NHTSA ID Number: 10232875
Manufacturer Communication Number: 1513108R
Summary
Rear Door Wheel Arch Molding
NUMBER: 15-131-08R
DATE: 08/20/08
REVISED: 02/22/13
APPLICABILITY: | 2009-2013MY Forester |
SUBJECT: | Rear Door Wheel Arch Molding |
INTRODUCTION
In the event you encounter a customer complaint that the rear door wheel arch molding is loose, there is the possibility that the 3M™ Tape which attaches the molding has not adhered properly. Please use the following repair procedure for replacing the molding(s).
PART INFORMATION
PART NAME | PART NUMBER |
Molding Rear Door LH | E201SSC030 |
Molding Rear Door RH | E201SSC060 |
REPAIR PROCEDURE / INSTRUCTIONS
IMPORTANT INSTALLATION TIPS
DO NOT:
- Apply Parts to surface that are not thoroughly cleaned.
- Install parts if the temperature is less than 60 degrees or more than 110 degrees Fahrenheit.
- Apply less than 30 PSI to 3M Tape surfaces for less than 30 seconds.
- Install using other adhesives or epoxy not listed in the instructions.
DO:
- Make sure all installation surfaces are clean, free of dirt, grease and debris.
- Make sure all vehicle surfaces are between 60 and 110 degrees Fahrenheit, to allow for proper 3M Tape adhesion.
- Only use 3M Tape as indicated in installation instructions.
- Apply 30 psi to all 3M tape surfaces for a minimum of 30 seconds.
- Allow 24 hours for maximum bond.
CAUTION: If proper application pressure and time requirements are not followed, the part will not adhere properly to the vehicle!
Removal Procedure
1) Remove loose wheel arch molding.
2) Remove all adhesive residue using 3M™ Stripe Off Wheel (PN 07499) or equivalent.
3) Use 3M™ General Purpose Adhesive Remover, or equivalent, to remove any remaining adhesive.
4) Clean surface thoroughly.
1 Use an alcohol wipe to clean surfaces at areas of tape (shown below). NOTE: It is very important that the surface is clean and has a surface temperature between 60°F & 110°F.
2 Open door. Hold Inner Door Piece on door, door, aligning edge of door with alignment tab on inner door piece.
3 Align inner edge on door edge as shown.
4 While holding the properly aligned part to door, peel the two 1/2” tape liners on vehicle side and press part into place, focusing on shaded area (shown below), using 30 psi of pressure over the entire length of the part, holding for 30 seconds in each location.
Shaded area indicates portion of part to have pressure applied.
5 Break alignment tab. Trim with utility knife along scoring line if necessary.
Proper Adhesion Procedure
1) Pull Backing Tape.
2) Press (30 psi / 30 sec. min.)
3) Pull Backing Tape.
4) Press (30 psi / 30 sec. min.)
5) Pull Backing tape.
6) Press (30 psi / 30 sec. min.)
7) Pull remaining Backing Tape.
8) Press remaining areas (30 psi / 30 sec. min.)
a. Press lower section to adhere lower tape.
b. Press upper section to adhere upper tape.
6 Ensure inner structure is adhered and placed properly. Position outer door piece over inner door piece. Align flare with door edge as shown in picture below. Avoid rolling part over door seam radius).
Peel liner from 114″ tape while pressing upward on inner edge of part.
Tape contact and good pressure along all areas between parts is critical.
Align edges of inner and outer door pieces and press together along edge while removing tape liner.
Tape contact and good pressure along all areas between parts is critical.
Verify position, and peel liners from remaining tape pieces. Press part into place, applying 30 PSI of pressure for a minimum of 30 seconds in each location. Allow 24 hours for maximum bond.
Tape contact and good pressure along all areas between parts is critical.
Note: Check for interface between the door piece and the door seal by slowly pushing the door shut. If necessary, adjust door seal by pushing it up towards the body.
5 Affected Products
Vehicle
MAKE | MODEL | YEAR |
SUBARU | FORESTER | 2009-2013 |
1 Associated Document
Manufacturer Communications
NUMBER: 15-131-08R
DATE: 08/20/08
REVISED: 02/22/13
https://www.nhtsa.gov/recalls?nhtsaId=10232875
MC-10232875-9999.pdf 978.545KB
