NHTSA ID Number: 10174544
Manufacturer Communication Number: 05-74-20
Summary
This bulletin provides a service procedure to address a small number of customer concerns regarding a knocking type sound coming from the engine compartment when going over bumps at low speed.
NUMBER: 05-74-20
DATE: 04/30/20
APPLICABILITY: | 2020MY BRZts / Tuned by STI Model |
SUBJECT: | Knocking -Type Sound from Engine Compartment |
INTRODUCTION:
This bulletin provides a service procedure to address a small number of customer concerns regarding a knocking -type sound coming from the engine compartment when going over bumps at low speed. The sound is a result of foreign material trapped between the attachment surfaces of both stays and the toe board bracket and strut tower. The stays are identified in the red call-outs below and the mounting points in green.
PART INFORMATION:
Description | Part Number |
FLANGE NUT M8 | 902370062 |
FLANGE BOLT 8X25 | 901000404 |
NOTE: These flange nuts (3 per stay) and flange bolts (1 per stay) are all one-time use items and MUST be replaced once they have been removed.
SERVICE PROCEDURE / INFORMATION:
REMINDER: Customer satisfaction and retention starts with performing quality repairs.
- Road test the vehicle to confirm the customer’s concern.
- If the condition is confirmed, remove the stays and road test again to determine if the condition still exists.
- If the sound persists, the root cause is elsewhere. The strut mount(s) would be the next component to investigate.
- If the sound is gone, proceed to 3).
- Remove both stays and discard the removed hardware.
- Thoroughly clean both the mounting surfaces of the stays and the corresponding mounting surfaces on the strut towers and toe board mounting bracket as shown below. Use a mild solvent on a clean shop cloth and allow to thoroughly dry before reassembly.
- Reassemble in reverse order using new hardware. Torque all of the new flange nuts and bolts to 16 Nm (11.8 ft. lbs.).
- Road test the vehicle again to confirm the repair.
1 Affected Product
Vehicle
MAKE | MODEL | YEAR |
---|---|---|
SUBARU | BRZ | 2020 |
1 Associated Document
Manufacturer Communications
NUMBER: 05-74-20
DATE: 04/30/20
https://www.nhtsa.gov/recalls?nhtsaId=10174544
MC-10174544-0001.pdf 1183.744KB
