April 7, 2023 NHTSA CAMPAIGN NUMBER: 23V258000
Damaged Tire Bead May Cause Loss of Air Pressure
A damaged tire may experience a sudden loss of air pressure, increasing the risk of a crash.
NHTSA Campaign Number: 23V258
Manufacturer Subaru of America, Inc.
Components TIRES
Potential Number of Units Affected 4,409
Summary
Subaru of America, Inc. (Subaru
) is recalling certain 2023 Ascent vehicles equipped with 20-inch wheels. The internal tire bead may have been damaged during the wheel mounting process.
Remedy
Dealers will replace all four tires, free of charge. Owner notification letters are expected to be mailed June 6, 2023. Owners may contact Subaru’s customer service at 1-844-373-6614. Subaru
’s number for this recall is WRH-23.
Notes
Owners may also contact the National Highway Traffic Safety Administration Vehicle Safety Hotline at 1-888-327-4236 (TTY 1-800-424-9153), or go to www.nhtsa.gov.
Check if your Subaru has a Recall
NUMBER: WRH-23R
DATE: 04/07/23
REVISED: 02/06/24
NHTSA ID: 23V258
APPLICABILITY: | 2023MY Ascent |
SUBJECT: | Safety Recall/STOP SALE – Tire Bead Damage |
Subaru of America, Inc. (Subaru
) is initiating a new safety recall and stop sale for certain 2023 model year Ascent vehicles equipped with 20-inch wheels.
Description of the Defect and Safety Risk
The vehicles included in this recall/stop sale may be equipped with tires that were damaged during the wheel mounting and assembly process. A misaligned bead guide arm on the tire mounting equipment may have caused excessive stress on the tire bead during mounting, possibly causing damage to the internal structure of the tire.
Internal damage to the tire bead may lead to structural failure of the tire and rapid tire deflation, increasing the risk of a crash.
Remedy
For all potentially affected vehicles, Subaru retailers will remove and replace all four tires with new ones at no cost to the customer. All removed tires should be rendered unusable and be disposed of according to local regulations.
Affected Vehicles
A total of 4,409 U.S. Subaru Ascent vehicles will be affected by this recall, as listed below:
Model Year | Carline | Production Date Range |
2023 | Ascent (w/20” wheels) | December 1, 2022 – January 5, 2023 |
Not all vehicles in the production date range listed above are affected by this recall. Coverage must be confirmed by using the Vehicle Coverage Inquiry function on subarunet.com prior to repair. This information is now available.
Retailer Responsibility
Please be advised that it is a violation of Federal law for a dealer to deliver a new motor vehicle covered by a recall under a sale or lease until the defect is remedied. Therefore, any Authorized Subaru Retailer failing to perform the applicable service procedures to correct all affected vehicles in their inventory prior to the vehicle being placed in service may be subject to civil penalties of up to $22,423 per violation (i.e., for each vehicle), as provided in 49 CFR §578.6 and will also be in breach of the Subaru
Dealer Agreement.
Any vehicles listed in any recall/campaign that are in retailer stock must be:
- Immediately identified
- Tagged or otherwise marked to prevent their delivery or use prior to repair
- Repaired in accordance with the repair procedures outlined in the Product Campaign Bulletin
Retailers are to promptly perform the applicable service procedures, to correct all affected vehicles in their inventory (used, demo & SSLP). Whenever a vehicle subject to this recall is taken into retailer inventory necessary steps should be taken to ensure the recall correction has been made before selling or releasing the vehicle.
Owner Notification
Subaru will notify affected vehicle owners by first class mail in May. Retailers will be notified when the owner notification has been scheduled.
PART INFORMATION:
The tires are to be ordered using the normal ordering process through the Subaru Tire Center.
Part Description | Part Number | Quantity |
FALKEN ZIEX ZE001 A/S 245/50/20 | 45HR0ZE001ASV2 | 4 |
SERVICE PROCEDURE / INFORMATION:
STEP 1: Using a wax pen or tape, mark the position of ALL four wheels.
STEP 2: Replace ALL four tires following the Service Procedures supplied in the applicable Service Manual.
STEP 3: Using a unibit, drill bit, or hole saw, CAREFULLY drill one hole in the sidewall of ALL four tires above the DOT number. It is important to perform this step to confirm the tires cannot be re-used in any way. See the example images below.
STEP 4: CONFIRM ALL the wheel nuts are torqued in a star pattern to 120 Nm (12.2kgf-m, 88.5ft-lb).
IMPORTANT:
- The Tire Pressure Monitor System (TPMS) re-registration is NOT REQUIRED after tire replacement. The only exception to this is if a TPMS sensor requires replacement. In that case, follow the TPMS registration procedure supplied in the applicable Service Manual.
- Perform a road test when the repair is complete to confirm there are no TPMS or sound issues.
SERVICE PROGRAM IDENTIFICATION LABEL:
Type or print the necessary information on a Campaign Identification Label. The completed label should be attached to the vehicle’s upper radiator support.
IMPORTANT SAFETY RECALL
This notice applies to the VIN below
Subaru Safety Recall WRH-23
NHTSA Recall ID 23V-258
May 2023
Dear Subaru Owner:
This notice is sent to you in accordance with the National Traffic and Motor Vehicle Safety Act.
SUBARU OF AMERICA, INC. has decided that a defect, which relates to motor vehicle safety, exists in certain 2023 model year Ascent vehicles equipped with 20-inch wheels.
You received this notice because our records indicate that you currently own one of these vehicles.
DESCRIPTION OF THE DEFECT AND SAFETY RISK
Your vehicle may be equipped with tires that were damaged during the wheel mounting and assembly process. A misaligned bead guide arm on the tire mounting equipment may have caused excessive stress on the tire bead during mounting, possibly causing damage to the internal structure of the tire.
Internal damage to the tire bead may lead to structural failure of the tire and rapid tire deflation, increasing the risk of a crash.
WHAT SUBARU WILL DO
Subaru will remove and replace all four tires with new ones at no cost to you.
WHAT YOU SHOULD DO
You should contact any authorized Subaru retailer (dealer) to have this repair performed.
HOW LONG WILL THE REPAIR TAKE?
The time required for this repair is one hour. Your retailer can provide you with a better estimate of the overall time for this service visit, as it may be necessary to make your vehicle available for a longer period of time for scheduling purposes.
OWNER INFORMATION
Government regulations require that recall notifications be sent to the last known owner of record. That information is based primarily on state registration and title data. If you are a lessor of this vehicle, federal regulations require you to forward this notice to your lessee within ten days.
If you have moved or sold your vehicle, please update this information online at https://www.subaru. com/support/customer-support.html.
IF YOU HAVE PREVIOUSLY PAID FOR A REPAIR
If you have already paid for repairs associated with this condition, you may be eligible for reimbursement. Reimbursement consideration will be based on the amount an authorized Subaru retailer in your area would charge for the same repair.
Please send the original service repair order, which has the name of the repair facility, date of repair, mileage at the time of repair, complete 17-digit vehicle identification number (VIN), and your name, with correct mailing address and telephone number to the address listed below:
Subaru of America, Inc.
Customer Advocacy Department, Attention: WRH-23 Recall
P.O. Box 9103, Camden, NJ 08101-9877
Please send original receipts only and retain a photocopy for your records. Please be assured that we will attempt to process your reimbursement request as quickly as possible, but it may take up to 60 days for this process to be completed.
IF YOU NEED FURTHER ASSISTANCE
To locate the nearest Subaru retailer, you can access our website at www.subaru.com and select ‘Find a Retailer.’
For additional information, please go to: http://www.wrh23.service-campaign.com.
If you need additional assistance, please contact us directly:
- By e-mail: https://www.subaru.com/support/customer-support.html
- By telephone: 1-844-373-6614
Monday through Friday between 8:00 a.m. and 7:00 p.m. ET
- By U.S. Postal mail: Write us at Subaru
of America, Inc.
Attn: Customer Advocacy Department
P.O. Box 9103, Camden, NJ 08101-9877
To subscribe to the NHTSA Recall Notification email System, please go to: https://www-odi.nhtsa. dot.gov/nhtsa/subscriptions.
Please contact us immediately if the Subaru retailer fails or is unable to make the necessary repairs free of charge.
You may also contact the Administrator, National Highway Traffic Safety Administration (NHTSA),
1200 New Jersey Ave., SE, Washington, DC 20590 or call the toll-free Vehicle Safety Hotline at 1-888-327-4236 (TTY: 1-800-424-9153) or go to http://www.safercar.gov if you believe the Subaru retailer has failed or is unable to remedy your vehicle without charge within a reasonable amount of time.
Your continued satisfaction with your Subaru is important to us. Please understand that we have taken this action in the interest of your safety and your vehicle’s proper operation. We sincerely apologize for any inconvenience this matter may cause and urge you to schedule an appointment as soon as possible.
Sincerely,
Subaru of America, Inc.
A subsidiary of SUBARU CORPORATION
Chronology :
February 17, 2023 – Subaru received a technical report based on a reported flat tire where the technician noted a break in the sidewall. Subaru
opened an investigation.
March 2023 – The results of the investigation indicated that the tire bead was being over stressed during the tire/wheel mounting process. Further investigation found that the bead guide arm on a piece of tire mounting equipment had been out of alignment from December 5, 2022, to January 10, 2023, when it was repaired after the condition was identified during routine inspection.
March 31, 2023 – Subaru decided to conduct a voluntary safety recall. Subaru
is only aware of 10 technical reports in the U.S. market between February 17, 2023 and March 31, 2023. Subaru
is not aware of any crashes or injuries resulting from this condition
1 Affected Product
Vehicle
MAKE | MODEL | YEAR |
SUBARU![]() | ASCENT | 2023 |
10 Associated Documents
Recall Acknowledgement
RCAK-23V258-5859.pdf 645.793KB
Subaru – WRH23 Subarunet Announcement – April 2023
Defect Notice 573 Report
RCLRPT-23V258-9387.PDF 216.852KB
Remedy Instructions and TSB
RCRIT-23V258-2492.pdf 573.885KB
Subaru – WRH23 Subarunet Announcement – April 2023
RCMN-23V258-9595.pdf 185.291KB
ISSUED Owner Notification Letter(Part 577)
RCONL-23V258-5156.pdf 159.369KB
Remedy Instructions and TSB
RCRIT-23V258-9458.pdf 706.981KB
Recall Quarterly Report #3, 2023-4
RCLQRT-23V258-8605.PDF 211.48KB
Remedy Instructions and TSB
RCRIT-23V258-4242.pdf 647.808KB
Recall Quarterly Report #4, 2024-1
RCLQRT-23V258-7191.PDF 211.578KB
Latest Recalls Documents
NHTSA ID Number: 10235299
Manufacturer Communication Number: SubaruNet Announ
Summary
UPDATE Safety Recall/STOP SALE: WRH-23 Tire Bead Damage.
1 Associated Document
Manufacturer Communications
Date: April 28, 2023
UPDATE Safety Recall/STOP SALE: WRH-23 Tire Bead Damage
MC-10235299-0001.pdf 185.291KB
NHTSA ID Number: 10235276
Manufacturer Communication Number: SubaruNet Announ
Summary
Subaru of America, Inc. (Subaru
) is initiating a new safety recall and stop sale for certain 2023 model year Ascent vehicles equipped with 20-inch wheels.
1 Associated Document
Manufacturer Communications
Date: April 5, 2023
New Safety Recall/STOP SALE: WRH-23 Tire Bead Damage
MC-10235276-0001.pdf 288.933KB
NHTSA ID Number: 10238466
Manufacturer Communication Number: WRH-23R
Summary
Subaru of America, Inc. (Subaru
) is initiating a new safety recall and stop sale for certain 2023 model year Ascent vehicles equipped with 20-inch wheels.
1 Associated Document
Manufacturer Communications
NUMBER: WRH-23R
DATE: 04/07/23
NHTSA ID: 23V258
MC-10238466-0001.pdf 706.981KB
NHTSA ID Number: 10235286
Manufacturer Communication Number: WRH-23
Summary
Subaru of America, Inc. (Subaru
) is initiating a new safety recall and stop sale for certain 2023 model year Ascent vehicles equipped with 20-inch wheels.
1 Associated Document
Manufacturer Communications
NUMBER: WRH-23
DATE: 04/07/23
NHTSA ID: TBD
MC-10235286-0001.pdf 573.885KB
