NHTSA ID Number: 10235918
Manufacturer Communication Number: 1215113R
Summary
Increase to Detent Force of Front Door Checker Mechanism
NUMBER: 12-151-13R
DATE: 05/07/13
REVISED: 10/30/13
| APPLICABILITY: | 2014MY Forester Models |
| SUBJECT: | Increase to Detent Force of Front Door Checker Mechanism |
INTRODUCTION
If you receive a customer concern of the front door checkers not holding the doors securely enough in the half or fully open positions, this bulletin informs of a change which adds 2 additional holding positions and an increase to the detent force of the front door checker mechanism. The new door checker provides a more positive feeling when holding the front doors in partially open positions.
COUNTERMEASURE IN PRODUCTION
The new door checker mechanisms were incorporated into production on October 10, 2013 starting with VIN E*508768.
PART INFORMATION
NOTE: The same part number is used for both the left and right front doors.
| PART NAME | NEW PART NUMBER | OLD PART NUMBERS |
| CHECKER ASSY DR F | 61124SG003 | 61124SG000, 002 |
SERVICE PROCEDURE / INFORMATION
Follow the procedure in the applicable Service Manual for replacing the door checker assembly.
1 Affected Product
Vehicle
| MAKE | MODEL | YEAR |
| SUBARU | FORESTER | 2014 |
1 Associated Document
Manufacturer Communications
NUMBER: 12-151-13R
DATE: 05/07/13
REVISED: 10/30/13
https://www.nhtsa.gov/recalls?nhtsaId=10235918
Loading...
Reload document
Open in new tab
NHTSA ID Number: 10068658
Manufacturer Communication Number: 12-151-13R
Summary
SUMMARY TO BE PROVIDED ON A FUTURE DATE.
1 Associated Document
Service Bulletin Document
NUMBER: 12-151-13R
DATE: 05/07/13
REVISED: 10/30/13
https://www.nhtsa.gov/recalls?nhtsaId=10068658
Loading...
NHTSA ID Number: 10234847
Manufacturer Communication Number: 1215113
Summary
Increase to Detent Force of Front Door Checker Mechanism
1 Associated Document
Manufacturer Communications
NUMBER: 12-151-13
DATE: 05/07/13
https://www.nhtsa.gov/recalls?nhtsaId=10234847
MC-10234847-9999.pdf 423.735KB
Loading...
