NHTSA ID Number: 10228780
Manufacturer Communication Number: 15-302-22R
Summary
This bulletin contains illustrations of exchange components and their manufacturer as well as a description of the proper exchange procedure.
INTRODUCTION
This bulletin contains illustrations of exchange components and their manufacturer as well as a description of the proper exchange procedure. The exchange program policy can also be found in Sections 8.4.9 and 11.2.10 of your Claims Policies and Procedures Manual found in Subarunet.
CONTENTS
Within the terms of the Basic New Car Warranty and the one year Replacement Parts Warranty, the Exchange Program provides for replacement of a defective unit from the manufacturer.
In the event the vehicle is “New” and “In-stock”,call the Vendor’s Service Center prior to calling Subaru Retailer Claims. A new unit will be supplied rather than a remanufactured unit. If the Vendor Service Center is unable to provide a new unit, immediately contact a Subaru Retailer Claims Specialist at 1-866-782-2782 prior to placing an order for further instructions.
The replacement of a new unit, other than new units supplied through the exchange program, requires authorization from a Subaru of America, Inc. Retailer Claims Specialist at 1-866-782-2782. An authorization code will be provided and must be included upon claim submission.
Vehicles that have been placed in demo service should use exchange units only.
11 Affected Products
Vehicles
MAKE | MODEL | YEAR |
SUBARU | ASCENT | 2023 |
SUBARU | BRZ | 2023 |
SUBARU | CROSSTREK | 2023 |
SUBARU | CROSSTREK HYBRID | 2023 |
SUBARU | FORESTER | 2023 |
SUBARU | IMPREZA | 2023 |
SUBARU | LEGACY | 2023 |
SUBARU | OUTBACK | 2023 |
SUBARU | SOLTERRA | 2023 |
SUBARU | WRX | 2023 |
SUBARU | XV CROSSTREK | 2023 |
1 Associated Document
Manufacturer Communications
NUMBER: 15-302-22R
DATE: 08/23/22
REVISED: 12/09/22
https://www.nhtsa.gov/recalls?nhtsaId=10228780
MC-10228780-0001.pdf 2456.367KB
MC-10228780-0001
