2024 Subaru Impreza Owner’s Manual

SEOCONTENT-START

s12 12-1. Specifications . 484 Dimensions 484 Engine 485 Fuel 485 Engine Oil 486 Front Differential and Rear Differential Gear Oil. 488 Fluids . 488 Engine Coolant. 489 Electrical System 489 Tires. 489 Brake Disc 490 12-2. Bulb Chart491 Safety Precautions . 491 Bulb Chart . 492 12-3. Vehicle Identification.494 12-4. Function Settings 495 Function Settings and Adjustments on the Center Information Display . 495 Individual Settings and Adjustments Excluding Center Information Display . 495 Function Settings and Adjustments Performed by a Dealer 495 Specifications 12 Specifications 12-1. Specifications s12aa These specifications are subject to change without notice. & Dimensions s12aa01 in (mm) Item Overall length 176.2 (4,475) Overall width 70.1 (1,780) Overall height 58.3 (1,480) Wheel base 105.1 (2,670) Tread Front 60.6 (1,540) Rear 60.8 (1,545) Ground clearance*1 5.1 (130) *1: Measured with vehicle empty 484 Specifications & Engine s12aa02 Engine model FB20 (2.0 L, DOHC, non-turbo) FB25 (2.5 L, DOHC, non-turbo) Engine type Horizontally opposed, liquid cooled 4 cylinder, 4 stroke direct injection gasoline engine Horizontally opposed, liquid cooled 4 cylinder, 4-stroke direct injection gasoline engine Displacement cu-in (cc) 122 (1,995) 152 (2,498) Bore 6 Stroke in (mm) 3.31 6 3.54 (84.0 6 90.0) 3.70 6 3.54 (94.0 6 90.0) Compression ratio 12.5 : 1 12.0 : 1 Firing order 1 – 3 – 2 – 4 1 – 3 – 2 – 4 & Fuel s12aa08 Fuel requirement Fuel tank capacity Unleaded gasoline with 87 AKI (90 RON) or higher 16.6 US gal (63 liters, 13.9 Imp gal) For more details, refer to “Fuel” P303. – CONTINUED – Specifications 485 12 Specifications & Engine Oil s12aa12 For the checking, adding and replacing procedure or other details, refer to “Engine Oil” P445. NOTE Have the procedure for changing the engine oil and oil filter performed by a properly-trained expert. It is recommended that you have this service performed by your SUBARU dealer. ! Approved engine oil s12aa1201 Always use the SUBARU approved engine oil. For further details, please contact your SUBARU dealer. If the approved engine oil is unavailable, use the alternative engine oil described on the next page. ! Alternative engine oil s12aa1202 If the SUBARU approved oil is unavailable, the following alternative oil can be used. NOTE . Each quantity indicated here is only a guideline. The necessary quantity for replacement may differ slightly depending on the temperature and other factors. . In choosing an oil, you want the proper quality and viscosity, as well as one that will enhance fuel economy. Oils of lower viscosity provide better fuel economy. However, in hot weather, oil of higher viscosity is required to properly lubricate the engine. The following table lists the recommended viscosities and applicable temperatures. . When adding oil, you may use different brands together as long as they are the same ILSAC and API classification and SAE viscosity as those recommended by SUBARU. 486 Specifications Oil grade SAE viscosity No. and applicable temperature Engine oil capacity ILSAC (International Lubricant Specification Advisory Committee) GF-6B, which can be identified with the ILSAC certification mark (Shield mark) 0W-16 synthetic oil is the required oil for optimum engine performance and protection. Conventional oil may be used if synthetic oil is unavailable. *: If 0W-16 synthetic oil is not available, 0W-20 conventional oil may be used if replenishment is needed but should be changed to 0W-16 synthetic oil at the next oil change. · Adding the oil from L to F level: 1.1 US qt (1.0 liters, 0.9 Imp qt) · Changing the oil and oil filter: 4.7 US qt (4.4 liters, 3.9 Imp qt) · Changing the oil: 4.4 US qt (4.2 liters, 3.7 Imp qt) ILSAC (International Lubricant Specification Advisory Committee) GF-6A, which can be identified with the ILSAC certification mark (Starburst mark) API (American Petroleum Institute) classification SP with the words “RESOURCE CONSERVING” – CONTINUED – Specifications 487 12 Specifications & Front Differential and Rear Differential Gear Oil s12aa13 Oil Front differential gear oil Rear differential gear oil Oil grade . SUBARU Extra MT*3 . API classification GL-5 (75W-90) API classification GL-5 (75W-90) Oil capacity*1 1.4 US qt (1.3 liters, 1.1 Imp qt) 0.8 US qt (0.8 liters, 0.7 Imp qt) Remarks*2 “Front Differential Gear Oil and Rear Differential Gear Oil” P452 *1: The indicated oil quantity is only a guideline. The necessary quantity for replacement may differ slightly depending on the temperature and other factors. Check the oil level after refilling the gearbox with oil. *2: For more details about maintenance and service, refer to the indicated section. *3: The vehicle is filled at the factory with this oil. & Fluids s12aa10 Fluid Fluid type*1 Fluid capacity*2 Remarks*3 Continuously variable transmission fluid Consult your SUBARU dealer. 2.0 L engine models: 10.8 US qt (10.2 liters, 9.0 Imp qt) 2.5 L engine models: 12.0 US qt (11.3 liters, 10.0 Imp qt) “Continuously Variable Transmission Fluid” P451 Brake fluid FMVSS No. 116, DOT 3 or DOT 4 brake fluid — “Brake Fluid” P452 *1: Use one of the indicated types of fluid. *2: The indicated fluid quantity is only a guideline. The necessary quantity for replacement may differ slightly depending on the temperature and other factors. *3: For more details about maintenance and service, refer to the indicated section. 488 Specifications & Engine Coolant s12aa11 Coolant capacity Coolant type 2.0 L engine models 8.4 US qt (7.9 liters, 7.0 Imp qt) SUBARU SUPER COOLANT 2.5 L engine models 8.9 US qt (8.4 liters, 7.4 Imp qt) The indicated coolant quantity is only a guideline. The necessary quantity for replacement may differ slightly depending on the temperature and other factors. For more details about maintenance and service, refer to “Cooling System” P447. & Electrical System s12aa03 Battery type Q-85 Alternator 2.0 L engine models 12 V 130 A 2.5 L engine models 12 V 150 A Spark plugs DILKAR7Q8 (NGK) & Tires s12aa05 Tire size 205/55R16 91V 205/50R17 89V P225/40R18 88V Wheel size 16 6 6 1/2 J 17 6 7 J 18 6 7 1/2 J Pressure Front 36 psi (250 kPa, 2.5 kgf/cm2) 33 psi (230 kPa, 2.3 kgf/cm2) Rear 35 psi (240 kPa, 2.4 kgf/cm2) 32 psi (220 kPa, 2.2 kgf/cm2) Wheel nut tightening torque 89 lbf·ft (120 N·m, 12 kgf·m)*1 *1: This torque is equivalent to applying approximately 88 to 110 lbf (40 to 50 kgf) at the end of the wheel nut wrench. If you have tightened the wheel nuts by yourself, have the tightening torque checked at the nearest automotive service facility as soon as possible. For the wheel nut tightening procedure, refer to “Replacement procedure” P462. – CONTINUED – Specifications 489 12 Specifications & Brake Disc s12aa18 If you need information on the usage limit value of brake discs and the method for measuring them, we recommend that you consult your SUBARU dealer. 490 Specifications 12-2. Bulb Chart s12ac & Safety Precautions s12ac03 WARNING Bulbs may become very hot while illuminated. Before replacing bulbs, turn off the lights and wait until the bulbs cool down. Otherwise, there is a risk of sustaining a burn injury. CAUTION Replace any bulb only with a new bulb of the specified wattage. Using a bulb of different wattage could result in a fire. – CONTINUED – Bulb Chart 491 12 Specifications & Bulb Chart s12ac04 NOTE Lights indicated by letters are the LED (Light Emitting Diode) type. Consult your SUBARU dealer for replacement. 492 Bulb Chart Wattage Bulb No. 1 Vanity mirror lights 12 V-2 W — 2 Map lights 12 V-8 W — 3 Dome light 12 V-8 W — 4 Front position lights (if equipped) 12 V-28 W/8 W 7444NA Front turn signal lights (if equipped) 12 V-28 W/8 W 7444NA 5 Front side marker light (if equipped) 12 V-5 W W5W 6 Backup light 12 V-16 W W16W 7 Cargo area light 12 V-5 W W5W 8 License plate lights 12 V-5 W W5W 9 Rear turn signal lights 12 V-21 W WY21W A Low and high beam headlights — — Daytime running lights — — B Front turn signal lights (if equipped) — — C Front fog lights (if equipped) — — D Front position lights (if equipped) — — Accessory lights (if equipped) — — E Front side marker lights (if equipped) — — F Side turn signal lights — — G High-mounted stop light — — H Stop lights — — I Tail and stop lights — — Rear side marker lights — — Bulb Chart 493 12 Specifications 12-3. Vehicle Identification s12ad 1 Vehicle identification number (under the floor carpet of the right-hand front seat) 2 Emission control label 3 Tire inflation pressure label (vehicle placard) 4 Certification label 5 Vehicle identification number 6 Model number label 7 Fuel label 8 Air conditioner label 494 Vehicle Identification 12-4. Function Settings s12ag & Function Settings and Adjustments on the Center Information Display s12ag01 Setting adjustments can be manually changed within the center information display to meet your personal requirements. Refer to “Center Information Display (CID)” P184. & Individual Settings and Adjustments Excluding Center Information Display s12ag02 For setting adjustments to the following items, refer to the appropriate page for details. Item Function Available settings Factory default setting Page Alarm system Alarm system Operation/Non-operation Operation 131 Remote keyless entry system Audible signal Operation/Non-operation Operation 122 & Function Settings and Adjustments Performed by a Dealer s12ag03 Item Function Available settings Factory default setting Alarm system Monitoring start delay time (after closing doors) 0 seconds/30 seconds 30 seconds Map lights/Dome light/Cargo area light illumination ON/OFF OFF Keyless access with push-button Audible signal volume*1 Level 1 to 7 Level 6 Remote keyless entry system Audible signal volume*1 Level 1 to 7 Level 6 Key lock-in prevention Key lock-in prevention Operation/Non-operation Operation Auto dimmer cancel Sensitivity of the operation of the auto dimmer cancel OFF/Min/Low/Mid/Hi/Max Mid High beam assist function High beam assist function Operation/Non-operation Operation – CONTINUED – Function Settings 495 12 Specifications Item Function Available settings Factory default setting Reverse gear interlocked rear wiper Reverse gear interlocked rear wiper operation Operation/Non-operation U.S.-spec. models: Non-operation Other models: Operation *1: The audible signal volume cannot be set under level 5 for the warning chime. 496 Function Settings s13 13-1. For U.S.A. 498 13-2. Tire Information 498 Tire Labeling 498 Recommended Tire Inflation Pressure. 500 Glossary of Tire Terminology 501 Tire Care – Maintenance and Safety Practices . 506 Vehicle Load Limit – How to Determine . 506 Determining Compatibility of Tire and Vehicle Load Capacities 509 Adverse Safety Consequences of Overloading on Handling and Stopping and on Tires 510 Steps for Determining Correct Load Limit. 510 13-3. Uniform Tire Quality Grading Standards.511 TREADWEAR . 511 TRACTION AA, A, B, C . 511 TEMPERATURE A, B, C 511 13-4. Reporting Safety Defects (USA).512 13-5. How to Contact Transport Canada in Order to Report a Safety Concern Relating to the Vehicle (Canada) .513 Consumer Information and Reporting Safety Defects 13 Consumer Information and Reporting Safety Defects 13-1. For U.S.A. s13aa The following information has been compiled according to Code of Federal Regulations “Title 49, Part 575”. 13-2. Tire Information s13ab & Tire Labeling s13ab01 Many markings (e.g. Tire size, Tire Identification Number or TIN) are placed on the sidewall of a tire by tire manufacturers. These marking can provide you with useful information on the tire. ! Tire size s13ab0101 Your vehicle comes equipped with P-Metric tire size. It is important to understand the sizing system in selecting the proper tire for your vehicles. Here is a brief review of the tire sizing system with a breakdown of its individual elements. ! P Metric s13ab010101 With the P-Metric system, Section Width is measured in millimeters. To convert millimeters into inches, divide by 25.4. The Aspect Ratio (Section Height divided by Section Width) helps provide more dimensional information about the tire size. Example: (1) P = Certain tire type used on light duty vehicles such as passenger cars (2) Section Width in millimeters (3) Aspect Ratio (= section height 7 section width). (4) R = Radial Construction (5) Rim diameter in inches ! Load and Speed Rating Descriptions s13ab010102 The load and speed rating descriptions will appear following the size designation. They provide two important facts about the tire. First, the number designation is its load index. Second, the letter designation indicates the tire’s speed rating. 498 For U.S.A. Example: (6) Load Index: A numerical code which specifies the maximum load a tire can carry at the speed indicated by its speed symbol, at maximum inflation pressure. For example, “91” means 1,356 lbs (615 kg), “90” means 1,323 lbs (600 kg), “89” means 1,279 lbs (580 kg) WARNING Load indices apply only to the tire, not to the vehicle. Putting a load rated tire on any vehicle does not mean the vehicle can be loaded up to the tire’s rated load. (7) Speed Rating: An alphabetical system describing a tire’s capability to travel at established and predetermined speeds. For example, “V” means 149 mph (240 km/h) WARNING . Speed ratings apply only to the tire, not to the vehicle. Putting a speed rated tire on any vehicle does not mean the vehicle can be operated at the tire’s rated speed. . The speed rating is void if the tires are worn out, damaged, repaired, retreaded, or otherwise altered from their original condition. If tires are repaired, retreaded, or otherwise altered, they may not be suitable for original equipment tire designed loads and speeds. ! Tire Identification Number (TIN) s13ab0102 Tire Identification Number (TIN) is marked on the intended outboard sidewall. Here is a brief review of the TIN with a breakdown of its individual elements. Type A (1) DOT symbol* (2) Manufacturer’s Identification Mark (3) Tire Size Code (4) Tire Type Code (5) Date of Manufacture The first two figures identify the week, starting with “01” to represent the first full week of the calendar year; the second two figures represent the year. For example, 0101 means the 1st week of 2001. *: The DOT symbol certifies that the tire conforms to applicable Federal Motor Vehicle Safety Standards. – CONTINUED – Tire Information 499 13 Consumer Information and Reporting Safety Defects Type B (1) DOT symbol* (2) Plant Code (3) Manufacturer’s Code (4) Date of Manufacture The first two figures identify the week, starting with “01” to represent the first full week of the calendar year; the second two figures represent the year. For example, 0101 means the 1st week of 2001. *: The DOT symbol certifies that the tire conforms to applicable Federal Motor Vehicle Safety Standards. ! Other markings s13ab0103 The following makings are also placed on the sidewall. ! Maximum permissible inflation pressure s13ab010301 The maximum cold inflation pressure to which this tire may be inflated. For example, “350 kPa (51 PSI) MAX. PRESS” ! Maximum load rating s13ab010302 The load rating at the maximum permissible weight load for this tire. For example, “MAX. LOAD 615 kg (1,356 LBS) @ 350 kPa (51 PSI) MAX. PRESS.” WARNING Maximum load rating applies only to the tire, not to the vehicle. Putting a load rated tire on any vehicle does not mean the vehicle can be loaded up to the tire’s rated load. ! Construction type s13ab010303 Applicable construction of this tire. For example, “TUBELESS STEEL BELTED RADIAL” ! Construction s13ab010304 The generic name of each cord material used in the plies (both sidewall and tread area) of this tire. For example, “PLIES: TREAD 2 STEEL + 2 POLYESTER + 1 NYLON SIDEWALL 2 POLYESTER” ! Uniform Tire Quality Grading (UTQG) s13ab010305 For details, refer to “Uniform Tire Quality Grading Standards” P511. & Recommended Tire Inflation Pressure s13ab02 ! Recommended cold tire inflation pressure s13ab0201 For the recommended cold tire inflation pressure for your vehicle’s tires, refer to “Tires” P489. 500 Tire Information ! Vehicle placard s13ab0202 The vehicle placard is affixed to the driver’s side B-pillar. Example: The vehicle placard shows original tire size, recommended cold tire inflation pressure on each tire at maximum loaded vehicle weight, seating capacity and loading information. ! Adverse safety consequences of under-inflation s13ab0203 Driving at high speeds with excessively low tire pressures can cause the tires to flex severely and to rapidly become hot. A sharp increase in temperature could cause tread separation, and failure of the tire(s). Possible resulting loss of vehicle control could lead to an accident. ! Measuring and adjusting air pressure to achieve proper inflation s13ab0204 Check and, if necessary, adjust the pressure of each tire (including the spare) at least once a month and before any long journey. Check the tire pressures when the tires are cold. Use a pressure gauge to adjust the tire pressures to the specific values. Driving even a short distance warms up the tires and increases the tire pressures. Also, the tire pressures are affected by the outside temperature. It is best to check tire pressure outdoors before driving the vehicle. When a tire becomes warm, the air inside it expands, causing the tire pressure to increase. Be careful not to mistakenly release air from a warm tire to reduce its pressure. & Glossary of Tire Terminology s13ab03 . Accessory weight The combined weight (in excess of those standard items which may be replaced) of automatic transmission, power steering, power brakes, power windows, power seats, radio, and heater, to the extent that these items are available as factory-installed equipment (whether installed or not). . Bead The part of the tire that is made of – CONTINUED – Tire Information 501 13 Consumer Information and Reporting Safety Defects steel wires, wrapped or reinforced by ply cords and that is shaped to fit the rim. . Bead separation A breakdown of the bond between components in the bead. . Bias ply tire A pneumatic tire in which the ply cords that extend to the beads are laid at alternate angles substantially less than 90 degrees to the centerline of the tread. . Carcass The tire structure, except tread and sidewall rubber which, when inflated, bears the load. . Chunking The breaking away of pieces of the tread or sidewall. . Cold tire pressure The pressure in a tire that has been driven less than 1 mile or has been standing for three hours or more. . Cord The strands forming the plies in the tire. . Cord separation The parting of cords from adjacent rubber compounds. . Cracking Any parting within the tread, sidewall, or inner liner of the tire extending to cord material. . Curb weight The weight of a motor vehicle with standard equipment including the maximum capacity of fuel, oil and coolant, and if so equipped, air conditioning and additional weight optional engine. . Extra load tire A tire designed to operate at higher loads and higher inflation pressure than the corresponding standard tire. . Groove The space between two adjacent tread ribs. . Innerliner The layer(s) forming the inside surface of a tubeless tire that contains the inflating medium within the tire. . Innerliner separation The parting of the innerliner from cord material in the carcass. . Intended outboard sidewall (1) The sidewall that contains a whitewall, bears white lettering or bears manufacturer, brand, and/or model name molding that is higher or deeper than the same molding on the other sidewall of the tire, or (2) The outward facing sidewall of an asymmetrical tire that has a particular side that must always face outward when mounting on a vehicle. . Light truck (LT) tire A tire designated by its manufacturer as primarily intended for use on lightweight trucks or multipurpose passenger vehicles. . Load rating The maximum load that a tire is rated to carry for a given inflation pressure. 502 Tire Information . Maximum inflation pressure The maximum cold inflation pressure to which a tire may be inflated. . Maximum load rating The load rating for a tire at the maximum permissible inflation pressure for that tire. . Maximum loaded vehicle weight The sum of: (a) Curb weight (b) Accessory weight (c) Vehicle capacity weight (d) Production options weight . Maximum permissible inflation pressure The maximum cold inflation pressure to which a tire may be inflated. . Measuring rim The rim on which a tire is fitted for physical dimension requirements. . Normal occupant weight 150 lbs (68 kg) times the number of occupants specified in the second column of Table 1 that is appended to the end of this section. . Occupant distribution Distribution of occupants in a vehicle as specified in the third column of Table 1 that is appended to the end of this section. . Open splice Any parting at any junction of tread, sidewall, or innerliner that extends to cord material. . Outer diameter The overall diameter of an inflated new tire. . Overall width The linear distance between the exteriors of the sidewalls of an inflated tire, including elevations due to labeling, decorations, or protective bands or ribs. . Passenger car tire A tire intended for use on passenger cars, multipurpose passenger vehicles, and trucks, that have a gross vehicle weight rating (GVWR) of 10,000 lbs (4,535 kg) or less. . Ply A layer of rubber-coated parallel cords. . Ply separation A parting of rubber compound between adjacent plies. . Pneumatic tire A mechanical device made of rubber, chemicals, fabric and steel or other materials, that, when mounted on an automotive wheel, provides the traction and contains the gas or fluid that sustains the load. . Production options weight The combined weight of those installed regular production options weighing over 5.1 lbs (2.3 kg) in excess of those standard items which they replace, not previously considered in curb weight or accessory weight, including heavy duty brakes, ride levelers, roof rack, heavy duty battery, and special trim. . Radial ply tire A pneumatic tire in which the ply cords that extend to the beads are laid at substantially 90 degrees to the centerline of the tread. . Recommended inflation pressure The cold inflation pressure recom- – CONTINUED – Tire Information 503 13 Consumer Information and Reporting Safety Defects mended by a vehicle manufacturer. . Reinforced tire A tire designed to operate at higher loads and at higher inflation pressures than the corresponding standard tire. . Rim A metal support for a tire or a tire and tube assembly upon which the tire beads are seated. . Rim diameter Nominal diameter of the bead seat. . Rim size designation Rim diameter and width. . Rim type designation The industry of manufacturer’s designation for a rim by style or code. . Rim width Nominal distance between rim flanges. . Section width The linear distance between the exteriors of the sidewalls of an inflated tire, excluding elevations due to labeling, decoration, or protective bands. . Sidewall That portion of a tire between the tread and bead. . Sidewall separation The parting of the rubber compound from the cord material in the sidewall. . Snow tire A tire that attains a traction index equal to or greater than 110, compared to the ASTM E1136-93 Standard Reference Test Tire, when using the snow traction test as described in ASTM F-1805-00, Standard Test Method for Single Wheel Driving Traction in a Straight Line on Snow-and Ice-Covered Surfaces, and that is marked with an Alpine Symbol “ ” on at least one sidewall. . Test rim The rim on which a tire is fitted for testing, and it may be any rim listed as appropriate for use with that tire. . Tread That portion of a tire that comes into contact with the road. . Tread rib A tread section running circumferentially around a tire. . Tread separation Pulling away of the tread from the tire carcass. . Treadwear indicators (TWI) The projections within the principal grooves designed to give a visual indication of the degrees of wear of the tread. . Vehicle capacity weight The rated cargo and luggage load plus 150 lbs (68 kg) times the vehicle’s designated seating capacity. . Vehicle maximum load on the tire Load on an individual tire that is determined by distributing to each axle its share of the maximum loaded vehicle weight and dividing by two. . Vehicle normal load on the tire Load on an individual tire that is determined by distributing to each axle its share of the curb weight, accessory weight, and normal oc- 504 Tire Information cupant weight (distributed in accordance with Table 1 that is appended to the end of this section) and dividing by 2. . Wheel-holding fixture The fixture used to hold the wheel and tire assembly securely during testing. Table 1 — Occupant loading and distribution for vehicle normal load for various designated seating capacities Designated seating capacity, number of occupants Vehicle normal load, number of occupants Occupant distribution in a normally loaded vehicle 2 through 4 2 2 in front. 5 through 10 3 2 in front, 1 in second seat. 11 through 15 5 2 in front, 1 in second seat, 1 in third seat, 1 in fourth seat. 16 through 22 7 2 in front, 2 in second seat, 2 in third seat, 1 in fourth seat. – CONTINUED – Tire Information 505 13 Consumer Information and Reporting Safety Defects & Tire Care – Maintenance and Safety Practices s13ab04 . Check on a daily basis that the tires are free from serious damage, nails, and stones. At the same time, check the tires for abnormal wear. . Inspect the tire tread regularly and replace the tires before their tread wear indicators become visible. When a tire’s tread wear indicator becomes visible, the tire is worn beyond the acceptable limit and must be replaced immediately. With a tire in this condition, driving at even low speeds in wet weather can cause the vehicle to hydroplane. Possible resulting loss of vehicle control can lead to an accident. . To maximize the life of each tire and ensure that the tires wear uniformly, it is best to rotate the tires every 6,000 miles (10,000 km). For details about tire rotation, refer to “Tire Rotation” P460. Replace any damaged or unevenly worn tire at the time of rotation. After tire rotation, adjust the tire pressures and make sure the wheel nuts are correctly tightened. For information about the tightening torque and tightening sequence for the wheel nuts, refer to “Tire Replacement” P461. & Vehicle Load Limit – How to Determine s13ab05 The load capacity of your vehicle is determined by weight, not by available cargo space. The load limit of your vehicle is shown on the vehicle placard attached to the driver’s side B-pillar. Locate the statement “The combined weight of occupants and cargo should never exceed XXX kg or XXX lbs” on your vehicle’s placard. The vehicle placard also shows seating capacity of your vehicle. The total load capacity includes the total weight of driver and all passengers and their belongings, any cargo, any optional equipment such as a trailer hitch, roof rack or bike carrier, etc., and the tongue load of a trailer. Therefore cargo capacity can be calculated by the following method. Cargo capacity = Load limit − (total weight of occupants + total weight of optional equipment + tongue load of a trailer (if applicable)) ! Calculating total and load capacities varying seating configurations s13ab0501 Calculate the available load capacity as shown in the following examples: 506 Tire Information Example 1A Vehicle capacity weight of the vehicle is 800 lbs (363 kg), which is indicated on the vehicle placard with the statement “The combined weight of occupants and cargo should never exceed 363 kg or 800 lbs”. For example, if the vehicle has one occupant weighing 154 lbs (70 kg) plus cargo weighing 551 lbs (250 kg). 1. Calculate the total weight. 2. Calculate the available load capacity by subtracting the total weight from the vehicle capacity weight of 800 lbs (363 kg). 3. The result of step 2 shows that a further 95 lbs (43 kg) of cargo can be carried. Example 1B For example, if a person weighing 176 lbs (80 kg) now enters the same vehicle (bringing the number of occupants to two), the calculations are as follows: 1. Calculate the total weight. – CONTINUED – Tire Information 507 13 Consumer Information and Reporting Safety Defects 2. Calculate the available load capacity. 3. The total weight now exceeds the capacity weight by 81 lbs (37 kg), so the cargo weight must be reduced by 81 lbs (37 kg) or more. Example 2A CAUTION Your vehicle is neither designed nor intended to be used for trailer towing. Therefore, never tow a trailer with your vehicle. Vehicle capacity weight of the vehicle is 800 lbs (363 kg), which is indicated on the vehicle placard with the statement “The combined weight of occupants and cargo should never exceed 363 kg or 800 lbs”. For example, the vehicle has one occupant weighing 165 lbs (75 kg) plus cargo weighing 265 lbs (120 kg). In addition, the vehicle is fitted with a trailer hitch weighing 22 lbs (10 kg), to which is attached a trailer weighing 1,764 lbs (800 kg). 10% of the trailer weight is applied to the trailer tongue (i.e. Tongue load = 176 lbs (80 kg)). 1. Calculate the total weight. 2. Calculate the available load capacity. 3. The result of step 2 shows that a further 172 lbs (78 kg) of cargo can be carried. 508 Tire Information Example 2B CAUTION Your vehicle is neither designed nor intended to be used for trailer towing. Therefore, never tow a trailer with your vehicle. For example, if a person weighing 143 lbs (65 kg) and a child weighing 40 lbs (18 kg) now enter the same vehicle (bringing the number of occupants to three), and a child restraint system weighing 11 lbs (5 kg) is installed in the vehicle for the child to use, the calculations are as follows: 1. Calculate the total weight. 2. Calculate the available load capacity. 3. The total weight now exceeds the capacity weight by 22 lbs (10 kg), so the cargo weight must be reduced by 22 lbs (10 kg) or more. & Determining Compatibility of Tire and Vehicle Load Capacities s13ab06 The sum of four tires’ maximum load ratings must exceed the maximum loaded vehicle weight (“GVWR”). In addition, sum of the maximum load ratings of two front tires and of two rear tires must exceed each axle’s maximum loaded capacity (“GAWR”). Original equipment tires are designed to fulfill those conditions. The maximum loaded vehicle weight is referred to Gross Vehicle Weight Rating (GVWR). And each axle’s maximum loaded capacity is referred to Gross Axle Weight Rating (GAWR). The GVWR and each axle’s GAWR are shown on the vehicle certification label affixed to the driver’s door. The GVWR and front and rear GAWRs are determined by not only – CONTINUED – Tire Information 509 13 Consumer Information and Reporting Safety Defects the maximum load rating of tires but also loaded capacities of the vehicle’s suspension, axles and other parts of the body. Therefore, this means that the vehicle cannot necessarily be loaded up to the tire’s maximum load rating on the tire sidewall. & Adverse Safety Consequences of Overloading on Handling and Stopping and on Tires s13ab07 Overloading could affect vehicle handling, stopping distance, vehicle and tire as shown in the following. This could lead to an accident and possibly result in severe personal injury. . Vehicle stability will deteriorate. . Heavy and/or high-mounted loads could increase the risk of rollover. . Stopping distance will increase. . Brakes could overheat and fail. . Suspension, bearings, axles and other parts of the body could break or experience accelerated wear that will shorten vehicle life. . Tires could fail. . Tread separation could occur. . Tire could separate from its rim. & Steps for Determining Correct Load Limit s13ab08 1. Locate the statement “The combined weight of occupants and cargo should never exceed XXX kg or XXX lbs.” on your vehicle’s placard. 2. Determine the combined weight of the driver and passengers that will be riding in your vehicle. 3. Subtract the combined weight of the driver and passengers from XXX kg or XXX lbs. 4. The resulting figure equals the available amount of cargo and luggage load capacity. For example, if the “XXX” amount equals 1,400 lbs (635 kg) and there will be five 150 lbs (68 kg) passengers in your vehicle, the amount of available cargo and luggage load capacity is 650 lbs (1,400 − 750 (5 6 150) = 650 lbs). 5. Determine the combined weight of luggage and cargo being loaded on the vehicle. That weight may not safely exceed the available cargo and luggage load capacity calculated in Step 4. 6. If your vehicle will be towing a trailer, load from your trailer will be transferred to your vehicle. Consult this manual to determine how this reduces the available cargo and luggage load capacity of your vehicle. 510 Tire Information 13-3. Uniform Tire Quality Grading Standards s13ac This information indicates the relative performance of passenger car tires in the area of treadwear, traction, and temperature resistance. This is to aid the consumer in making an informed choice in the purchase of tires. Quality grades can be found where applicable on the tire sidewall between tread shoulder and maximum section width. For example: TREADWEAR 200 TRACTION AA TEMPERATURE A The quality grades apply to new pneumatic tires for use on passenger cars. However, they do not apply to deep tread, winter type snow tires, space-saver or temporary use spare tires, tires with nominal rim diameters of 12 inches or less, or to some limited production tires. All passenger car tires must conform to Federal Safety Requirements in addition to these grades. & TREADWEAR s13ac02 The treadwear grade is a comparative rating based on the wear rate of the tire when tested under controlled conditions on a specified government test course. For example, a tire graded 150 would wear one and one-half (1- 1/2) times as well on the government course as a tire graded 100. The relative performance of tires depends upon the actual conditions of their use, however, and may depart significantly from the norm due to variations in driving habits, service practices and differences in road characteristics and climate. & TRACTION AA, A, B, C s13ac03 The traction grades, from highest to lowest, are AA, A, B and C. Those grades represent the tire’s ability to stop on wet pavement as measured under controlled conditions on specified government test surfaces of asphalt and concrete. A tire marked C may have poor traction performance. WARNING The traction grade assigned to this tire is based on straightahead braking traction tests, and does not include acceleration, cornering, hydroplaning, or peak traction characteristics. & TEMPERATURE A, B, C s13ac04 The temperature grades are A (the highest), B, and C, representing the tire’s resistance to the generation of heat and its ability to dissipate heat when tested under controlled conditions on a specified indoor laboratory test wheel. Sustained high temperature can cause the material of the tire to degenerate and reduce tire life, and excessive temperature – CONTINUED – Uniform Tire Quality Grading Standards 511 13 Consumer Information and Reporting Safety Defects can lead to sudden tire failure. The grade C corresponds to a level of performance which all passenger car tires must meet under the Federal Motor Vehicle Safety Standard No. 109. Grades B and A represent higher levels of performance on the laboratory test wheel than the minimum required by law. WARNING The temperature grade for this tire is established for a tire that is properly inflated and not overloaded. Excessive speed, underinflation, or exc
