Accessory Installation Guide
| 2025MY Forester – LED Door Projector Light | H4610SL100 |
DOOR PROJECTOR LIGHT
FORESTER 2025MY ～
Installation Manual
PART NO．H4610SL100
For installers
Important
・ We recommend that this product should be installed by a Subaru dealer. Damage and injury resulting from improper assembly will not be warranted.
・ When installing or removing vehicle parts, pay careful attention not to damage the parts.
・ Ensure that the harnesses are wired safely and properly so that a short circuit does not occur, for example, due to a contact with a sharp edge of a body panel.
・ For details on how to remove and install vehicle parts, refer to the service manual.
Warning・・・Be sure to observe the following for safety. Failure to observe these instructions could lead to danger to life or serious damage.
・ Perform this work in a suffi ciently spacious and fl at space while paying attention to safety. Also, perform this work with the shift knob in neutral or parking, the parking brake set, the engine stopped, and the key removed.
・ Avoid performing this work in an area exposed to rain, etc. Working with wet hands is very dangerous, as doing so could lead to an electric shock. Also, provide adequate ventilation and pay adequate attention to prevent accumulation of exhaust gas etc.
Caution・・・When using or installing this product, be sure to observe the following. Failure to observe these instructions could lead to product performance deterioration or property damage.
・ Before starting the work, be sure to disconnect the negative (-) battery terminals.
・ When disconnecting and connecting the connector, hold the connector and ensure to do so securely.
If the connector is not connected securely, the light may not come on.
・ When connecting the connector, secure the connector fi rmly by inserting it all the way.
・ Do not pull the harness with excessive force. Doing so may cause the terminal to come off , resulting in a contact failure. Also, wire the harness so that it is not caught in the moving part.
・ When removing or restoring the vehicle parts to their original states, follow the service manual.
・ When removing dirt on the product, wipe it off with sponge or other cloth dampened with neutral detergent.
Never use an organic solvent, such as thinner, or acid or alkaline cleaner.
H4610SL100
https://static.oemdtc.com/AccessoryInstallationGuide/H4610SL100.pdf
Loading...
Reload document
Open in new tab
- Note: Please Identify the Seller Eruseay !!! Customized for SUBARU Forester/Outback /Legacy/XV/Impreza /Tribeca/Ascent . Integrally injection-molded, will not separate and deform during installation.
- HIGH DEFINITION AND BRIGHT PROJECTION - This door light sign projector is powered by a 12V power cord and uses a high brightness LED chip. When you open the door, the light passes through 6 layers of ultra-high definition precision lenses to project a bright and vivid courtesy welcome sign on the floor.
- Built-in Smart Chip- The LED Ghost Projector uses the latest automotive decoding circuit chip that will not conflict with your car's software. Uses high quality circuit boards and parts that can carry more current. Adopt high brightness Cree LED chip with waterproof, shockproof and anti-corrosion ABS flame retardant housing, strong and durable, high temperature and pressure resistant, better protect the lens and internal chip circuit.
- Easy to install - plug and play! No drilling, no wiring, no disassembly, no damage to your car. Specially designed for Subaru car tuning and enthusiasts. The old lights just need to be pried forward gently, and the new lights can be stuck in place by hand.
- Note: The original position of the car does not have a light position or not energized, you need to add a line modification.
- 【Compatible for】Forester Fourth generation 2013-2017 SJ,Forester Fifth generation 2018-PRESENT SK
- 【Super cool 】When the door is opened, the Forester LOGO is illuminated onto the open door surface to provide a light to aid entry into and out of the vehicle.
- 【Easy to install】 Direct Replacement. No modifications required. No wire cutting. Please kindly confirm your original car door light can be powered before purchasing.
- 【Product Features】 High-brightness led door projection lamp, to show your car a bright, clear and color-fast logo projection
- 【After sale】 If there are any problems with our products, just feel free to contact us.
- 【Compatibility】1.Forester Fourth generation 2013-2017 SJ Fifth generation 2018-PRESENT SK 2.Outback, 4th Gen/5th Gen 6th Gen 2009-2014 BR/BM, 2014-2019 BS, 2020-present BT 3.Ascent 2019-2022
- 2.【High Quality】Featuring high definition projection with a premium lens, these puddle lights offer a longer lifespan, brighter output, and lower power consumption. The high-brightness LED door projection lamp creates a bright and clear logo projection, making your car stand out.
- 【Easy to install】No modifications or wire cutting are required for installation. These car door logo lights are a direct replacement and require the car to have original door lights for compatibility.
- 【Super cool】When the door is opened, the logo is illuminated onto the open door surface for a super cool effect, making it a perfect choice for car enthusiasts who want to add a unique touch to their vehicle.
- 【After sale】We offer full after-sale support. If there are any problems with our products, please feel free to contact us.
- 【Compatible for】1.Forester Fourth generation 2013-2017 SJ Fifth generation 2018-PRESENT SK 2.Outback, 4th Gen/5th Gen 6th Gen 2009-2014 BR/BM, 2014-2019 BS, 2020-present BT
- 【Super cool 】When the door is opened, the LOGO is illuminated onto the open door surface to provide a light to aid entry into and out of the vehicle.
- 【Easy to install】 Direct Replacement. No modifications required. No wire cutting. Please kindly confirm your original car door light can be powered before purchasing.
- 【High-quality LED chip】 Very low power consumption, will not add burden to your car battery
- 【after-sales 】 If you have any questions or other questions about the product, please feel free to contact us, we will solve it for you immediately
- 🚗Compatibility：Our logo door lights fit for Forester Fourth generation 2013-2017 SJ,Forester Fifth generation 2018-PRESENT SK, Detailed compatible car models please refer to the description page. Please make sure your car has original door light at first.
- 🆒Attract people's attention and get surprises: LED welcome lights with cool Forester logo projectors enhance the luxury of the car and create a high-end fashion atmosphere. Perfect for surprising your family and friends during the holiday season.
- 🥇Convenient：Plug and play! No drilling, no wiring, no disassembly, and no damage to your car.
- 👍Built-in Smart Chip：The LED Ghost Projector uses the latest automotive decoding circuit chip that will not conflict with your car's software. Uses high quality circuit boards and parts that can carry more current. Adopt high brightness Cree LED chip with waterproof, shockproof and anti-corrosion ABS flame retardant housing, strong and durable, high temperature and pressure resistant, better protect the lens and internal chip circuit.
- ✅We offer a 30-day refund. If you have any problems, please feel free to contact us and all issues will be resolved within 24 hours.
- 【Compatible for】Forester 2013-present SJ/SK Outback 2015-present BS/BT Legacy 2010-present BM/BR/BN/BS/BW/BT XV 2012-2022
- 【Super cool 】When the door is opened, the LOGO is illuminated onto the open door surface to provide a light to aid entry into and out of the vehicle.
- 【Easy to install】 Direct Replacement. No modifications required. No wire cutting. Please kindly confirm your original car door light can be powered before purchasing.
- 【Product Features】 High-brightness led door projection lamp, to show your car a bright, clear and color-fast logo projection
- 【After sale】 If there are any problems with our products, just feel free to contact us.
- 【Compatibility】BRZ ZN6 2012-2020
- 【Never fade 】Never fade high brightness BRZ logo slides 2pcs set car door ghost shadow projector logo light ,High-brightness led door projection lamp, to show your car a bright, clear and color-fast logo projection
- 【Easy to install】 Direct Replacement. No modifications required. No wire cutting. Note: Before purchasing, you must first confirm whether the car has original door lights, if not, it is incompatible
- 【Super cool 】When the door is opened, the BRZ is illuminated onto the open door surface to provide a light to aid entry into and out of the vehicle.
- 【After sale】 If there are any problems with our products, just feel free to contact us.
- 🚗Why is it worth buying? ---Get rid of the batteries. Upgrade Rechargeable Wireless Car Door Courtesy Welcome Lights. It can be used for up to 50 days at a time.The holder and the lamp can be separated. Convenient to charge without dismantling, safe and convenient.
- 🚗Why you need it? ---The upgraded car projection lamp uses intelligent infrared sensor, which can turn off the light without installing a magnet in the door. Both automatically turn off when the distance from the obstacle is 1.5- 4 inch, and automatically light up when you open the door, make your car luxurious and unique, and also can be used as a car warning light to prevent accidents in the dark.
- 🚗How to Install? ---So easy! No drilling, no wiring. Just stick the light lamp on the door panel. The 3M sticker is super strong and durable. Not easy to fall down, only 1 minute.
- 🚗Best Cool Gift! ---When the door is opened, a super bright light source and clear logo is illuminated to the ground, super cool~ The image is crisp and the light is bright. Make your car the shiny and coolest car on the road. Show the lights in the dark! Trust me, that's amazing!
- 🚗What you get? ---Two LED car door lights (❗The pre-set logo is already installed in the machine!) and additional 5 pair cards with different patterns. LOWEEY Professional after-sales service. If you have any future questions, please contact us and we will handle them for you within 24 hours.
- 【Compatible for】2pcs Never fade colorful outback soeries logo car door ghost shadow projector logo light for Outback, 4th Gen/5th Gen 6th Gen 2009-2014 BR/BM, 2014-2019 BS, 2020-present BT
- 【EASY INSTALLATION】Plug and play! No drilling,no wiring no modification, just replace the old light directly,The colorful Door Light Signs Make Your Car More Attractive
- 【Product Features】High light transmittance three-layer combination lamp, triple filter, energy saving, environmental protection and high efficiency. Using high-quality quartz stone glass projection chips, the projection will be the brightest, clearest, and never fade.
- 【INSTALLATION EFFECT】When you open the car door,you will see the Bright and vivid outback logo light projects on the ground. it will be turn off when you close the door.
- 【after-sales 】 If you have any questions or other questions about the product, please feel free to contact us, we will solve it for you immediately
- 【Great Performance】:This door light logo projector has a built-in LED chip, ABS cover, HD translucent composite film with bright light output, high clarity, logo projection is clear and bright, and very low power consumption. There are two projection patterns: red American flag and black American flag, you can switch as often as you like.
- 【Easy Installation】:These door welcome lights are easy to install, with a wireless design that requires no drilling. The steps are as follows: 1. Adjust the position of the light and the distance between the magnet and the light; 2. Gently stick the marker light to the door and the magnet to the door sill, it is recommended to close the door when installing; 3. When the light separates from the magnet, the light will light up automatically. After adjusting the position, stick the light with the magnet tightly; 4. To avoid kicking the light when getting out of the car, it is recommended to install the welcome light near the seat back.
- 【Magnet Sensor Design】:The door light sign features a magnetic induction design. When you open the door (the light leaves the magnet), the projector will turn on automatically; when you close the door (the light overlaps the magnet), the projector will turn off automatically, which is very convenient.
- 【Widely Applications】:There are 2PCS projector lights in the package that can be installed on the left and right doors. The door sign light projector is compatible with most cars and SUVs, it is specially designed for car modification enthusiasts and will bring more driving pleasure to the driver. Please confirm that the inside and bottom of your door are flat before purchasing.
- 【Perfect Gift】:The car door welcome light makes your car artistic and atmospheric. The light is stable and constant, clear and soft, the lighting time is long, and the darker the environment the better the effect, it is a perfect gift for husband, wife, friends, father, son, and colleagues, and it can also be used as a Christmas gift, birthday gift, New Year's gift, Valentine's Day gift and so on.
Last update on 2024-04-21 / Affiliate links / Images from Amazon Product Advertising API
This product presentation was made with AAWP plugin.
SEOCONTENT-START
-1-
PART NO．H4610SL100
DOOR PROJECTOR LIGHT
PKI-0095-2
△ 00
Warning・・・Be sure to observe the following for safety. Failure to observe these instructions could lead to danger to life or serious damage.
・ Perform this work in a suffi ciently spacious and fl at space while paying attention to safety. Also, perform this
work with the shift knob in neutral or parking, the parking brake set, the engine stopped, and the key removed.
・ Avoid performing this work in an area exposed to rain, etc. Working with wet hands is very dangerous, as doing
so could lead to an electric shock. Also, provide adequate ventilation and pay adequate attention to prevent
accumulation of exhaust gas etc.
For installers
Important
・ We recommend that this product should be installed by a Subaru dealer. Damage and injury resulting from
improper assembly will not be warranted.
・ When installing or removing vehicle parts, pay careful attention not to damage the parts.
・ Ensure that the harnesses are wired safely and properly so that a short circuit does not occur, for example, due
to a contact with a sharp edge of a body panel.
・ For details on how to remove and install vehicle parts, refer to the service manual.
Caution・・・When using or installing this product, be sure to observe the following. Failure to observe these instructions could lead to
product performance deterioration or property damage.
・ Before starting the work, be sure to disconnect the negative (-) battery terminals.
・ When disconnecting and connecting the connector, hold the connector and ensure to do so securely.
If the connector is not connected securely, the light may not come on.
・ When connecting the connector, secure the connector fi rmly by inserting it all the way.
・ Do not pull the harness with excessive force. Doing so may cause the terminal to come off , resulting in a
contact failure. Also, wire the harness so that it is not caught in the moving part.
・ When removing or restoring the vehicle parts to their original states, follow the service manual.
・ When removing dirt on the product, wipe it off with sponge or other cloth dampened with neutral detergent.
Never use an organic solvent, such as thinner, or acid or alkaline cleaner.
Installation Manual
FORESTER 2025MY ～
-2-
○○○○ R
A14930-2000
○○○○ L
A14930-1000
NO.
①
②
Part name
DOOR PROJECTOR LIGHT L
DOOR PROJECTOR LIGHT R
Quantity
1
１
① ②
● Waste cloth ● fl at head screwdriver
Completion drawing
Components
DOOR PROJECTOR LIGHT
“L” mark indicated
on the backside
“R” mark indicated
on the backside
Tools
-3-
Confi rm L/R side is correct. Connect the
DOOR PROJECTOR LIGHT to the courtesy
lamp connector.
● L side：DOOR PROJECTOR LIGHT L
● R side：DOOR PROJECTOR LIGHT R
1
3
2
Courtesy lamp
Flat head screwdriver
Courtesy lamp
connector
DOOR PROJECTOR LIGHT L
L side door
L side door
Front of the
car body
Installation procedure
（1）Turn off the ignition switch.
（2）Disconnect the negative (-) battery terminal.
（1）Apply a waste cloth on a fl at head
screwdriver. Remove the courtesy lamp
by inserting the fl at head screwdriver into
the vehicle’s front side of the courtesy
lamp.
（2）Remove the connector from the courtesy
lamp.
When removing the vehicle parts, follow the
service manual and be careful not to scratch
or damage them.
-4-
4
5
6
7
Insert
②
①
Tab
Connect the negative (-) battery terminal.
Open the door and confi rm the DOOR
PROJECTOR LIGHT’s image is correctly
projected.
Confi rm the DOOR PROJECTOR LIGHT unit is securely fi xed to the door trim.
Open/close the door and check the DOOR PROJECTOR LIGHT unit does not contact
with the door-sill, does not move, or fall off .
L side R side
Door trim
DOOR PROJECTOR
LIGHT
Front of the
car body
Insert the DOOR PROJECTOR LIGHT into
the door trim. Ensure the front side tab is
locked at the correct position.
Repeat Steps 2 － 4 for the R Side Door.
-5-
△ Description Date
Revision History
△ 00 ・Initial release August 31, 2023
**************************************************************************************************************
**************************************************************************************************************
