solution on adhesive side of applique.
4
Spray Bumper Surface
Spray the bumper surface with the application solution.
5
Applique Placement
While using the handling tabs align the Bumper Applique into position. This allows the part to float on the surface until proper fit is achieved. Locate center notch in the applique directly under the notches in bumper and align as shown above.
6
Squeegee Applique
Use caution not to scratch the paint surface with the squeegee.
Spray top surface of premask with an even mist of Application Solution. Using smooth even overlapping strokes to squeegee the Bumper Applique into position. Do not wrap the edge at this time.
7
Squeegee Applique
**Confirm that the rear bumper appliqué does not obstruct any of the Reverse Automatic Braking sensors.
Use caution not to scratch the paint surface with the squeegee.
Firmly squeegee over the corner edge of the bumper in the direction shown. Then, continue squeegeeing down past corner edge.
8
Remove Premask
Carefully remove the premask from the Bumper Applique by slowly lifting and pulling backward at an 180º angle as shown.
9
Inspect Applique
If bubbles are present after premask carrier removal, wrap a towel around the squeegee and carefully attempt to push the bubble to the side of the Bumper Applique. If the bubble cannot be moved, use a sewing needle to pierce the bubble and press the remaining solution from beneath the Bumper Applique.
Care and Cleaning
Wash bumper appliqué with warm soapy water as needed, (do not use other chemical based cleaners).
Visual Check
Make sure all edges are firmly adhered.
Confirm that the rear bumper appliqué does not obstruct any of the Reverse Automatic Braking sensors.
E771SFN200
