NHTSA ID Number: 10233426
Manufacturer Communication Number: 055814
Summary
Sound from Rear Suspension Upper Control Arm
NUMBER: 05-58-14
DATE: 03/13/14
APPLICABILITY: | 2011MY Legacy, Outback, Forester, Impreza, WRX, & STI Models |
SUBJECT: | Sound from Rear Suspension Upper Control Arm |
INTRODUCTION
This bulletin provides a procedure for diagnosing and repairing a rattle-type rear suspension sound determined to be coming from the upper control arm ball joint. A revised torque specification for the ball joint retaining nut / bolt set is also included.
COUNTERMEASURE IN PRODUCTION
MODEL | STARTING VIN |
Legacy | B*024553 |
Outback | B*075920 |
Forester | B*760668 |
Impreza, WRX & STI 4-Door | B*520604 |
Impreza, WRX & STI 5-Door | B*827341 |
PART INFORMATION
PART NAME | PART NUMBER |
Bolt | 901000182 |
Nut | 902350032 |
SERVICE PROCEDURE / INFORMATION
- Once the condition has been confirmed, remove both rear tire and wheel assemblies for access to the suspension components as BOTH sides of the vehicle must be inspected.
- Remove the nut and bolt securing the upper control arm ball joint to the bearing housing as indicated in the illustration above.
- Rock the upper arm and the bearing housing as necessary to check for any looseness or free-play in the upper arm ball joint.
- If any looseness in the ball joint is visible or felt, replace the upper arm assembly for that side of the vehicle following the procedure outlined in the applicable Service Manual.
- ALWAYS install a NEW ball joint retaining nut and bolt set then torque to 90 Nm (66.4 ft. lbs.).
- Repeat steps 2 through 5 for inspection / repair to the opposite side of the vehicle.
1 Affected Product
Vehicle
MAKE | MODEL | YEAR |
SUBARU | LEGACY | 2011 |
1 Associated Document
Manufacturer Communications
NUMBER: 05-58-14
DATE: 03/13/14
https://www.nhtsa.gov/recalls?nhtsaId=10233426
MC-10233426-9999.pdf 356.212KB
