NHTSA ID Number: 10234946
Manufacturer Communication Number: RegistrationManu
Summary
Manual for immobilizer
1 IMPORTANT – 3
2 Immobilizer Application Chart – 4
3 What to Prepare – 4
3-1 Special Tool – 4
3-2 Others – 4
4 A type – 5
4-1 Registering Immobilizer Key – 6
4-2 Immobilizer system: Correspondence table at the time of parts lost or failure – 11
4-3 Correspondence table when registration is not possible – 12
5 B type – 14
5-1 Adding Keys – 15
5-2 Registering Body Integrated Unit – 18
5-3 Registering Engine ECM – 21
5-4 Registering Combination Meter or Security CU – 22
5-5 Registering Remote Control Engine Starter – 24
5-6 Deleting Key ID – 25
5-7 Immobilizer system: Correspondence table at the time of parts lost or failure – 28
5-8 Correspondence table when registration is not possible – 31
6 C type – 37
6-1 Adding Access Keys – 39
6-2 Registering Collation CU – 42
6-3 Registering the Steering Lock CU or ID Code Box – 46
6-4 Registering the Engine ECM – 49
6-5 Readout the Number of Access Key Registration – 51
6-6 Delete the Access Key ID – 52
6-7 Registering Remote Control Engine Starter – 55
6-8 Registering Body Integrated Unit or Combination Meter – 57
6-9 Keyless access with push button start system (except for North America): Correspondence table at the time of parts failure – 58
6-10 Correspondence table when registration is not possible – 65
7 D type – 74
7-1 Adding Access Keys – 76
7-2 Registering Keyless Access CU – 78
7-3 Registering the Steering Lock CU or ID Code Box – 81
7-4 Registering the Engine ECM – 83
7-5 Readout the Number of Access Key Registration – 84
7-6 Delete the Access Key ID – 86
7-7 Registering Remote Control Engine Starter – 88
7-8 Reading Registration History – 89
7-9 Keyless access with push button start system (when ID code box (U.K./CANADA)) : Correspondence table at the time of parts failure – 91
7-10 Keyless access with push button start system (when no ID code box (except for U.K./CANADA)): Correspondence table at the time of parts failure – 94
7-11 Correspondence table when registration is not possible – 96
7-12 List of registration history – 106
7-13 ID Code Box (With ID code box) – 109
8 E type – 110
8-1 Registering Immobilizer CM – 111
8-2 Adding Keys – 114
8-3 Registering Engine ECM – 117
8-4 Registering Remote Control Engine Starter – 119
8-5 Deleting Key ID – 121
8-6 Immobilizer system (when Immobilizer CU (U.K./CANADA)) : Correspondence table at the time of parts lost or failure – 124
8-7 Correspondence table when registration is not possible – 125
8-8 Immobilizer control module – 128
1 Affected Product
Vehicle
MAKE | MODEL | YEAR |
SUBARU | SUBARU | 9999 |
1 Associated Document
Manufacturer Communications
REGISTRATION MANUAL FOR IMMOBILIZER
https://www.nhtsa.gov/recalls?nhtsaId=10234946
MC-10234946-9999.pdf 8412.303KB
