NHTSA ID Number: 10173198
Manufacturer Communication Number: 09-71-20
Summary
This bulletin provides a service procedure to address a small number of concerns regarding a rattle/ buzz-type sound coming from the fuel tank area.
NUMBER: 09-71-20
DATE: 03/31/20
| APPLICABILITY: | 2017-20MY Impreza 2018-20MY Crosstrek 2019-20MY Forester |
| SUBJECT: | Rattle / Buzz -Type Sound from Fuel Pipe at Fuel Tank |
INTRODUCTION:
This bulletin provides a service procedure to address a small number of concerns regarding a rattle / buzz-type sound coming from the fuel tank area. The sound may occur due to a slight deformation of the plastic fuel tank in the area (Area A shown in the illustration below) where a plastic fuel delivery pipe is secured. If the tank does not hold the pipe securely, the rattle / buzz may result from clearance between the tank and pipe.
PART INFORMATION:
An EPT Foam Seal Kit, p.n. 63599AJ010 is required.
REMINDER: Always order the most up-to-date replacement parts based on the specific VIN being repaired.
SERVICE PROCEDURE / INFORMATION:
REMINDER: Customer satisfaction and retention starts with performing quality repairs.
NOTES:
- This procedure can be performed without lowering or removing the fuel tank assembly by removing the rear seat cushion and fuel pump / level sensor access cover.
- If either of the 2 white plastic clips securing the seat cushion to the floor panel come out of the floor along with the seat cushion, they MUST be replaced.
Step 1) Remove the rear seat cushion and the fuel pump / level sensor access cover following the procedures in the applicable Service Manual.
Step 2) Using the EPT Foam Seal Kit, prepare three pieces (2 pcs. of Size A and 1 pc. of Size B) of self-adhesive foam as shown in the illustrations below:
Step 3) CAREFULLY remove / disengage the fuel pipe from Area A as shown in the photo below.
Using the illustrations and photos below as a guide, thoroughly clean the areas where the Size A and Size B EPT foam pieces will be applied using isopropyl alcohol on a clean shop cloth and allow to completely dry. Peel the backing and apply the two Size A foam pieces.
Step 4) CAREFULLY refit the fuel pipe back into position on the tank. Peel the backing an apply the one Size B foam piece over top of the fuel pipe and in between the two Size A foam pieces as shown below.
Step 5) Reinstall the fuel the fuel pump / level sensor access cover and rear seat cushion in reverse order of removal to complete the procedure.
9 Affected Products
Vehicles
| MAKE | MODEL | YEAR |
| SUBARU | CROSSTREK | 2018-2020 |
| SUBARU | FORESTER | 2019-2020 |
| SUBARU | IMPREZA | 2017-2020 |
1 Associated Document
Manufacturer Communications
NUMBER: 09-71-20
DATE: 03/31/20
https://www.nhtsa.gov/recalls?nhtsaId=10173198
MC-10173198-0001.pdf 1590.497KB
