Accessory Installation Guide
| 2025MY Forester – Cargo Shelf Kit | F5510SL110 |
CARGO SHELF KIT
Installation Manual
Genuine part number F5510SL110
Applicable car model FORESTER 2025MY ～
Installation Instructions
１．Remove the trim cap with flat-blade screwdriver
Caution
The removed trim covers will not be reused.
Place trim covers in glove box.
２．Turn the Utility hook clockwise by hand to install it to the trim.
Caution
When fastening the Utility hook, install it securely until it touches the vehicle trim and the Utility hook does not rattle and turn.
３．Tie-on the two Caution labels to both RH and LH hooks installed on vehicle backward.
<When installing another optional Utility Hooks (6 hooks in total)>
Please hand over the unused one caution label to the customer.
Post-Installation Check
・Make sure that there is no rattling or looseness of each Utility hooks.
・Make sure that the Caution label is tied-on to the Utility hook properly.
4．Confirm the location where the Utility bar install. The Utility bar should be inserted center of the Utility hooks which are installed location ① and ②.
Caution
Genuine Utility Hook must be used to install this product. It can cause breakdown or unexpected injury if don’t use genuine Utility Hooks.
Do not install on the built-in hooks of vehicle and topmost Utility hooks for this shelf.
5．Installing the Utility Bars
(1) Twist the Utility Bar to release the lock and then extend it to its installation length.
(2) Insert the ends of the Utility Bar firmly as far as it will go.
Caution
Do not install the Utility Bars in any holes other than the Utility Hooks.
(3) Push each side of Utility bar to outward and then rotate the bar to fasten firmly.
Caution
Clearance between the bar ends and hooks can cause breakdown, rattling noise and unexpected injury.
Post-Installation Check
・Make sure that there is no rattling or looseness of each Utility bars.
6. Expand the Cargo shelf and put on the Utility Bars. Make sure that the sponge which is attached on the back side of the shelf is positioned inside the bar.
Refer the figure below to make sure that the front/rear direction and the position of the sponges are correct.
<Usage example>
Make the J-shaped hook and hang it to the top of the rear gate to temporally hold the board in opening state.
F5510SL110
https://techinfo.subaru.com/stis/doc/accInstallGuide/F5510SL110%20Forester%20CARGO%20SHELF%20KIT.pdf
https://static.oemdtc.com/AccessoryInstallationGuide/F5510SL110.pdf
Loading...
Reload document
Open in new tab
- Fitment:The trunk cover fit for Subaru Forester 2009 2010 2011 2012 2013（FIT with Manual Rear GATE)
- Update Version:There is no gap between the back seats and the trunk cover.The fabric of the cover is adequate and nicely blends with the rear cargo area carpeting. It does not rattle in the open or closed position.The spring that retracts it is strong.
- Function: Good privacy cover all around.Trunk Shielding Shade help protect your belongings from damaging UV rays.Hide your precious property under the cargo cover to added measure of security and peace of mind.
- Easy Install:Retractable for easy cargo access and removal.The retractable cargo area cover conceals your cargo area from view for added peace of mind.
- Easy Install:Fully retractable like a window shade for easy use and removal,Direct snap-on designed,Very easy to install.
![RED SHIELD Auto Trunk Organizer for Car, SUV, or Minivan – 22.4 x 7.08 inches [Black]](https://m.media-amazon.com/images/I/51EO+mlVOBL._SL160_.jpg)
- KEEP YOUR TRUNK ORGANIZED: Have you ever got annoyed by items rolling around in the trunk? If you are looking for a trunk organizer to keep your items in place, here's an ideal storage shelf for automotive essentials to keep items from rolling around in the trunk. No more mess with RED SHIELD's trunk divider.
- EASY TO CLEAN: Simple to keep clean the trunk divider. All you need to do is using mild soap and water to wipe away mess and hand dry. As RED SHIELD trunk organizer does not require to use sticky adhesive, or sticker, it will not leave a weird or sticky residue in your trunk and won’t damage. You can simply attach and detach with velcro.
- HIGH-QUALITY MATERIAL: Waterproof organizer made from polyurethane ideal for trunks with carpet lined trunks. Velcros hold your stuff strongly and tightly, so store cleaning tools, towels, shoes, sandals, brushes, picnic mats, bags, groceries, and more easily.
- MULTIPURPOSE FEATURES: Easy to attach and detach, waterproof, durable shelf to secure items in place. Suitable for sedan, truck, SUV, RV, and any cars. If you are planning a trip, it will absolutely assist you. Perfect gift idea. Auto Trunk Towel Rack [not included]. More options available at RED SHIELD.
- ELASTIC STRAP: RED SHIELD Elastic strap helps to secure multiple items that are prone to falling and prevent moving and sliding. Ideal for holding car washing products and allows for convenient access and storage.
- [Premium Quality] Our car trunk organizer is made of high-quality oxford cloth fabric with 4 Magic sticks, upgraded sewing, light weight nylon mesh and 3 buckles. Durable, waterproof and anti-scratch, ensures it's longevity.
- [Suitable Size] Dimension of 35" in length and 17" in width. Universal fit for most cars, vehicles, SUVs, vans, fit 90% car types. Road trip essentials for adults, very useful and convenient while your road traveling. Our foldable trunk organizer will not take up big space to store.
- [Keep Tidy] Is your trunk storage a mess? This would definitely helped. There are 4 deep pockets and mesh pockets for extra storage which you can keep your stuff together and organized, like tools, toys, snacks, books, etc. Also easier to find anything you need when you are in a rush. Provide you with a clean trunk.
- [Easy installation and cleaning] Quickly install and remove in seconds, use adjustable shoulder straps, clip around your headrests and that's done. And it is washable, you can clean by using wet cloth. Instruction is attched in the picture.
- [Worry-Free Shopping Experience] If you have any issues or question about our products, please let us know, we are always here to satisfy all of you.
- Perfect Fitment: Based on the original car design, 1:1 ratio of production. Rear trunk mat compatible with 2019 2020 2021 2022 2023 2024 Subaru Forester. Please check your car model before purchasing.
- Premium Materials: Made of high quality TPE material. TPE cargo mats without any bad smell, can be bent and folded, with strong elasticity and flexibility.
- Abundant functionality: Cargo liner enhance appearance, protect your trunk 24/7. Keep your car clean, protect your trunk away from scratches and stain.
- Easy Installation: Very easy to install and remove. Install the trunk liner directly in the trunk without any other tools or cutting. When you want to clean, take it out and rinse it with water or towel.
- Warranty: If you have any questions with the rear trunk mat replacement for your Subaru Forester 2019 2020 2021 2022 2023 2024, please contact us immediately and we will provide a satisfactory after-sales service.
- Cargo Liner for Subaru Ascent: Trunk mat is compatible with 2019-2024 Subaru Ascent. Only Fits Models equipped with Subwoofer in cargo area. Behind The 2nd Row Seats.
- All Season Guard and Safe TPE Material: Cargo mat is made of premium durable TPE materials, wear-resistant, non-slip and odorless. High tensity and safe TPE material keeps its flexibility in all season while still offering an excellent feel and extreme wear resistance.
- Non-slip and Trap Debris: With a textured non-slip surface and unique channels, this weatherproof cargo liner can effectively trap sand, water, mud, dirt, rain and muck. You won't have to worry about your luggage scratching or staining the original carpet thanks to the trunk liner.
- Spill Blocking Sides: The trunk mat has a raised lip all the way around to keep liquids and debris from reaching your original floor. Make sure the mess stays on the trunk mat and off your original clean carpet. Protect your vehicle from all kinds of damage.
- Convenient and Easy to Clean: The weatherproof and stain-resistant cargo liner is easy to clean by wiping with a wet towel or rinsing with water directly. *Attention: The cargo liner is folded for shipping. Just place it under the sun to help get the creases out.
- APPLICATION: This cargo cover perfectly fits for Subaru XV Crosstrek 2012 2013 2014 2015 2016 2017, Subaru Impreza 2013 2014 2015 2016
- SUPERIOR MATERIAL: the trunk cover is durable and waterproof nylon with strong aluminum alloy structure.Strong bearing capacity, durability, anti- wear and anti-tear, anti-deformation and anti-impact and aging resistance for long-lasting reliability.
- FUNCTION: This cargo cover covers the back cargo area to protect valuable and personal items that you place in the back and keep your items away from peeping eyes. The Cargo Security Shade will help protect your valuables from damaging UV rays, and provides more storage space.
- SIMPLE INSTALLATION: No drilling&tools required. Direct snap-on designed to directly match the original car hole to install and no damage to your car.
- AFTER-SALES SERVICE: If you're not 100% satisfied with our cargo cover, simply return it for a full refund in 30 days.
- Precise Fit---This cargo cover is custom fit for Subaru Forester 2019 2020 2021 2022 2023 2024.Please check the model before purchasing.
- Fully Covered---Different from other ordinary trunk shade covers,we made an extra piece to cover the gap between the bar and the second row of seats.Comprehensive protection from UV rays,and giving you a more private trunk space for added security.
- Extra Storage Net---Specially designed a cargo net on the trunk cargo cover to put some small stuffs.A clever and simple way to enlarge storage space.Keep your vehicle organized.
- Excellent Materials---Our trunk cover is made of high-grade aluminium alloy&waterproof PVC with carbon fiber texture.Both ends of the crossbar with sound insulation cotton,will not make any noise while driving.Super stable and firmly.
- Simple Installation---No need any tools or modified,the installation can be done in few seconds.Easy to remove and install.
- 【Fitment】-Compatible with Subaru Crosstrek 2024 Touring,Limited,Wilderness,Convenience, Sport,Premium,Base,Onyx Edition, Impreza 2024 RS,Sport,Base.
- 【Rear Cargo Cover Application】 ①Protect your belongings from damaging UV rays. ②Hide your valuables and privacy under the extended cargo screen,ensure the safety of valuables. ③Separate the passenger room and the cargo area,make it faster to warm up/cool down. ④Provide larger storage space,light pacels could be loaded on extended cargo screen.
- 【High Quality】 ①The main bar is made of thicker aluminum alloy,stronger and more durable. ②The cargo screen is made of waterproof PVC,wear-resistant and easy to clean.
- 【Custom Fit and Easy Installation】 ①Special designed open handle makes you easy to catch,easier to pull out and release. ②Chamfered and polished latch bar will not scratch your trunk interior. ③Design according to the original vehicle radian, perfectly fits car's trunk wall. ④Install in a few munites,NO drilling needed,easy to use and removal.
- 【Quality Assurance】-30 days free return and refund,365 days free replacement.
- 【Perfect Fit】 - Cargo liner custom molded specifically for your 2019 2020 2021 2022 2023 2024 Subaru Forester (with Subwoofer models Needing to be clipped). Precision digital laser scanning ensures complete carpet protection.
- 【2024 Upgrade Material】 - The cargo mat made with premium TPE material. odorless, and environmentally friendly. Provides excellent grip, ensuring no slipping.
- 【All-Weather Guard Protection】: Make the car keep far from the Mud,Dirt, Snow, Water and the rear trunk look good.Top of the line all-weather, stain-resistant, 100% waterproof odorless protection that gives your car,SUV, truck, or van interior a first class look while protecting the resale value.
- 【Easy to Clean】: The Cargo Mat of the textured skid-resistant surface is easily cleaned by wiping clean, hosing off, or simply using soap and water for a tough mess.
- 【Great Gift】 - This Quality cargo liner makes a perfect gift for Cars owners. LIMITED LIFETIME warranty for any manufacturer defects. Contact us for any fitment issues.
Last update on 2024-04-22 / Affiliate links / Images from Amazon Product Advertising API
This product presentation was made with AAWP plugin.
SEOCONTENT-START
Installation Manual
△00
1
CARGO SHELF KIT
Genuine part number Applicable car model
F5510SL110 FORESTER 2025MY ～
Installation order is as follows;
1. Utility Hooks x4
2. Utility Bars x2
3. Cargo Shelf x1
Please make sure that the Cargo Shelf can be opened and hanged after installation.
Close the Rear Gate after putting down the Cargo Shelf into place. It can cause breakdowns if close the Rear Gate with the Cargo Shelf opening.
Note
Kit includes
No. Components Qty.
1 Utility Hooks 4 Marks
Part Number F5510SL010×2 2 Caution Labels
3 Utility Bars
4 Cargo Shelf 2
2 Part Number F5510SL020×2
1 Part Number F5510SL100×1 ※Instruction manuals are included in each one.
① ② ③ ④
※Instruction
manuals Installation Instructions
１．Remove the trim cap with flat-blade
screwdriver Front of Vehicle Caution
The removed trim covers will not be re- used. Place trim covers in glove box. Trim Cap ２．Turn the Utility hook clockwise by
hand to install it to the trim. Front of Vehicle Caution
When fastening the Utility hook, install it securely until it touches the vehicle trim and the Utility hook does not rattle and turn. Utility Hook ３．Tie-on the two Caution labels to both RH and
LH hooks installed on vehicle backward.
Please hand over the unused one caution label to the customer.
Tip
How to tie on the Caution label; Front of Vehicle Utility Hook Caution Label Post-Installation Check
・Make sure that there is no rattling or looseness of each Utility hooks.
・Make sure that the Caution label is tied on to the Utility hook properly. 2 4．Confirm the location where the Utility bar install. The Utility bar should be inserted center of the Utility hooks which are installed location ① and ②. Caution
Genuine Utility Hook must be used to install this product. It can cause breakdown or unexpected injury if don’t use genuine Utility Hooks.
Do not install on the built-in hooks of vehicle and topmost Utility hooks for this shelf. 5．Installing the Utility Bars
(1) Twist the Utility Bar to release the lock and then extend it to its installation length. (2) Insert the ends of the Utility Bar firmly as far as it will go. Front of the vehicle Lock release Caution
Do not install the Utility Bars in any holes other than the Utility Hooks. Correct Insert all the way. Incorrect (3) Push each side of Utility bar to outward and then rotate the bar to fasten firmly. Caution
Clearance between the bar ends and hooks can cause breakdown, rattling noise and unexpected injury. Push outward. Push outward. Post-Installation Check
・Make sure that there is no rattling or looseness of each Utility bars. 3 4
Hinge
Sponge
Sponges are in front of the bar.
Hinge doesn’t catch the bar if the sponges are behind the bar.
Δ Content
Revised Content
Date
Δ00
Δ01 Δ02
Created New
2023.10.06
6. Expand the Cargo shelf and put on the Utility
Bars. Make sure that the sponge which is attached on the back side of the shelf is positioned inside the bar. Refer the figure below to make sure that the front/rear direction and the position of the sponges are correct.
Make the J-shaped hook and hang it to the top of the rear gate to temporally hold the board in opening state.
**************************************************************************************************************
**************************************************************************************************************
