Accessory Installation Guide
2025MY Forester – Moonroof Air Deflector | F5410SL000 |
Instruction Manual
PART NUMBER F5410SL000
APPLICABLE MODEL FORESTER
This instruction manual explains the installation procedure of the Moon roof Air Deflector.
Note
1. Before installing the Moonroof Air Deflector, read this manual thoroughly and install correctly.Never modify the product before the installation.
2. Descriptions under the caution mark in this instruction manual are for safety matters regarding the installation. Be sure to follow the cautions.
3. If any failure occurs by not following the caution, please note that we may not take any responsibility.
Precautions
1. Before start installing the Moonroof Air Deflector, fully open the moonroof. Then turn turn off the ignition switch and apply the parking brake securely.
2. Two people should be engaged in the installation.
3. The protect sheet is attached to the fastening surface between the product and the vehicle.
Before starting the installation, wipe the dirt, dust, and oil from the surface to attach the protect sheet with clean cloth. When wiped with cleaner, attached oil can be removed well.
4. The product is made of resin; therefore, handle carefully not to bend forcibly or make flaws.
5. After checking the installation, open/close the moonroof for several times in order to check that the smooth operation of the moon roof.
6. Do not use an automatic car-washing machine.
F5410SL000
https://static.oemdtc.com/AccessoryInstallationGuide/F5410SL000.pdf
- Genuine Subaru Moonroof Deflector
- F541SAN000
- Helps reduce wind noise and sun glare.
- 2020-2024 Outback
- 2020-2024 Legacy
- Genuine Subaru Moonroof Air Deflector
- F541SAL000
- Helps reduce wind noise and sun glare.
- 2015-2019 Legacy
- 2015-2019 Outback
- Genuine Subaru Moonroof Air Deflector
- F541SFN000
- 2024 Crosstrek Sport and Limited and Wilderness
- Helps reduce wind noise and sun glare.
- Genuine Subaru Moonroof Air Deflector
- F541SFJ000
- 2013-2017 CROSSTREK
- 2012-2016 IMPREZA
- 2012-2021 STI
- Genuine Subaru Moonroof Deflector
- F5410SJ010
- 2022 2023 2024 Forester
- Helps reduce wind noise and sun glare. Cannot be used in conjunction with the Extended Roof Cargo Carrier
- Genuine OEM
- High quality
- Dependability
- ⭐Looking for a way to enhance your driving experience? Look no further than our top-quality sunroof visor! ICBEAMER visor is specifically designed to improve your driving experience by providing a range of benefits that you won't find with any other product on the market.
- ⭐First and foremost, ICBEAMER visor is made from a durable, long-lasting material that can withstand even the toughest weather conditions. It's designed to resist the damaging effects of the sun's UV rays, as well as rain, wind, and other environmental factors that can take a toll on your vehicle over time.
- ⭐In addition to its durability, our visor is also incredibly easy to install. With no cutting or drilling required, you can have it up and running in just minutes, and with our step-by-step video instructions, you won't need any special tools or skills to get the job done right.
- ⭐Once installed, our sunroof visor will allow you to enjoy fresh air even on rainy days, thanks to its unique design that lets you leave your sunroof/moonroof open a few inches without getting wet. It also helps reduce wind noise, keeping your ride quiet and peaceful no matter how fast you're going.
- ⭐To ensure your complete satisfaction with our sunroof visor, we stand behind our product with a warranty that guarantees its quality and performance. If you experience any issues with your visor due to manufacturer defects, simply reach out to us and we'll make it right. Your satisfaction is our top priority, and we're committed to delivering a product that you'll love for years to come.
- ⭐⭐⭐Installation video available: Strongly recommend watch installation video before purchase.
- ⭐Installation Tips: Double side tape cannot be re-apply/re-adhere/reuse once it has been placed onto the vehicle. Position the sunroof visor and align it correctly before removing the red plastic. In-case place it wrong position will require to replace a brand new Double side tape to re-adhere.
- ⭐Feature: Long lasting material designed to withstand the rigors of the elements, 5. Make it possible to leave the sunroof/moon roof open a few inches to get fresh air even on rainy days.
- ⭐Direct tape on OEM style design. No Cutting & No Drilling (High quality Double side tape included).
- ⭐Made of Top Quality Acrylic in Dark Smoke Color UV-resistant Material & Improve Safer Driving. Reduce Wind, Noise & Keep Rain Out. 5 times longer life than other PVC
- FITMENT: This Roof Visor Can Only Fit The Sunroof/Moonroof Which Is Not Wider Than 41.8".Please Measure The Size Of The Sunroof/Moonroof On Your Vehicle First And Make Sure This Is The Correct Item Before Purchase!
- PACKAGE INCLUDED: 1pc 43" (41.8" between the inner edge) universal roof visor(Installation instruction is included,Please read User Instruction before installation)
- DURABLE AND NICE: Our Vent Deflector made with Hardy&Shatterproof premium-quality reinforced acrylic,will not bend, break or crack. Dark smoke colored streamlined flexible design is chosen finest for sun protection,also adding to the appearance of your precious!
- MAKE TRAVEL ENJOYABLE AND SAFE: You can drive in comfort with our rain guards, without worrying about the noisy wind, chilly snow, annoying rain sprays,blazing sunshine. It help improve ventilation to reduce window fogging keep sight clearly make rides safe.
- EASY INSTALLATION:Direct Tape-On design,easy Peel-N-Stick installation and no disturbed in the windows up and down.Easy to remove will not affect your car appearance(No Cutting & No Drilling)
- ✔️ 【Custom-fit Window Visors Rain Guards & Sunroof Compatible with Subaru Forester (2009-2013)】: Ensures A Best Fit And Seamless Integration With Your Specific Vehicle Model. Important: For Proper Sunroof Visors Fit, Measure Your Sunroof And Leave a 1-inch Space On Each Side.
- ☑️ 【Dark-Smoke Reinforced Acrylic & Improved Ventilation】: Rain Guards For Car Windows Offers A Stylish Look And Enhanced Durability For Long-lasting Use. Car Window Visor Reduces Heat Buildup And Allows Fresh Air Circulation Even When Windows Are Partially Open, Keeping Rain Out.
- ☑️ 【Strong, One-Time Application】: For Best Fit, Take Your Time Positioning the Sunroof Visor Before Removing The Red Tape Backing. Our Double-sided Tape Is Designed For a Secure, Long-lasting Bond. Tip: Double-check the Placement Before Applying For Optimal Results.
- ☑️ 【Reduces Wind Noise & Rain Deflection】: Enjoy A Quieter, More Comfortable Ride With Protection From Rain Showers. This Weatherproof Sun Visor Deflects Noise In Windy Weather, Crafted From UV-resistant Material For Lasting Protection.
- ☑️ 【Guaranteed 100% Color Fade Resistance & Easy, No-drill Installation】: Rain Visor For Car Window Maintains A Sleek, Smoke-tinted Appearance, Even With Extended Sun Exposure.. Window Deflectors Attached Securely Using Pre-applied, Automotive-grade Double-sided Tape For a Hassle-free Application.
Last update on 2024-04-16 / Affiliate links / Images from Amazon Product Advertising API
This product presentation was made with AAWP plugin.
SEOCONTENT-START
SUBARU
Moonroof Air Deflector
Instructio
PART NUMBER APPLICABLE MODEL
F5410SL000 FORESTER
Manual
This instruction manual explains the installation procedure of the Moonroof Air Deflector. Note
1. Before installing the Moonroof Air Deflector, read this manual thoroughly and install correctly.Never modify the product before the installation.
2. Descriptions under the &caution mark in this instruction manual are for safety matters regarding the installation. Be sure to follow the cautions.
3. If any failure occurs by not following the caution, please note that we may not take any responsibility.
&
Precautions
1. Before start installing the Moonroof Air Deflector, fully open the moonroof. Then turn turn off the ignition switch and apply the parking brake securely.
2. Two people should be engaged in the installation.
3. The protect sheet is attached to the fastening surface between the product and the vehicle. Before starting the installation, wipe the dirt, dust, and oil from the surface to attach the protect sheet with clean cloth. When wiped with cleaner, attached oil can be removed
well.
4. The product is made of resin; therefore, handle carefully not to bend forcibly or make flaws.
5. After checking the installation, open/close the moonroof for several times in order to check that the smooth operation of the moonroof.
6. Do not use an automatic car-washing machine. Component tr D No.
G) (2)
@ @ @ @ (l) Part Moonroof Air Deflector Front fixing bracket Side fixing bracket Screw (with screw lock) Nut
Pattern sheet Protect sheet Quantity 1
2
2
4
4
1
4 Repair part number Tools
– Cleaner
– Cloth
– Scale
– Masking tape
– Scissors
– Wrench ( 9/32″ (7mm] )
– Phillips-head screw driver (with torque control function) Outline drawing of product
Moonroof Air Deflector
jj> & Caution
Tips for installation – Park the vehicle at a flat and sufficiently large place for the safe operation.
– Stop the engine, activate the parking brake, and keep the vehicle in a stable condition while operating.
– Cut the Pattern sheet in advance. In addition, the Pattern sheets are for both right side and left side. Check the indications on the Pattern sheets and use for both sides. igure 1] 1. Preparation before installation
(1) Fully open the moonroof and turn off the ignition switch.
(2) Keep the deflector downward by using both hands. [Figure 1]
& Caution
· The deflector moves up if the hands holding the deflector are released. Conduct the operations by keeping the deflector pressed down. 2 E-69 2. Attachment of the protect sheet
(1) Cut the Pattern sheets G) and (2) by the line on the Pattern sheet by using scissors.
(2) Press the Pattern sheet G) against the moonroof opening edge along the indicated line on the Pattern sheet G) .
(3) Attach the protect sheet by aligning the upper corner to the position instructed on the Pattern sheet for the right and the left position, and by aligning to the moonroof R-end for the up and down position. (Four sections) The figure indicates the left side. [Figure 2] [Figure 2] 3. Temporary fixing of the front fixing bracket
(1) Align the front fixing bracket to the center of the protect sheet. At that time, push in the lower edge of the protect sheet to inside of the vehicle roof by using the front fixing bracket. (Two sections) [Figure 3]
(2) Raise the front fixing bracket and hook to the lower edge of the flange. Temporarily fix with the masking tape. (Two sections) [Figure 3] [Figure 3] 3 E-69 (3) Align the Pattern sheet® against the moonroof opening edge according to the indication on the Pattern sheet®·
Fix with the masking tape. [Figure 4]
(4) Apply masking tape for initial positioning e to the vehicle in accordance with the front
terminal of the fixed stencil®· [Figure 4]
(5) Remove the Pattern sheet®· Screw
(with screw lock) become symmetric. [Figure 4] (6) Mount the Moonroof Air Deflector on the vehicle roof. Align the Moonroof Air Deflector mounting hole and the front fixing bracket mounting hole.
Temporarily fix with the screw (with screw lock) and the nut.
Remove the masking tape attached on the front fixing bracket. (Two sections) Nut Phillips screwdriver nroof Deflector Masking tape [Figure 5]
& Caution
· When temporary tightening of the nut is difficult, move the Moonroof Air Deflector backward a little and fix temporarily. Then, align to the standard position. [Figure 5] (7) Align the front end of the rubber trim edge to the masking tape attached on the vehicle. [Figure 6] [Figure 6] 4 E-69 roof
ector
4. Positioning of the Moonroof Air Deflector
(1) Align the Moonroof Air Deflector against the moonroof opening section so its position becomes symmetric. [Figure 7] Side fixing
b p
s R-end [Figure 7] oonroof
r Deflector king 5. Temporary fixing of the side fixing bracket
(1) Align the side fixing bracket to the mounting hole of the Moonroof Air Deflector. At that time, push in the lower edge of the protect sheet to inside of the vehicle roof by using the side fixing bracket. (Two sections) [Figure 8]
(2) Pull up the side fixing bracket and hook to the lower edge of the flange. Temporarily fix with the masking tape. (Two sections) [Figure 8]
& Caution
Do not install the side mounting brackets forward of the vehicle beyond the R-end. Phillips
i
Moon Air Defl R-end [Figure 8] Screw (with screw lock) (3) As conducted with the front fixing bracket, temporarily fix by using the screw (with screw lock) and the nut. Remove the masking tape attached on the side fixing bracket. (Two sections) [Figure 9] Side fixin M
9] 5 E-69 Fi b
Cross section of fixing bracket [Figure 1O]
Remove the initial positioning masking tape r [Figure 11]
Figure 12]
[Figure 13]
6 6. Mounting of Moonroof Air Deflector
(1) Move the Moonroof Air Deflector forward/backward and righUleft so the mounting fixing bracket fully contacts the flange surface of the moonroof opening section. (Four sections)
(2) If the rubber edge trim is curled inside, fix to outside by using fingers. [Figure 1O]
& Caution
Conduct operations thoroughly; otherwise, rain water may leak from the roof.
(3) Check that the Moonroof Air Deflector position is symmetric to the moonroof opening section. [Figure 11]
(4) Remove the masking tape for initial positioning of the front end of the rubber molding on the Moonroof Air Deflector.
(5) Fully tighten screws (with screw lock) and nuts of each fixing bracket by using a Phillips-head screw driver (with torque control function) and a wrench.
(Torque : 1.4 ± 0.2 Nm) & Caution
· Turn the screws (with screw lock) for final tightening of the screw (with screw lock) and the nut. Excessive tightening of the nuts may break the vehicle and the fixing bracket.
· When tightening the screws (with screw lock), tighten four screws uniformly.
· Check that the rubber edge trim is not curled in. 7. Inspection after completion of mounting
(1) Lightly push and pull the Moonroof Air Deflector up/down and forward/backward, and check that the Moonroof Air
Deflector is securely mounted. [Figure 12] (2) Operate the moonroof and check that the moonroof properly opens/closes.
[Figure 13]
E-69
**************************************************************************************************************
**************************************************************************************************************
