Hub Remover / Special Tool – J-53014 – 2012-2018 Subaru

“This site contains affiliate links for which OEMDTC may be compensated”

NHTSA ID Number: 10173125

Manufacturer Communication Number: 14-24-20

Summary

This service information bulletin outlines a procedure for Subaru Special Tool Kit number J-53014.



15 Affected Products

Vehicles

MAKE MODEL YEAR
SUBARU CROSSTREK 2013-2017
SUBARU FORESTER 2014-2018
SUBARU IMPREZA 2012-2016








NUMBER: 14-24-20
DATE: 03/19/20

APPLICABILITY: 2012MY-2016MY IMPREZA
2013MY-2017MY CROSSTREK
2014MY-2018MY FORESTER
SUBJECT: Hub Remover / Special Tool – J-53014



INTRODUCTION

This Service Information bulletin outlines a procedure for Subaru Special Tool kit number J-53014. These special tools are used when the rust of the rear hub is severe making it difficult to remove.



PART INFORMATION

ILLUSTRATION Part Number DESCRIPTION
Plate A 28499SG000 When using this product, use it as a set of 2.
Plate B 28499SG010 When using this product, use it as a set of 2.
Bolts 28499SG020 When using this product, use it as a set of 4.



SERVICE PROCEDURE / INFORMATION

  1. Remove the 4 hub housing fastening bolts.



  1. Thread 2 bolts into the outer hub bolt holes.



NOTE: Make sure the bolts clear the hub bolts.  (NG photo shown here)



  1. Attach Plate B 28499SG020 to the face between the hub unit and the back plate. NOTE: Pay attention to the mounting direction of Plate A.



  1. Attach Plate A between Plate B and bolt flange. Tighten by hand until the bolt is seated on Plate A.



  1. Install plates A, B, bolts on the opposite side.



  1. Remove the hub unit by tightening the bolts using a 14 mm box-end wrench in a crossing pattern as shown below.



NOTE: Tighten the bolts in a crossing pattern to evenly apply axial force.  If force is unevenly applied, the hub unit may stick in the housing and become extremely difficult to remove.



  1. By tightening the bolts as specified, the hub should release from the housing normally.

NOTE: If rust sticking is severe, the use of penetrating lubricant (e.g. PB Blaster or equivalent) is recommended.
