Sport Grille – 2025 Subaru Forester

SEOCONTENT-START

1 GG219–02670 Thank you for purchasing the Subaru Genuine Sport Grille. This manual describes the procedure to install the Sport Grille on the FORESTER. Be sure to read this manual before installing this product and follow the instructions described below. Genuine Part Number Applicable Model Sport Grille Installation Manual Component Parts △ 00 Sport Grille No. Part Name Quantity Sport Grille 1 Camera Cover 1 Screws #4 × 12 mm 2 1 3 2 1 2 3 J1010SL000 FORESTER 2025MY～ 2 Make sure to arrange vehicle parts by part when removing them s o that you do not lose the tapping screws, nuts and bolts, and so you do not mistaken them when reinstalling the vehicle components. Also, pay due attention not to damage the vehicle and the removed parts during work.⑵⑴Park the vehicle on a level place, apply the parking brake, and use wheel chocks.To prevent damage to the vehicle and vehicle parts when removing vehicle parts and installing the product, be sure to perform the work on a Protective Sheet.⑷Follow the Service Manual when handling the battery.⑶Follow the Service Manual when performing the work.Installation PrecautionsClicksNOTECAUTIONInstallation of Parts●Use the proper size of tools.●Pay attention to the back side and do not allowany wire harness to get caught.After Completion of Installation●Be sure to reassemble all the vehicle parts thathave been removed.……This refers to situations in which injury may occur or property may be damaged if the caution instructions are not followed.For your safety, important instructions that should be observed are shown with the following symbols in this Installation Manual.……This denotes things that you should be made aware of so you can do the work quickly.CAUTION Tools Required Philips screwdriver, Flat head screwdriver, Torque check screwd river, clip removal tool, Needle nose pliers, Protection tape, Waste cloth, De-greasing agent 3 1. Applying Protective Tape ⑴ Apply Protective Tape to the shaded area in the figure. ⑵ Repeat the same procedure for the right side. Protective Tape Protective Tape Protective Tape The figure shows the left side. TG-CT-A01 Post-installation Diagram Installation Procedure 1Sport Grille 4 3. Removing the Front Bumper ⑴ Pull out the Headlamp Washer Nozzle, disengage the Claw, and remove the cover. ⑵ Repeat the same procedure for the right side. 2. Detaching the Camera Harness ⑴ Disconnect the Connector on the Camera Harness. Camera Harness Connector TG-CT-A06 Claw Cover Headlamp Washer Nozzle Protective Tape Flathead Screwdriver The figure shows the left side. Cover TG-CT-A02 ⑶ Remove Plastic Clips A (4 pcs) that secure the Front Bumper and Fender Molding. ⑷ Repeat the same procedure for the right side. Front Bumper The figure shows the left side. Fender Moulding Plastic Clip A x 4 TG-CT-A03 CAUTION Unless otherwise stated, the removed vehicle parts will be reused, so be careful not to misplace them. (Adopt this practice throughout the rest of the procedure) 5 ⑺ Remove Bolt (1 pc) and Plastic Clips (15 pcs). ⑸ Disengage Clips (3 places) and Claws (4 places) and allow Fender Moulding to rise up on front side of vehicle. ⑹ Repeat the same procedure for the right side. Front Bumper Bolt Plastic Clip B x 15 TG-CT-A04 ⑻ Pull back the Mudguard and disconnect the Fog Lamp Connector. ⑼ Repeat the same procedure for the right side. Fog Lamp Connector Mudguard Pull back The figure shows the left side. TG-CT-A07 If Clips remain on vehicle, remove them using a Clip Remover, etc. and attach to Fender Moulding before restoring to original position. N O T E Clip x 3 Front Bumper The figure shows the left side. Fender Moulding Claw x 4 Claw Cross-section Push TG-CT-A08 6 ⑴ Be sure to remove or install the Front Bumper above a blanket or Protective Sheet so that it will not get scratched. (Adopt this practice throughout the rest of the procedure) ⑵ Use needle nose pliers to gently pinch the sides of the clips or flat head screwdriver to pry each side out. Be careful not to damage the clip. ⑶ Protect the Camera with a blanket or the like so that it does not get scratched. 4. Removing the Camera ⑴ Remove the Screws (2 pcs). ⑵ Disengage the Clips (2 places) and Guide (1 place), and remove the Camera from the Front Grille. Guide Camera Harness Front Grille (vehicle part) Screw x 2 Camera ASSY Clip x 2 TG-CT-B01 5. Removing the Front Grille ⑴ Remove the Screws (2 pcs). ⑵ Disengage the Claws (8 places) and remove the Front Grille (vehicle part). Front Grille (vehicle part) will not be used again. Claw cross-section Front Grille (vehicle part) 􁵮􁶓􁶑􁶆 Front Bumper (Back side) Screw x 2 Claw x 8 TG-CT-B02 Be sure to remove or install the Front Bumper above a blanket or Protective Sheet so that it will not get scratched. (Adopt this practice throughout the rest of the procedure) ⑽ Disengage the Claws (18 places) and remove Claw x 9 the Front Bumper. (same on RH side) Front Bumper Blanket or Protective Sheet TG-CT-A05 ⑴ Be careful not to break the harness when removing the Front Bumper. ⑵ Place the Front Bumper on a blanket or Protective Sheet so that it will not get scratched. CAUTION CAUTION CAUTION N O T E 7 6. Installing the Sport Grille ⑴ Engage the Claws (8 places) to attach 1 Sport Grille to the Front Bumper. ⑵ Affix the 1 Sport Grille using Screws (2 pcs). Claw cross-section Front Bumper (Back side) Screw x 2 Claw x 8 1Sport Grille TG-CT-B03 7. Installing the Camera ⑴ Attach the Camera Assy to the 1 Sport Grille using Screws (2 pcs). Tightening torque:1.1 N･m ± 0.2 ⑵ Engage the Clips (2 places) and Guide (1 place), and then secure the Camera Harness. 1Sport Grille Screw x 2 Guide Camera Harness Camera ASSY Clip x 2 TG-CT-B04 8. Installing the Camera Cover ⑴ Attach the 2 Camera Cover to the 1 Sport Grille using 3 Screws (2 pcs). Tightening torque:1.1 N･m ± 0.2 1Sport Grille Screw x 2 2Camera Cover TG-CT-B05 Reuse the vehicle screws (2 pcs). Do not use the 3 Screws (2 pcs) included with the product. Use the 2 Camera Cover and 3 Screws (2 pcs) included with the product. Tightening the screw with an electric drill or another tool with a high torque specification may damage the screw, so use a Phillips-head Screwdriver to tighten the screw by hand. (FYI:Tightening torque = 1.5 N･m ± 0.3) CAUTION CAUTION CAUTION 8 ⑴ Check that the Front Bumper Claws are set in the correct position before pushing them in to engage them. Not doing so may damage the Front Bumper. ⑵ For vehicles with a camera, face the camera harness toward the engine room so that you will be able to connect it. 9. Reinstalling the Front Bumper ⑴ Engage the Claws (18 places) and reinstall the Front Bumper. Camera Harness (only vehicles with a camera) Claw x 9 (same on RH side) Front Bumper Blanket or Protective Sheet TG-CT-C06 ⑷ Secure the Front Bumper with Bolt (1 pc) and Plastic Clips B (15 pcs). Tightening torque: 7.5 Nm (0.8kgf-m, 5.5ft-lb) ⑵ Pull back the Mudguard and connect the Fog Lamp Connector. Fog Lamp Connector Mudguard Pull back The figure shows the left side. TG-CT-C07 Front Bumper Bolt Plastic Clip B x 15 TG-CT-C08 Check the orientation of the Fog Lamp Connector and insert it until it makes a clicking sound. The Fog Lamps will not turn on if the connector is not connected correctly. ⑶ Repeat the same procedure for the right side. CAUTION CAUTION 9 ⑺ Secure the Front Bumper and Fender Moulding with Plastic Clips A (4 pcs). ⑻ Repeat the same procedure for the right side. Front Bumper The figure shows the left side. Fender Moulding Plastic Clip A x 4 TG-CT-C09 ⑼ With the Head Lamp Washer Nozzle pulled out, engage the Claw to attach the cover. ⑽ Repeat the same procedure for the right side. The figure shows the left side. Claw Cover Headlamp Washer Nozzle Cover TG-CT-C10 ⑸ Engage Clips (3 places) and Claws (4 places) to restore Fender Moulding to original position on front side of vehicle. ⑹ Repeat the same procedure for the right side. Clip x 3 Front Bumper The figure shows the left side. Fender Moulding Claw x 4 TG-CT-C12 10 Camera Harness Connector TG-CT-C11 10. Connecting the Camera Harness ⑴ Connect the Camera Harness Connector. Revision History △ Description Revision Date △00 First version November 2023 ⑴ Remove all Protective Tape. ⑵ Follow the Service Manual when performing the work. ⑴ Check that the Fog Lamps turn on. ⑵ Check that the camera images are displayed correctly on the multifunction display. ⑶ Re-check that the Plastic Clips, Bolts and Screws are not loose and that parts are firmly secured and are not damaged or soiled. Post-installation Inspection Inspection Procedure

**************************************************************************************************************

**************************************************************************************************************
