Accessory Installation Guide
| 2025MY Forester Utility Hook Manual Rear Gate | F5510SL060 |
UTILITY HOOK MANUAL RR GATE KIT
Installation Manual
Genuine part number F5510SL060
Applicable car model FORESTER 2025MY ～
Installation Instructions
１．Remove the Trim caps of the rear gate with a flat blade screwdriver.
Caution
The removed trim caps will not be re-used. Place trim caps in glove box.
２．Fit the washer to the turn nut, and slightly insert it into the screw of the Utility hook.
３．Insert the Utility Hook to the rear gate and turn it clockwise by hand.
Caution
When fastening the Utility Hook, install it securely until it touches the vehicle trim and the hook does not rattle and turn.
Tip
Make sure that the screws are tightened before installing the hooks. If the hook spins freely, use a flathead screwdriver to correct the direction of the turn nut (1) and check it that the screws are tightened again (2). Turn nut will be pulled to downward by screwed bolt (3) if its position is correct.
４．Tie on the caution label to the installed utility hook.
Post-Installation Check
Check the followings;
・Make sure that there is no rattling or looseness of each Utility Hooks.
・Make sure that the Caution label is tied on to the Utility Hook.
5. Rear Gate Stopper Installation
Note
Please put the stopper in the Under-floor storage after installation check.
This stopper is only for RH side when rear gate is opening. It cannot be installed on the LH side or when rear gate closing.
（1）Hold the bottom end of the stopper with your right hand and hold it near the Bracket B.
Tip
Please make sure that do not scratch to vehicle body by the end of the stopper when installing.
（2）Run the band of upper side through the Bracket A as shown in the figure.
Then insert the tip of the holder into the gap between the Bracket A and rear gate panel.
（3）Properly fit a groove of the bottom end of the stopper to the Bracket B. There is a gently match point of the groove and the bracket edge.
（4）Fasten the button of the band of upper side.
Then wrap the band of the bottom side around the damper and fasten the button.
Caution
Please make sure that the button is fastened properly before use the hooks. There is a risk of breakdown or injury.
（5）Please do it in reverse order when remove the stopper.
