NHTSA ID Number: 10232888
Manufacturer Communication Number: 1216614
Summary
Revised L/Front Dash Speaker Grille
NUMBER: 12-166-14
DATE: 03/03/14
| APPLICABILITY: | 2010-2014MY Legacy and Outback Models |
| SUBJECT: | Revised L/Front Dash Speaker Grille |
INTRODUCTION
A design change has been made to the retaining hook and reinforcement rib portions of the left front dash speaker grille to increase retention and maintain proper fit to the dashboard trim.
COUNTERMEASURE IN PRODUCTION
The new speaker grille was incorporated into production during October, 2013 starting with the following VINs: Legacy- E*015842 and Outback- E*240453.
PART INFORMATION
| PART NAME | NEW PART NUMBER |
|---|---|
| GRILLE-SPEAKER, SIDE | 66119AJ06A |
SERVICE PROCEDURE / INFORMATION
Use a plastic trim tool to CAREFULLY remove the old speaker grille from the dash as shown below. Install the new grille by inserting the 2 front claws into their holes in the dash structure closest to the windshield first. After the rear hook and the retaining clip are secure, confirm proper retention and fit.
10 Affected Products
Vehicles
| MAKE | MODEL | YEAR |
| SUBARU | LEGACY | 2010-2014 |
| SUBARU | OUTBACK | 2010-2014 |
1 Associated Document
Manufacturer Communications
NUMBER: 12-166-14
DATE: 03/03/14
https://www.nhtsa.gov/recalls?nhtsaId=10232888
MC-10232888-9999.pdf 829.185KB
Loading...
Reload document
Open in new tab
NHTSA ID Number: 10068297
Manufacturer Communication Number: 12-166-14
Summary
SUMMARY TO BE PROVIDED ON A FUTURE DATE.
1 Associated Document
Service Bulletin Document
NUMBER: 12-166-14
DATE: 03/03/14
https://www.nhtsa.gov/recalls?nhtsaId=10068297
SB-10068297-0699.pdf 829.185KB
Loading...
