NHTSA ID Number: 10180731
Manufacturer Communication Number: 09-72-20R
Summary
This bulletin announces availability of new intake manifold assemblies.
NUMBER: 09-72-20R
DATE: 07/31/20
REVISED: 09/11/20
APPLICABILITY: | 2017-20MY Impreza 2018-20MY Crosstrek 2018-20MY Crosstrek Hybrid (PHEV) |
SUBJECT: | Intake Manifold / Tumble Generator Valve (TGV)- Design Change |
INTRODUCTION:
This bulletin announces availability of new intake manifold assemblies. These new manifolds include enhanced TGV assemblies to address related DTCs which may set as a result of lubricant contained within the actuator component of the TGV leaking and being drawn into the engine. Over time, the TGV operation can become erratic and cause any of the following TGV related DTC(s) to set: P2004, P2005, P2006, P2007, P2009 and / or P2012. The internal sealing of the TGV actuator assembly has been optimized to eliminate lubricant leakage into the engine. Since the TGV component is not serviced separately, the intake manifold assembly must be replaced when a failure is confirmed.
PRODUCTION CHANGE INFORMATION:
The new Intake Manifold assemblies were incorporated into production as per the table below.
Model | Starting VIN |
Impreza 4-Door | L3612652 |
Impreza 5-Door | L3728005 |
Crosstrek | LH264200 |
Crosstrek Hybrid | LH262309 |
PART INFORMATION:
Description | Part Number | Application |
MANIFOLD COMPLETE- INTAKE | 14001AC501 | Crosstrek & Impreza |
14001AC631 | Crosstrek Hybrid (PHEV) |
REMINDER: Always order the most up-to-date replacement parts based on the specific VIN being repaired.
SERVICE PROCEDURE / INFORMATION:
REMINDER: Customer satisfaction and retention starts with performing quality repairs.
The service procedures for Intake Manifold replacement remain unchanged. Always refer to the applicable Service Manual and review the full requirements of the repair being performed. The Service Manual procedures contain information critical to performing an effective repair the first time, every time. This includes but is not limited to, proper inspection criteria, necessary special tools, required processes and related one-time-use parts needed for a complete and lasting repair.
7 Affected Products
Vehicles
MAKE | MODEL | YEAR |
SUBARU | CROSSTREK | 2018-2020 |
SUBARU | IMPREZA | 2017-2020 |
1 Associated Document
Manufacturer Communications
NUMBER: 09-72-20R
DATE: 07/31/20
REVISED: 09/11/20
https://www.nhtsa.gov/recalls?nhtsaId=10180731
MC-10180731-0001.pdf 878.129KB
NHTSA ID Number: 10177834
Manufacturer Communication Number: 09-72-20
Summary
This bulletin announces availability of new intake manifold assemblies which include enhanced TGV assemblies to address related DTCs which may set as a result of lubricant contained within the actuator component of the TGV leaking and being drawn into the engine.
1 Associated Document
Manufacturer Communications
NUMBER: 09-72-20
DATE: 07/31/20
https://www.nhtsa.gov/recalls?nhtsaId=10177834
MC-10177834-0001.pdf 996.616KB
